1. Introduction
Thank you for purchasing the QZT Pen-Type IC Voice Recorder and MP3 Player. This device is designed for discreet and high-quality audio recording, offering 8GB of internal storage for up to 96 hours of recordings. It also functions as an MP3 player. This manual provides essential information for setup, operation, maintenance, and troubleshooting to ensure optimal performance and longevity of your device.
2. Product Overview
The QZT Pen-Type IC Voice Recorder is designed to resemble a standard ballpoint pen, making it highly portable and discreet. It features a one-touch recording switch, an internal microphone, and a 3.5mm jack for earphones and USB connection.
2.1 Components
- Pen-Type Voice Recorder Unit
- USB Charging/Data Cable
- Earphones with Remote Control
- Ink Refills (for pen function)
2.2 Device Diagram
3. Setup
3.1 Charging the Device
Before first use, fully charge the device. Connect the included USB cable to the 3.5mm jack on the recorder and the other end to a computer's USB port or a USB wall adapter (not included). The indicator light will show charging status.
- During charging, the red indicator light will blink.
- Once fully charged, the blue indicator light will illuminate steadily.
- A full charge takes approximately 1 hour and provides about 16 hours of recording or playback time.
3.2 Understanding the Indicator Light
The device features a discreet indicator light located between the main body and the clip. To view it, gently rotate the clip approximately 45 degrees from the body. This light provides crucial feedback on the device's status (recording, charging, etc.).
4. Operating Instructions
4.1 Recording
- To start recording, press and hold the top button (ON/OFF switch) of the pen.
- The red indicator light will illuminate, then quickly blink for about 5 seconds, and finally turn off. This indicates that recording has started. You can release the button once the light starts blinking.
- To stop recording and save the file, press and hold the top button again.
- The red indicator light will blink rapidly several times and then turn off. This confirms that the recording has stopped and the file is saved.
- Recordings are saved as WAV files with a timestamp filename.
Note: The indicator light behavior differs slightly between starting and stopping recording. Pay attention to the blinking pattern to confirm the device's status.
4.2 Playback
Playback can be done using the included earphones with remote control or by connecting the device to a computer.
Using Earphones:
- Ensure the device is off.
- Firmly insert the earphones' 3.5mm jack into the device's port until it clicks.
- The remote control on the earphones allows you to play, pause, skip tracks, fast forward, rewind, and delete files. Refer to the remote's markings for specific functions.
- The device can play both recorded WAV files and MP3 music files.
Using a Computer:
Connect the device to a computer as described in section 4.3. The recorded WAV files can be played directly from the device's storage using your computer's media player.
4.3 Connecting to a Computer
- Ensure the device is off.
- Connect the USB cable's standard USB end to your computer and the 3.5mm end firmly into the recorder's port.
- Wait approximately 5 seconds. Your computer should recognize the device as a removable disk.
- The red indicator light will illuminate, then blink, and finally the blue light will stay on, indicating a successful connection.
- You can now access the device's internal storage to transfer, copy, or delete recorded files (WAV format) or MP3 files.
- Important: While connected to a computer, the ON/OFF switch on the pen is inactive. To disconnect, safely eject the device from your computer first, then remove the USB cable. Removing the cable abruptly while data is being accessed may corrupt files.
5. Maintenance
- Keep the device clean and dry. Avoid exposure to extreme temperatures, dust, or moisture.
- Use only the provided USB cable for charging and data transfer.
- When not in use for extended periods, charge the device at least once every three months to maintain battery health.
- Replace ink refills as needed for the pen function.
6. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Device does not turn on or record. | Low battery; incorrect operation of ON/OFF switch. | Charge the device fully. Ensure the ON/OFF switch is pressed and held correctly as per section 4.1. |
| Cannot hear playback through earphones. | Earphones not fully inserted; volume too low; corrupted file. | Ensure earphones are firmly inserted. Adjust volume using the remote. Try playing the file on a computer to check if it's corrupted. |
| Computer does not recognize the device. | Loose USB connection; faulty USB cable/port; device not in correct mode. | Ensure the USB cable is firmly connected to both the device and the computer. Try a different USB port or cable. Ensure the device is off before connecting to the PC. |
| Poor recording quality. | Device too far from sound source; excessive background noise. | Place the device closer to the sound source. Record in a quieter environment. |
| Indicator light behavior is confusing. | Misinterpretation of light patterns. | Refer to section 3.2 and 4.1 for detailed descriptions of indicator light patterns for charging, recording start, and recording stop. Remember to rotate the clip to view the light. |
7. Specifications
- Brand: QZT
- Model: B07BF8HK2J
- Storage Capacity: 8 GB
- Recording Time: Up to 96 hours (approximate)
- Battery Life (Recording/Playback): Approximately 16 hours on a full charge
- Charging Time: Approximately 1 hour
- Audio Format: WAV (recording), MP3 (playback)
- Headphone Jack: 3.5 mm
- Connectivity: USB (via included cable)
- Compatible Devices: PC
8. Warranty and Support
For warranty information or technical support, please refer to the documentation included with your purchase or contact the seller directly through the platform where the product was purchased. Keep your purchase receipt as proof of purchase.
