Introduction
This manual provides essential information for the safe installation, operation, and maintenance of your Arcchio Zuzana Dimmable Wall Light. Please read these instructions carefully before installation and retain them for future reference.
Image: The Arcchio Zuzana Dimmable Wall Light, a black cube-shaped fixture, mounted on a light-colored wall, casting warm light both above and below, illuminating the surrounding area.
Safety Instructions
- Installation must be performed by a qualified electrician in accordance with local wiring regulations.
- Ensure the main power supply is switched off at the fuse box or circuit breaker before commencing any installation or maintenance.
- Do not connect the fixture to a power source other than 230V.
- This product is designed for indoor use only (IP20 rating).
- Do not attempt to modify the fixture in any way.
- Use only G9 bulbs as specified. Do not exceed the maximum wattage of 8W LED.
- Keep packaging materials out of reach of children.
Package Contents
Please check that all components are present and undamaged:
- 1 x Arcchio Zuzana Wall Light Fixture (Model 9621472)
- Mounting hardware (screws, wall plugs)
- Instruction Manual
Note: The G9 bulb is not included and must be purchased separately.
Setup and Installation
- Preparation: Switch off the main power supply at the circuit breaker before starting installation.
- Marking: Hold the fixture against the wall at the desired mounting location. Mark the positions for the mounting holes.
- Drilling: Drill holes at the marked positions. Insert appropriate wall plugs if necessary.
- Wiring: Connect the household electrical wires to the terminal block inside the fixture. Ensure correct polarity (Live, Neutral, Earth). Refer to the internal wiring diagram.
- Mounting: Secure the fixture to the wall using the provided screws. Ensure it is firmly attached.
- Bulb Installation: Carefully insert one G9 bulb (max 8W LED) into the G9 socket.
- Final Check: Once installation is complete, restore power at the circuit breaker.
Image: An open view of the Arcchio Zuzana wall light's interior, revealing the terminal block for electrical connections and the mounting holes. The internal components are neatly arranged within the black metal casing.
Image: An angled perspective of the Arcchio Zuzana wall light, showing the interior where the G9 bulb is to be inserted. The light is emitting a warm glow, indicating the bulb is in place.
Operating Instructions
The Arcchio Zuzana Wall Light operates via your standard wall switch. As it is a dimmable fixture, if connected to a compatible dimmer switch, you can adjust the light intensity.
- Switching On/Off: Use the wall switch connected to the fixture to turn the light on or off.
- Dimming: If a compatible dimmer switch is installed, rotate or press the dimmer control to adjust the brightness level of the light.
Image: A composite image displaying the Arcchio Zuzana wall light in various lighting conditions, demonstrating its dimmable functionality and how it can produce different light intensities and color temperatures.
Maintenance
- Cleaning: Ensure the power is off before cleaning. Wipe the fixture with a soft, dry cloth. Do not use abrasive cleaners or solvents.
- Bulb Replacement: Switch off the power. Allow the bulb to cool completely. Carefully remove the old G9 bulb and insert a new one (max 8W LED).
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Light does not turn on. | No power supply. Bulb is faulty or not installed correctly. Loose wiring connection. | Check circuit breaker. Replace bulb or ensure it is seated properly. Consult a qualified electrician to check wiring. |
| Light flickers. | Loose bulb. Incompatible dimmer switch. Faulty bulb. | Ensure bulb is securely seated. Ensure dimmer switch is compatible with LED bulbs. Replace bulb. |
Specifications
- Model: 9621472
- Brand: Arcchio
- Material: Metal
- Color: Black
- Dimensions (L x W x H): 12 cm x 10 cm x 10 cm
- Weight: 380 grams
- Bulb Socket: G9
- Max Wattage: 8W LED (bulb not included)
- Voltage: 230 Volts
- IP Rating: IP20 (Indoor use only)
- Installation Type: Wall Mount
Image: A technical diagram illustrating the precise dimensions of the Arcchio Zuzana wall light, indicating a width of 100mm, a height of 100mm, and a depth of 100mm from the mounting surface.
Warranty and Support
For warranty information and technical support, please refer to the documentation provided with your purchase or contact Arcchio customer service through their official website or your retailer.
Manufacturer: Arcchio
Contact: Please visit the Arcchio brand store on Amazon for further assistance or product information.
