1. Introduction
This manual provides essential instructions for the safe installation, operation, and maintenance of your Utilitech LED 90W High Ceiling Recessed Retrofit Downlight. Please read this manual thoroughly before installation and retain it for future reference.
The Utilitech LED Downlight is designed for high ceiling applications, offering efficient and warm white illumination. It is a retrofit solution, suitable for replacing existing recessed lighting fixtures.
2. Safety Information
WARNING: Risk of electric shock. Disconnect power at the fuse or circuit breaker before installation or servicing.
- Ensure the electrical rating of the fixture is compatible with your power supply (120 Volts).
- All wiring connections must be made in accordance with local and national electrical codes. If you are unsure about wiring, consult a qualified electrician.
- Do not install in areas with excessive moisture or extreme temperatures unless specified as suitable. This product is Wet Rated.
- Do not attempt to modify the fixture. Any modifications may void the warranty and create safety hazards.
- Handle the fixture with care to avoid damage.
This product is designed for indoor use in suitable recessed housings.
3. Package Contents
Verify that all components are present before beginning installation:
- Utilitech LED Recessed Retrofit Downlight (Model DNL90905650-27)
- Instruction Manual (This document)
Figure 1: Product packaging for the Utilitech LED Recessed Retrofit Downlight. The packaging highlights key features such as 2700K Soft White light, 90W replacement equivalent, 1200 lumens output, 35,000 hours lifespan, dimmable functionality, wet rating, and compatibility with 5 or 6 inch recessed housings.
4. Specifications
| Feature | Detail |
|---|---|
| Brand | Utilitech |
| Model Number | DNL90905650-27 |
| Light Output (Lumens) | 1200 Lumens |
| Wattage | 20 Watts |
| Wattage Equivalent | 90W Incandescent |
| Lumens per Watt (Efficacy) | 60 |
| Color Temperature (CCT) | 2700K (Warm White) |
| Color Rendering Index (CRI) | 90 |
| Voltage | 120 Volts |
| Bulb Type | LED |
| Estimated Lifespan | 35,000 hours |
| Dimmable | Yes |
| Wet Rated | Yes |
| Compatible Housing Size | 5 or 6 inch |
| Product Dimensions | 4 x 8.5 x 4.2 inches |
| Item Weight | 13.6 ounces |
| Material | Copper |
Figure 2: Lighting facts label detailing the performance specifications of the Utilitech LED Downlight, including light output, wattage, efficacy, color accuracy (CRI), and correlated color temperature (CCT) of 2700K Warm White.
5. Setup and Installation
This downlight is designed for retrofit installation into existing 5-inch or 6-inch recessed housings.
- Turn Off Power: Before starting any electrical work, ensure the power to the fixture location is turned off at the circuit breaker or fuse box. Verify power is off using a voltage tester.
- Remove Existing Trim and Bulb: Carefully remove the existing recessed trim and light bulb from the housing.
- Connect Adapter: Screw the E26 (standard base) adapter from the new LED downlight into the existing socket of the recessed housing.
- Connect Downlight: Connect the electrical connector from the downlight to the adapter. Ensure a secure connection.
- Insert Downlight: Gently push the LED downlight into the recessed housing until the spring clips engage and hold the fixture securely in place. Ensure the downlight is flush with the ceiling.
- Restore Power: Once the downlight is securely installed, restore power at the circuit breaker.
Note: For dimming functionality, ensure you are using a compatible LED dimmer switch. Refer to the dimmer manufacturer's instructions for compatibility and installation.
6. Operating Instructions
Operating the Utilitech LED Recessed Retrofit Downlight is straightforward:
- On/Off: Use the standard wall switch connected to the fixture to turn the light on or off.
- Dimming: If connected to a compatible dimmer switch, adjust the dimmer control to achieve the desired light level.
The downlight provides a consistent 2700K Warm White light output at 1200 lumens when fully on.
7. Maintenance
The Utilitech LED Downlight is designed for long-term, maintenance-free operation. However, occasional cleaning may be necessary.
- Cleaning: Ensure power is off before cleaning. Use a soft, dry, or slightly damp cloth to wipe the surface of the downlight. Do not use abrasive cleaners, solvents, or cleaners containing alcohol, as these can damage the finish or electrical components.
- No User-Serviceable Parts: There are no user-serviceable parts inside this LED downlight. Do not attempt to open or repair the unit.
8. Troubleshooting
If you encounter issues with your downlight, refer to the following troubleshooting guide:
- Light Does Not Turn On:
- Check if the power switch is in the "ON" position.
- Verify that the circuit breaker or fuse for the fixture is not tripped or blown.
- Ensure all electrical connections (E26 adapter and downlight connector) are secure.
- Confirm that the power supply voltage is 120 Volts.
- Light Flickers or Dims Incorrectly:
- Ensure you are using an LED-compatible dimmer switch. Incompatible dimmers can cause flickering or poor dimming performance.
- Check all electrical connections for looseness.
- If using multiple downlights on one dimmer, ensure the total wattage does not exceed the dimmer's maximum load.
- Light Output is Low:
- If connected to a dimmer, ensure the dimmer is set to its maximum brightness level.
- Verify the power supply voltage is stable.
If these steps do not resolve the issue, contact customer support.
9. Warranty and Support
Utilitech products are manufactured to high-quality standards. For specific warranty information, please refer to the documentation included with your purchase or visit the official Utilitech website.
For technical assistance, replacement parts, or customer service inquiries, please contact Utilitech customer support through their official channels. Have your model number (DNL90905650-27) ready when contacting support.
