KFI 105590 Winch Plow Mount Instruction Manual

1. Introduction

This manual provides comprehensive instructions for the safe and effective installation, operation, and maintenance of your KFI 105590 Winch Plow Mount. Please read this manual thoroughly before attempting to install or operate the product. Retain this manual for future reference.

The KFI 105590 Winch Plow Mount is designed to attach a snow plow system to various ATV and UTV models, including specific Arctic Cat, CFMOTO, Honda, Kawasaki, KYMCO, Polaris, Suzuki, TGB, and Yamaha vehicles. It facilitates the connection of a winch for raising and lowering the plow blade.

2. Safety Information

WARNING: Failure to follow these safety instructions could result in serious injury or property damage.

• Always wear appropriate personal protective equipment (PPE), including safety glasses and gloves, during installation and maintenance.
• Ensure the vehicle is parked on a level surface, the engine is off, and the parking brake is engaged before beginning installation.
• Do not modify the plow mount or any of its components. Unauthorized modifications can compromise safety and void the warranty.
• Verify all fasteners are securely tightened before operating the plow system. Regularly check for loose hardware.
• Keep hands and clothing clear of moving parts during operation.
• Do not exceed the weight capacity of your ATV/UTV or the plow system.

3. Included Components

Carefully unpack all components and verify that all parts are present before beginning installation. If any parts are missing or damaged, contact KFI Products customer support immediately.

• Winch Plow Mount Assembly
• Mounting Hardware (bolts, nuts, washers, spacers)

Note: A snow plow blade and winch are sold separately and are required for a complete plow system.

4. Setup and Installation

Installation typically requires basic hand tools. Refer to your ATV/UTV owner's manual for specific frame access and torque specifications.

1. Prepare the Vehicle: Park the ATV/UTV on a flat, stable surface. Turn off the engine, engage the parking brake, and remove the ignition key.
2. Locate Mounting Points: Identify the designated mounting points on your vehicle's frame. These are typically located beneath the front of the vehicle, often near the footrests or front suspension.
3. Position the Mount: Carefully lift the KFI 105590 Winch Plow Mount into position, aligning its mounting holes with the vehicle's frame mounting points. It may be helpful to have assistance for this step.
4. Secure with Hardware: Insert the provided bolts through the mount and frame, securing them with washers and nuts. Do not fully tighten at this stage.
5. Adjust and Align: Ensure the plow mount is level and properly aligned with the vehicle's centerline. Make any necessary adjustments.
6. Final Tightening: Once aligned, progressively tighten all bolts to the manufacturer's recommended torque specifications. Refer to your vehicle's manual for specific torque values if available. Double-check all connections for tightness.
7. Attach Plow Push Tubes: Connect your plow's push tubes to the plow mount according to the plow manufacturer's instructions. Ensure the quick-attach pins or bolts are securely fastened.
8. Install Winch (if not already present): If you are installing a new winch, follow the winch manufacturer's instructions for proper installation and wiring. Ensure the winch cable or strap can reach the plow's lift point.

5. Operating Instructions

Once the KFI 105590 Winch Plow Mount and your plow system are fully installed, follow these guidelines for safe operation.

1. Connect Winch to Plow: Attach the winch cable or strap hook to the designated lift point on your snow plow blade's push tube assembly.
2. Raise/Lower Plow: Use your winch's remote control or switch to raise and lower the plow blade. Ensure the plow moves freely and does not bind.
3. Plowing Technique: Engage the plow blade with the snow at a slow, controlled speed. Avoid sudden movements or excessive speed, which can damage the plow, mount, or vehicle. Clear snow in manageable sections.
4. Transport Position: When not plowing, always raise the plow blade to its highest position for transport to ensure adequate ground clearance and visibility.
5. Disengaging Plow: To remove the plow, lower it to the ground, disconnect the winch cable, and then remove the quick-attach pins or bolts securing the plow push tubes to the mount.

6. Maintenance

Regular maintenance will extend the life of your KFI 105590 Winch Plow Mount and ensure safe operation.

• Inspect Regularly: Before each use, inspect the plow mount for any signs of wear, damage, or loose fasteners. Pay close attention to welds, bolts, and connection points.
• Tighten Fasteners: Periodically re-check and tighten all bolts and nuts to ensure they remain secure. Vibration during operation can cause fasteners to loosen.
• Clean: After each use, especially in corrosive environments (e.g., salt-treated roads), clean the mount to remove dirt, snow, ice, and salt residue. A mild detergent and water are usually sufficient.
• Lubrication: While the mount itself has few moving parts requiring lubrication, ensure any pivot points on your plow's push tubes or quick-attach mechanism are properly lubricated as per the plow manufacturer's recommendations.
• Storage: When storing the plow mount for extended periods, clean it thoroughly and store it in a dry location to prevent rust and corrosion.

7. Troubleshooting

This section addresses common issues you might encounter with your KFI 105590 Winch Plow Mount.

• Mount Does Not Fit Vehicle:
  Solution: Double-check that the KFI 105590 mount is compatible with your specific ATV/UTV make, model, and year. Refer to the product's compatibility list. Ensure no existing vehicle components are obstructing the installation.
• Plow Does Not Raise/Lower Smoothly:
  Solution: Inspect the winch cable/strap for fraying or damage. Ensure the winch is functioning correctly. Check for obstructions or binding in the plow's lift mechanism or push tubes. Lubricate pivot points on the plow assembly.
• Loose Components After Operation:
  Solution: This is often due to vibration. Re-tighten all mounting hardware to the recommended torque specifications. Consider using thread-locking compound on critical fasteners if loosening persists (consult a professional).
• Excessive Noise or Vibration:
  Solution: Inspect all connections for tightness. Ensure the plow mount is securely fastened to the vehicle frame and the plow push tubes are firmly attached to the mount. Check for any contact between the mount and other vehicle components.

8. Specifications

9. Warranty and Support

For specific warranty information regarding your KFI 105590 Winch Plow Mount, please refer to the documentation provided with your purchase or visit the official KFI Products website. KFI Products offers customer support for product inquiries, technical assistance, and parts replacement.

While this product is eligible for 30-day easy returns through the retailer, any product-specific issues or warranty claims should be directed to KFI Products directly.

KFI Products Contact Information:
Please visit www.kfiproducts.com for contact details and further support resources.
