1. Product Overview
The Vinotemp EL-300COMM is a 188-bottle capacity wine cooler refrigerator designed for both built-in and freestanding installation. It features a glass door, touchscreen temperature control, and patented VinBo Racks for optimal wine storage and display.
Figure 1: Front view of the Vinotemp EL-300COMM 188-Bottle Wine Cooler Refrigerator.
2. Safety Information
Please read all safety instructions before operating the appliance. Ensure proper grounding and ventilation. Keep the appliance away from heat sources and direct sunlight. The unit is equipped with a safety lock to prevent unauthorized access.
Video 1: Demonstration on how to use the safety lock feature located at the bottom of the wine cooler.
3. Installation
The Vinotemp EL-300COMM can be installed as a built-in unit or used freestanding. Its front exhaust design allows for flexible placement. Ensure adequate clearance for ventilation.
3.1 Dimensions
- Width: 29.5 inches
- Depth: 27.1 inches
- Height: 74 inches
- Caster Size: 1.875 inches (height adjustable by 0.75 inches up or down)
Figure 2: Product dimensions for installation planning.
4. Operation
4.1 Temperature Control
The unit features an external touchscreen control panel for adjusting the temperature. The temperature range is 41°F to 64°F (5°C to 18°C). Use the '+' and '-' buttons to set your desired temperature.
Figure 3: Touchscreen control panel for temperature adjustment and lighting.
4.2 Interior Lighting
The wine cooler is equipped with soft blue LED lighting and a patented Backlit™ panel offering three color options: Heliotrope, Amber, and Vinotemp BioBlu™. These can be controlled via the touchscreen panel to enhance the display of your wine collection.
Figure 4: Interior view showcasing blue LED lighting and wine bottles.
Figure 5: Interior view showcasing amber LED lighting and wine bottles.
4.3 VinBo Racks and Shelf Adjustment
The unit features VinBo Racks designed to cradle bottles securely and slide forward for easy access. These racks are adjustable to accommodate various bottle sizes and quantities. The cooler also includes bulk storage at the bottom for oddly shaped bottles.
Figure 6: Detail of the VinBo Racks holding wine bottles.
Video 2: Instructions on how to remove and adjust the shelves within the wine cooler.
Video 3: Guidance on how to properly use and position the shelves for optimal storage.
Video 4: Overview of a similar wine fridge model, demonstrating the sliding rail shelves and capacity.
5. Maintenance
5.1 Cleaning
Regularly clean the interior and exterior surfaces with a soft cloth and mild detergent. Avoid abrasive cleaners. Ensure the unit is unplugged before cleaning.
5.2 Defrosting
This wine cooler features an automatic defrost system, minimizing the need for manual defrosting.
6. Specifications
| Feature | Specification |
|---|---|
| Brand | Vinotemp |
| Model Number | EL-300COMM |
| Capacity | 188 Bottles (750 Milliliters) |
| Item Weight | 282 Pounds |
| Product Dimensions | 27.1"D x 29.5"W x 74"H |
| Installation Type | Built-In, Free Standing |
| Annual Energy Consumption | 130 Kilowatt Hours |
| Special Feature | Digital Temperature Control |
| Color | Heliotrope (unit color, not lighting) |
| Voltage | 115 Volts |
| Racks | 15 Sliding shelves |
| Defrost System | Automatic |
| Door Hinges | Right |
| Door Material Type | Glass |
| Certification | ETL |
| Included Components | Wine Tools, Wine Chillers |
7. Customer Support
For any inquiries or assistance, please refer to the manufacturer's official support channels or contact your retailer.
