Introduction
This manual provides detailed instructions for the operation and maintenance of your BOBLOV BT-S3 Helmet Headset. The BT-S3 is designed for motorcycle communication, offering hands-free calling, music playback, FM radio, and intercom functionality for riders. Please read this manual thoroughly before using the device to ensure proper function and safety.
Package Contents
Verify that all items listed below are included in your package:
- 1 x BOBLOV BT-S3 Helmet Intercom Unit
- 1 x Stereo Headphones (with microphone)
- 1 x Mounting Clip & Screws
- 1 x Screwdriver
- 1 x USB Charging Cable
- 1 x User Manual
- 1 x Velcro Pad (for mounting)
- 1 x Audio Line
Figure 1: All components included in the BOBLOV BT-S3 package.
Product Overview
Control Buttons and Ports
Figure 2: BOBLOV BT-S3 control buttons and connection ports.
- Phone Button: Used for answering/ending calls, redialing, and activating voice assistant.
- Volume + Button: Increases volume, navigates forward in music/FM.
- Volume - Button: Decreases volume, navigates backward in music/FM.
- Power/Intercom Button: Powers the device on/off, initiates/ends intercom, plays/pauses music, activates FM radio.
- Charger and Headset Socket: Multi-purpose port for charging and connecting the headset.
- Cable Input Interface: For connecting the headset cable.
Setup
1. Charging the Device
Before initial use, fully charge the BT-S3 unit. Connect the provided USB cable to the charging port on the device and to a standard USB power adapter (not included). The LED indicator will show charging status. A full charge typically takes approximately 2-3 hours.
2. Installing the Headset in Your Helmet
The BT-S3 can be installed in various helmet types, including full-face, half-face, and open-face helmets.
- Attach the mounting clip to the side of your helmet using the provided screws and screwdriver, or use the adhesive Velcro pad for a tool-free installation. Ensure the clip is securely fastened.
- Slide the BT-S3 intercom unit onto the mounting clip until it clicks into place.
- Open the helmet's inner lining. Position the stereo headphones inside the helmet, ensuring they are aligned with your ears for optimal sound.
- Route the microphone to a position near your mouth, ensuring it is not obstructed.
- Connect the headset cable to the designated port on the BT-S3 unit.
Figure 3: Helmet mounting clip and unit attachment.
Operating Instructions
Power On/Off
- Power On: Press and hold the Power/Intercom Button for approximately 3 seconds until you hear an audible prompt and the LED indicator lights up.
- Power Off: Press and hold the Power/Intercom Button for approximately 3 seconds until you hear an audible prompt and the LED indicator turns off.
Bluetooth Pairing with Mobile Phone
- Ensure the BT-S3 is powered off.
- Press and hold the Power/Intercom Button for approximately 5-7 seconds until the LED indicator flashes red and blue alternately, indicating pairing mode.
- On your mobile phone, enable Bluetooth and search for available devices.
- Select "BT-S3" from the list of devices. If prompted for a password, enter "0000".
- Once paired, the LED indicator will flash blue slowly, and you will hear a confirmation tone.
Intercom Functionality
The BT-S3 supports full-duplex wireless communication. It allows for 2 riders to intercom simultaneously, with a maximum talking range of 1000 meters. Up to 3 riders can be connected, but only two can actively communicate at any given time. If a third rider wishes to join, one of the active intercom participants must end their conversation.
Figure 4: Intercom connection scenarios.
- Pairing Intercom Units:
- Ensure both BT-S3 units are powered off.
- On both units, press and hold the Power/Intercom Button for approximately 5-7 seconds until the LED indicators flash red and blue alternately.
- Briefly press the Power/Intercom Button on one of the units. The units will search and pair with each other.
- Once paired, the LED indicators will flash blue slowly, and you will hear a confirmation tone.
- Initiating Intercom: After pairing, a short press of the Power/Intercom Button on either unit will initiate an intercom conversation.
- Ending Intercom: A short press of the Power/Intercom Button will end the intercom conversation.
Phone Calls
- Answer Call: When a call comes in, the device will automatically answer after a few rings (auto-receiving phone calls feature). Alternatively, short press the Phone Button to answer.
- End Call: Short press the Phone Button to end an active call.
- Reject Call: Press and hold the Phone Button for 2 seconds to reject an incoming call.
- Redial Last Number: Double-press the Phone Button to redial the last dialed number.
Music Playback
After pairing with your mobile phone, you can stream music to the BT-S3.
- Play/Pause: Short press the Power/Intercom Button to play or pause music.
- Next Track: Short press the Volume + Button.
- Previous Track: Short press the Volume - Button.
FM Radio
The BT-S3 includes an FM radio function.
- Turn On/Off FM: Double-press the Power/Intercom Button to activate or deactivate FM radio.
- Scan Stations: While FM is active, short press the Volume + or Volume - buttons to change stations.
GPS Voice Instructions
When paired with a smartphone running a GPS application, the BT-S3 can receive voice instructions directly to your headset.
Maintenance
- Keep the device dry. Do not expose it to extreme temperatures.
- Clean the unit with a soft, damp cloth. Avoid using harsh chemicals or abrasive cleaners.
- Ensure the charging port cover is securely closed when not charging to maintain water resistance.
- Store the device in a cool, dry place when not in use for extended periods.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Device does not power on. | Low battery. | Charge the device fully. |
| Cannot pair with phone. | Device not in pairing mode; Bluetooth off on phone. | Ensure BT-S3 is flashing red/blue. Enable Bluetooth on phone and search again. |
| Intercom not connecting. | Units not paired or out of range. | Re-pair intercom units. Ensure units are within 1000m range. |
| Poor audio quality / Wind noise. | Microphone placement; environmental factors. | Adjust microphone closer to mouth. The device features DSP cancellation for wind noise. |
| Battery life shorter than expected. | Frequent use of high volume or intercom. | Battery life varies with usage. Ensure full charge before use. |
Specifications
- Model: BT-S3
- Connectivity: Wireless (Bluetooth)
- Intercom Range: Up to 1000 meters (between 2 riders)
- Working Speed: Up to 100 Km/h
- Talking Time: Up to 8 hours
- Standby Time: Up to 300 hours
- Phone Call Time: Up to 10 hours
- Music Playback Time: Up to 6 hours
- Water Resistance: Water-resistant (fully weather protection)
- Noise Cancellation: Wind noise DSP cancellation
- Features: Auto-receiving phone calls, FM Radio, Stereo music (A2DP), GPS voice instructions
- Helmet Compatibility: Fits all kinds of helmets (full/half/open face)
- Control Method: Touch buttons
- Headphone Jack: 3.5 mm Jack (for headset connection)
- UPC: 889251631535
Figure 5: Estimated battery performance for various functions.
Figure 6: Wireless helmet headset with 1000 meters direct full-duplex intercom.
Figure 7: Versatile applications for the BT-S3 headset, including motorcycling and skiing.
Warranty and Support
Specific warranty information is not provided in the product details. For warranty claims, technical support, or further assistance, please contact your retailer or the manufacturer directly. Retain your proof of purchase for any warranty-related inquiries.
Manufacturer: BOBLOV
