1. Introduction
This manual provides essential information for the safe and effective installation, operation, and maintenance of your Aexit AC 115/230V 15A 2-Pole Miniature Circuit Breaker. This device is designed to protect electrical circuits from damage caused by overload or short circuit conditions, ensuring the safety of your electrical system and connected appliances.
2. Safety Information
Please read all safety warnings and instructions carefully before installing or operating this circuit breaker. Failure to follow these instructions may result in electrical shock, fire, or serious injury.
Image Description: A warning label providing product safety and compliance information in multiple languages. Key warnings include: "Do not allow children to have casual contact," "Handle with care, do not shake forcefully," and "Avoid use in extreme temperatures such as open flames and super high temperatures."
- WARNING: Electrical work should only be performed by qualified and licensed personnel.
- WARNING: Always disconnect power at the main service panel before installing, inspecting, or performing any maintenance on the circuit breaker. Verify the power is off using a voltage tester.
- Ensure the rated voltage (AC 115/230V) and current (15A) of the circuit breaker match your application's requirements.
- Avoid exposing the circuit breaker to extreme temperatures, open flames, or excessive moisture.
- Do not modify or attempt to repair the circuit breaker. Replace damaged units immediately.
- Keep out of reach of children.
3. Product Overview
The Aexit Miniature Circuit Breaker is a compact device designed for reliable circuit protection. It features a robust plastic housing and a clear toggle switch for manual operation.
Image Description: Front view of the Aexit 15A 2-Pole Miniature Circuit Breaker. It is black with a gray toggle switch labeled "ON" in the up position. The front shows the terminal connections for wiring.
Image Description: Top-down view of the circuit breaker, highlighting the two sets of terminal connections. One set is clearly labeled "LINE" indicating the input side for power connection.
Image Description: Bottom view of the circuit breaker, showing the pre-drilled mounting holes and the overall compact design for installation.
Package Contents:
- 1 x Aexit Miniature Circuit Breaker
- 2 x Mounting Screws
Image Description: Image showing the two silver mounting screws included with the circuit breaker, essential for secure installation.
4. Setup and Installation
Proper installation is crucial for the safe and effective operation of the circuit breaker. If you are unsure about any step, consult a qualified electrician.
- Disconnect Power: Before starting any installation, ensure that the main power supply to the circuit is completely disconnected at the service panel. Use a voltage tester to confirm that no power is present.
- Mounting: Select a suitable, stable, and dry location for the circuit breaker. Securely mount the device using the two provided screws through the designated mounting holes.
- Wiring Connections:
- Identify the
