BLACK+DECKER WDC115WA-QW Rechargeable Wet/Dry Vacuum Cleaner User Manual

Introduction

Image: Front view of the BLACK+DECKER WDC115WA-QW Rechargeable Wet/Dry Vacuum Cleaner, showcasing its compact design and transparent dust bowl.

Thank you for choosing the BLACK+DECKER WDC115WA-QW Rechargeable Wet/Dry Vacuum Cleaner. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new appliance. Please read these instructions carefully before use and retain them for future reference.

This compact and versatile handheld vacuum is designed for quick clean-ups of both solid debris and liquid spills, powered by a 3.6V Lithium-Ion battery.

Important Safety Instructions

WARNING: When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury.

• Read all instructions before using the appliance.
• Do not use the appliance outdoors or on wet surfaces.
• Do not allow it to be used as a toy. Close attention is necessary when used by or near children.
• Use only as described in this manual. Use only manufacturer's recommended attachments.
• Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, return it to a service center.
• Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything that may reduce air flow.
• Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
• Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
• Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they may be present.
• Use extra care when cleaning on stairs.
• Do not use to pick up toxic material (e.g., chlorine bleach, ammonia cleaner).
• Do not use the appliance in an enclosed space where vapors are given off by oil base paints, paint thinner, some mothproofing substances, flammable dust, or other explosive or toxic vapors.
• Disconnect from electrical outlet before servicing.
• Use only the charger supplied by the manufacturer to recharge.
• Do not incinerate the appliance even if it is severely damaged. The batteries can explode in a fire.
• This appliance is intended for household use only.

Package Contents

Please check the package contents to ensure all items are present and undamaged:

• BLACK+DECKER WDC115WA-QW 5.4Wh/3.6V 1.5Ah Li-ion Wet/Dry Charged Vacuum Cleaner
• Charging Base / Wall Mount
• Crevice Tool
• Brush Attachment
• Squeegee Tool (for wet pick-up)
• Instruction Manual

Setup

Charging the Vacuum Cleaner

Before first use, ensure the vacuum cleaner is fully charged. This typically takes approximately 10-16 hours for a complete charge. The unit is designed for continuous charging, meaning it can be left on the charging base without overcharging.

1. Plug the charging adapter into a standard electrical outlet.
2. Place the vacuum cleaner onto the charging base. Ensure the charging contacts on the vacuum align with those on the base.
3. The charging indicator light (if present) will illuminate to confirm charging is in progress.
4. For optimal battery life, allow the unit to charge for the recommended duration before its initial use.

Image: The BLACK+DECKER WDC115WA-QW vacuum cleaner securely placed on its wall-mounted charging base, connected to a power outlet.

Image: A close-up view of the BLACK+DECKER WDC115WA-QW vacuum cleaner charging on its wall mount, showing the charging cable connected to the wall.

Operating Instructions

Turning On/Off

To turn the vacuum cleaner on, slide the power switch located on the handle forward. To turn it off, slide the switch backward.

Image: A diagram highlighting key features of the vacuum, including the power switch and the quick-release button for the dust bowl.

Dry Pick-Up

For dry debris, ensure the squeegee tool is removed. You can use the vacuum directly or attach the crevice tool for tight spaces or the brush attachment for upholstery and delicate surfaces.

Image: A woman using the BLACK+DECKER WDC115WA-QW handheld vacuum to clean dry crumbs from a kitchen countertop.

Image: A person using the BLACK+DECKER WDC115WA-QW vacuum to clean dirt and debris from a doormat near an entryway.

Image: A woman using the wide nozzle of the BLACK+DECKER WDC115WA-QW vacuum to efficiently clean a dining table.

Wet Pick-Up

For liquid spills, attach the squeegee tool to the nozzle. Hold the vacuum at an angle to allow the squeegee to effectively collect the liquid. Do not immerse the vacuum in water. The maximum liquid capacity is 385ml.

Image: A woman demonstrating the wet pick-up capability of the BLACK+DECKER WDC115WA-QW vacuum by cleaning a liquid spill on a kitchen counter.

Maintenance

Emptying the Dust Bowl

For optimal performance, empty the dust bowl after each use or when the debris reaches the "MAX FILL" line. The transparent dust bowl allows you to monitor the fill level easily.

1. Ensure the vacuum cleaner is turned off.
2. Press the quick-release button (refer to the diagram in Operating Instructions) to detach the dust bowl from the main unit.
3. Hold the dust bowl over a trash receptacle and empty its contents.

Image: A hand holding the BLACK+DECKER WDC115WA-QW vacuum, showcasing its transparent dust bowl for easy monitoring of collected debris.

Image: A person emptying the contents of the BLACK+DECKER WDC115WA-QW vacuum's dust bowl into a trash bin, demonstrating hygienic disposal.

Cleaning the Filters

The vacuum cleaner features a dual filter system. Regular cleaning of the filters is crucial for maintaining suction power and preventing motor damage. Filters should be cleaned after every wet pick-up and regularly after dry pick-ups.

1. After emptying the dust bowl, remove the filters.
2. Tap the filters gently over a trash can to remove loose dust.
3. For a more thorough cleaning, rinse the filters under running water. Ensure they are completely dry before reassembling them into the dust bowl and attaching it back to the vacuum. Do not use a brush or abrasive materials to clean the filters.

Image: A hand rinsing the detachable dust bowl and filter of the BLACK+DECKER WDC115WA-QW vacuum under a running faucet for thorough cleaning.

Troubleshooting

If your BLACK+DECKER WDC115WA-QW is not performing as expected, please consult the following table before contacting customer service.

Specifications

Warranty and Support

BLACK+DECKER products are manufactured to high quality standards and are guaranteed for a period of 24 months from the date of purchase against manufacturing defects. This guarantee does not affect your statutory rights.

The guarantee is valid within the territories of the Member States of the European Union and the European Free Trade Area. To claim on the guarantee, the appliance must be returned to the retailer or an authorized repair agent, along with proof of purchase.

For further assistance, technical support, or to locate an authorized service center, please visit the official BLACK+DECKER website or contact their customer service department. Contact information can typically be found on the product packaging or the official brand website.

Online Support: www.blackanddecker.com/support
