T TICCI Kids Digital Vibrating Alarm Watch

Introduction

This manual provides comprehensive instructions for the T TICCI Kids Digital Vibrating Alarm Watch, Model T1802. This watch is designed to assist children with medication reminders, potty training, and other scheduled activities through silent vibrations or audible alarms. Please read this manual carefully to ensure proper use and maintenance of your watch.

Key Features

• 8 Programmable Alarms: Set up to eight independent alarms with options for vibration only, sound (beep) only, or both vibration and sound. Alarms auto-repeat daily.
• Countdown Timer: Adjustable countdown interval from 15 minutes to 24 hours, useful for timed activities.
• Stopwatch Function: For timing events and activities.
• EL Backlight: Provides illumination for viewing the display in low-light conditions.
• Calendar Display: Shows year, month, week, and date.
• 12/24 Hour Format: Select preferred time display format.
• Water Resistance: 30 meters (suitable for hand washing, cold showers, and swimming, but avoid hot water).
• Lockout Function: Prevents accidental changes to settings.
• Child-Safe Materials: Complies with CPSC regulations, ensuring materials are safe for children.

Image: Overview of the watch's multi-functional display and features.

Setup and Basic Operation

The watch features several buttons for navigation and setting. Familiarize yourself with these buttons:

• Light Button: Activates the EL backlight.
• Set Button: Used to enter setting modes and confirm selections.
• Start Button: Used to start/stop functions like stopwatch or adjust values during setting.
• Stop Button: Used to stop functions or adjust values.
• Mode Button: Cycles through different modes (Time, Alarm, Stopwatch, Countdown).
• Lock/Date Button: Used for the lockout function and to display the date.
• Reset Button: Used to reset values or exit setting modes.

Image: Detailed view of the watch's buttons and their general functions.

Setting Time and Date

1. From the Time display mode, press the Mode button until the time digits begin to flash.
2. Use the Start or Stop buttons to adjust the flashing digit (e.g., hours, minutes).
3. Press the Set button to move to the next setting (e.g., minutes, year, month, day).
4. Repeat steps 2 and 3 until all time and date settings are correct.
5. Press the Mode button to exit the setting mode.

Setting Alarms

The watch supports up to 8 alarms. Each alarm can be set individually.

1. Press the Mode button repeatedly until you reach the Alarm mode (indicated by an alarm icon).
2. Press the Set button to select an alarm slot (e.g., AL1, AL2).
3. With the alarm time flashing, use the Start or Stop buttons to adjust the hour and minute.
4. Press the Set button to move between hour and minute settings.
5. After setting the time, press Set again to choose the alarm type: vibration only, sound only, or both.
6. Press the Mode button to save the alarm and exit.

Operating Functions

Using the Countdown Timer

1. Press the Mode button to navigate to the Countdown Timer mode.
2. Press the Set button to enter the countdown setting.
3. Use the Start or Stop buttons to set the desired countdown duration (from 15 minutes to 24 hours).
4. Press Set to confirm.
5. Press the Start button to begin the countdown.
6. The watch will alert you with vibration/sound when the countdown finishes. The timer automatically resets for the next day.

Using the Stopwatch

1. Press the Mode button to navigate to the Stopwatch mode.
2. Press the Start button to begin timing.
3. Press the Stop button to pause the stopwatch.
4. Press the Reset button to clear the stopwatch to zero.

Activating the Backlight

Press the Light button (usually located on the top left) to illuminate the display for a few seconds.

Lockout Function

To prevent accidental changes to the watch settings, you can activate the lockout function.

1. Simultaneously press and hold both the bottom left (Mode) and bottom right (Reset) buttons for approximately 2 seconds.
2. A lock icon will appear on the display, indicating that the settings are locked.
3. To unlock, repeat the same action: press and hold both the bottom left and bottom right buttons for 2 seconds. The lock icon will disappear.

Maintenance

Water Resistance

The watch is water-resistant up to 30 meters. This means it can withstand splashes, rain, hand washing, cold showers, and swimming. Important: Do not expose the watch to hot water, as this can compromise its water resistance seals.

Cleaning

To clean your watch, wipe it with a soft, damp cloth. Avoid using harsh chemicals or abrasive materials, which can damage the watch's finish or components.

Battery Replacement

When the display becomes dim or the watch functions erratically, the battery may need replacement. Battery replacement should ideally be performed by a qualified watch technician to ensure proper sealing and maintain water resistance.

Troubleshooting

• Watch not vibrating or alarming:
  • Check if the alarm is enabled and set to the correct time.
  • Ensure the alarm type is set to vibration, sound, or both.
  • Verify the watch is not in lockout mode.
• Display is blank or unreadable:
  • The battery may be low or depleted. Consider battery replacement.
  • If the display is jumbled, try resetting the watch (refer to the manual for specific reset instructions, if available, or remove/reinsert battery if comfortable).
• Buttons are unresponsive:
  • Check if the watch is in lockout mode.
  • Ensure no buttons are stuck or jammed.
• Strap breaks or comes loose:
  • Contact customer support for replacement parts or repair options.

Specifications

Image: Watch dimensions and ergonomic design details.

Warranty and Support

Warranty Information

This T TICCI product comes with an 18-month manufacturer's warranty from the date of purchase. This warranty covers manufacturing defects. Please retain your proof of purchase for warranty claims.

Customer Support

For any questions, technical assistance, or warranty claims, please contact T TICCI customer support through the retailer where the product was purchased or visit the official T TICCI website for contact information.
