Primo Rechargeable Portable USB Water Bottle Pump Instruction Manual

1. Product Overview

The Primo Rechargeable Portable USB Water Bottle Pump is designed to provide convenient access to drinking water from 3 and 5-gallon water bottles. Its portable and rechargeable design makes it ideal for home, office, camping, and other outdoor activities.

• Charges with included USB cord and charging brick.
• Pre-charged, works right out of the box.
• Dishwasher safe removable probe and stainless steel spout.

Figure 1: Primo Portable Water Dispenser. This image shows the sleek black and white design of the dispenser with its stainless steel spout.

2. Setup Guide

1. Unpack Components: Carefully remove the water pump, stainless steel spout, silicone hose, and USB charging cable from the packaging.
2. Clean Components: Wash the silicone hose and stainless steel spout with warm, soapy water before first use. Rinse thoroughly.
3. Assemble Spout and Hose: Insert the silicone hose into the bottom inlet of the pump unit. Attach the stainless steel spout to the outlet on the front of the pump unit. Ensure both are securely fitted.
4. Install on Water Bottle: Remove the cap from your 3 or 5-gallon water bottle. Insert the silicone hose into the water bottle, ensuring it reaches the bottom for optimal water extraction. Place the pump unit securely on the neck of the water bottle.
5. Initial Charge: Although the unit comes pre-charged, it is recommended to fully charge it before first use for optimal battery life. Connect the USB charging cable to the pump and a power source. The indicator light will show charging status.

Figure 2: Setup of the dispenser on a 5-gallon water bottle. The image illustrates how the pump unit sits on top of the bottle with the hose extending into the water.

Figure 3: Charging the portable water dispenser. The image shows the USB charging port and the dispenser connected to a power adapter.

3. Operating Instructions

The Primo water pump is designed for simple, one-touch operation.

1. Dispensing Water: Place your cup or container under the stainless steel spout. Press the power button located on the top of the pump unit once. The pump will begin dispensing water.
2. Stopping Water Flow: To stop the water flow, press the power button again. The pump will cease operation.
3. Battery Indicator: A blue indicator light on the unit illuminates when dispensing water and may indicate charging status.

Figure 4: Dispensing water into a bottle. This image demonstrates the ease of filling various containers directly from the dispenser.

4. Maintenance

• Cleaning: Regularly clean the stainless steel spout and silicone hose. These parts are dishwasher safe. Ensure they are completely dry before reassembly.
• Battery Care: To prolong battery life, avoid completely draining the battery frequently. Charge the unit when the indicator light suggests low power.
• Storage: When not in use for extended periods, store the dispenser in a cool, dry place. Ensure it is clean and fully charged before storage.

5. Troubleshooting

6. Specifications

• Model Number: 601244
• Color: Black and Stainless Steel
• Material: Stainless Steel, Plastic
• Capacity: Designed for 3 and 5 Gallon Bottles (dispenses up to 25 gallons per charge)
• Product Dimensions: 3.6"D x 11.8"W x 4.2"H
• Weight: 1.1 Pounds (unit only)
• Power Source: Battery Powered (Rechargeable Lithium-Ion)
• Charging: USB (cable included)

7. Warranty and Support

Primo products are manufactured to high-quality standards. For warranty information or technical support, please refer to the contact details provided in your product packaging or visit the official Primo Water website. Keep your purchase receipt for warranty claims.

For additional assistance, you may contact Primo Water Corporation directly.
