1. About the Product
The SYLVANIA LEDlescent™ T8 Ballast-Free lamp is an energy-efficient alternative designed to replace traditional fluorescent T8/T12 lamps. This LED lamp operates by bypassing the existing ballast, providing instant light and uniform light distribution without mercury. It is engineered to operate directly on 120-277V, which helps minimize labor and recycling costs. These lamps are suitable for use with occupancy and vacancy sensors for enhanced energy savings.
Key Features:
- Optimized glass optics for superior light quality.
- Instant-on with full light output and stable lamp-to-lamp color, requiring no warm-up time.
- Suitable for dry and damp locations (avoid direct contact with water), open and enclosed fixtures, and approved for use in tube guards.
- Patented built-in safety circuit prevents current flow when only one end is engaged, eliminating potential shock hazards and electrical arcing.
- Compatible with both shunted and non-shunted sockets, removing the need for socket changes.
2. Important Safety Information
Read all instructions before installation. Failure to follow these instructions may result in electric shock, fire, or other hazards.
- This LEDlescent T8 lamp is UL Classified as a luminaire conversion retrofit kit under UL standard 1598C. This classification ensures that the UL rating of the existing fixture is not voided when electrically modified for installation, provided the installer follows the installation instructions included with the lamps.
- Ensure power is disconnected at the circuit breaker before installation or maintenance.
- Do not use with dimmers. This product is non-dimmable.
- Do not expose to direct water contact. Suitable for damp locations only.
- Consult a qualified electrician if you are unsure about the installation process.
3. Setup and Installation
This SYLVANIA LEDlescent™ T8 lamp is designed for ballast-free operation, meaning the existing fluorescent ballast must be bypassed or removed. The lamp operates directly on 120-277V.
Installation Steps:
- Disconnect Power: Turn off power to the fixture at the circuit breaker before beginning any installation.
- Remove Existing Lamps: Carefully remove the existing fluorescent T8/T12 lamps from the fixture.
- Bypass/Remove Ballast: The existing fluorescent ballast must be bypassed or removed. This typically involves cutting the wires leading to the ballast and directly wiring the lamp holders to the main power supply (120-277V). Refer to the detailed wiring diagram provided with the product packaging for specific instructions.
- Install LED Lamp: Insert the SYLVANIA LEDlescent™ T8 lamp into the lamp holders. Ensure both ends are securely seated.
- Restore Power: Once the installation is complete and all connections are secure, restore power at the circuit breaker.
Note: The installer must follow the specific installation instructions included with the lamps to ensure the modified fixture retains its UL rating.
4. Operating Instructions
Once properly installed and power is restored, the Sylvania T8 LEDlescent LED Linear Light Bulb will provide instant illumination. There is no warm-up time required, and the light output is immediate and consistent.
- Instant On: The bulb provides full brightness immediately upon switching on.
- Sensor Compatibility: These lamps can be used effectively with occupancy and vacancy sensors to further enhance energy savings by ensuring lights are only on when needed.
- Non-Dimmable: This specific model is non-dimmable. Do not attempt to use it with dimmer switches, as this may damage the bulb or the dimmer.
Understanding Color Temperature:
The 3000K Warm White color temperature of this bulb provides a soft, inviting light suitable for various indoor environments. The following video provides a general guide to understanding different color temperatures (CCT).
Video: Color Temperature Guide (CCT) by LEDVANCE LLC. This video illustrates the visual differences between various color temperatures, from warm white to daylight, helping users understand light characteristics.
5. Maintenance
The Sylvania T8 LEDlescent LED Linear Light Bulb is designed for long-term, low-maintenance operation.
- Cleaning: Ensure power is off before cleaning. Wipe the bulb gently with a soft, dry cloth. Do not use liquid cleaners or abrasive materials.
- Mercury-Free: These LED lamps contain no mercury, simplifying disposal and minimizing environmental impact compared to traditional fluorescent lamps.
- Longevity: LED technology provides a significantly longer lifespan than traditional bulbs, reducing the frequency of replacements.
6. Troubleshooting
If you experience issues with your Sylvania T8 LEDlescent LED Linear Light Bulb, consider the following common troubleshooting steps:
- No Light:
- Check if the power supply to the fixture is active.
- Ensure the bulb is correctly seated in the lamp holders.
- Verify that the ballast has been properly bypassed or removed, and the fixture is wired for direct 120-277V operation.
- Confirm the circuit breaker has not tripped.
- Flickering Light:
- Ensure stable voltage supply.
- Confirm the bulb is not being used with a dimmer switch, as this product is non-dimmable.
- Inconsistent Light Output:
- Check for loose connections in the wiring.
If problems persist after attempting these steps, please contact customer support.
7. Specifications
| Brand | LEDVANCE (SYLVANIA) |
| Model Name | SYLVANIA LEDlescent™ Non-Dimmable Ballast-Free T8 |
| Item Model Number | 75013 |
| Light Type | LED |
| Bulb Shape Size | T8 |
| Bulb Base | G13 |
| Wattage | 9 Watts |
| Incandescent Equivalent Wattage | 60 Watts |
| Brightness | 1100 Lumens |
| Light Color | Warm White |
| Color Temperature | 3000 Kelvin |
| Color Rendering Index (CRI) | 82 |
| Voltage | 120-277 Volts |
| Accepted Voltage Frequency | 100 to 120 Volts and 60 Hertz (for specific regions) |
| Finish | Frosted |
| Material | Glass |
| Indoor/Outdoor Usage | Indoor (Suitable for dry and damp locations) |
| Control Method | App (Note: This specification might refer to general LEDVANCE products; this specific bulb is non-dimmable and does not have smart features.) |
| Specification Met | UL Listed (UL 1598C Classified) |
| Product Dimensions | 0.94"W x 0.94"H (Diameter x Length) |
| Item Weight | 8.63 pounds (Note: This weight seems high for a single bulb and might refer to a package weight.) |
8. Warranty and Support
For warranty information, customer questions, or support regarding your Sylvania T8 LEDlescent LED Linear Light Bulb, please contact LEDVANCE customer service.
Contact Information:
- Phone (US & Canadian Customers): 1-800-LIGHTBULB (1-800-544-4828)
- Email: lightbulb@ledvance.com
Please have your product model number (75013) and purchase details ready when contacting support.
