Introduction
This manual provides essential information for the installation, operation, and maintenance of your Havells MAX Water Purifier. Please read it thoroughly before using the appliance to ensure safe and efficient operation. The Havells MAX Water Purifier is designed to provide safe and healthy drinking water through advanced purification technologies.
Key Features and Purification Process
The Havells MAX Water Purifier incorporates a powerful 7-stage purification process to deliver clean and healthy water. This system includes:
- Absolute Safety through RO and UV Purification: Water undergoes purification through both the Reverse Osmosis (RO) membrane and Ultraviolet (UV) light, ensuring the removal of dissolved impurities, bacteria, and viruses.
- Minerals Cartridge: This cartridge corrects the pH level of the purified water and reintroduces a full spectrum of natural minerals and trace elements, enhancing taste and promoting healthier water.
- Revitalizer: The revitalizer restructures water molecules, making the water biologically active. This improves hydration and mineral absorption by the body.
- iProtect Purification Monitoring: The system continuously monitors the purification process to ensure consistent delivery of safe water.
- Electrical Protection System: Advanced electronics protect the purifier from electrical damage by ensuring stable operation within a voltage range of 170 V - 330 V. Power is automatically cut off if voltage exceeds 330 V or drops below 170 V.
Figure 1: Detailed diagram illustrating the 7-stage purification process of the Havells MAX Water Purifier. This includes Sediment Cartridge, Activated Carbon Cartridge, Reverse Osmosis Membrane, Germicidal UV, Mineralz Cartridge, Silver Impregnated Taste Enhancer, and Revitalizer Cartridge, ensuring safe and healthy drinking water.
Figure 2: Front view of the Havells MAX Water Purifier, showcasing its transparent tank and dispensing faucet. The unit features a white body with green accents.
Setup and Installation
The Havells MAX Water Purifier offers flexible mounting options to suit various kitchen layouts:
- Corner Mounting: Its patented design allows for efficient placement in kitchen corners, optimizing space.
- Straight Wall Mounting: Can be securely mounted on a flat wall.
- Table Top Placement: Suitable for placement on a countertop or table.
Ensure the installation is performed by a qualified technician to guarantee proper functioning and adherence to safety standards.
Figure 3: Illustration of the dual mounting options for the Havells MAX Water Purifier, demonstrating its versatility for corner or straight wall installation.
Operating Instructions
Dispensing Water
To dispense purified water, place a glass or container under the faucet and gently push the lever. The unique soft-touch, zero-splash faucet ensures a smooth and hygienic flow of water.
Indicator Lights
The purifier is equipped with smart indicators to keep you informed about its status:
- Purification Process Indicator: Illuminates when the purification process is active.
- Power & Error Indicator: Indicates power status and alerts to any system errors.
- Tank Full Indicator: Lights up when the 7-liter transparent storage tank is full.
Figure 4: Close-up view of the control panel with indicators for purification process, power/error, and tank full status.
Maintenance
Regular maintenance is crucial for the longevity and optimal performance of your water purifier. The Havells MAX features a removable tank for easy periodic cleaning. Refer to the service schedule for filter replacement and professional servicing.
Note on Water Wastage: For every liter of water purified, approximately 650 ml of water is discharged. This discharged water can be collected and reused for household purposes such as cleaning utensils or washing clothes, promoting water conservation.
Troubleshooting
If the Power & Error indicator blinks continuously, it signifies a system error, such as a UV lamp malfunction, SV (Solenoid Valve) issue, or pump failure. In such cases, the purification process will stop. Please contact customer support for assistance.
Specifications
| Feature | Detail |
|---|---|
| Brand | Havells |
| Model Name | Max |
| Item Model Number | GHWRPMB015 |
| Special Feature | RO, UV |
| Product Dimensions | 15L x 10.8W x 19.3H Centimeters |
| Installation Type | Countertop (also supports Corner and Straight Wall Mounting) |
| Power Source | Corded Electric |
| Item Weight | 8.6 kg |
| Supported Water TDS Level Maximum (PPM) | 2000 |
| Capacity | 7 Liters (Transparent Tank) |
| Material | Plastic |
| Included Components | 1N Water Purifier and 1N Installation Kit |
Warranty and Support
Your Havells MAX Water Purifier comes with a manufacturer's warranty. For detailed information regarding warranty terms, service requests, or technical support, please refer to the warranty card included with your product or visit the official Havells website. The built-in Electrical Protection System helps ensure the longevity of your appliance by safeguarding against voltage fluctuations.
Official Product Overview
Video 1: An official overview of the Havells MAX Water Purifier, demonstrating its features, purification process, and installation flexibility. This video provides a visual guide to understanding the product's benefits and operation.
