1. Introduction
Thank you for choosing the HAVA Mini Recessed Motion Detector. This device is designed to provide automatic lighting control for 12V and 24V LED systems, offering convenience and energy efficiency. It features a passive infrared (PIR) sensor and an adjustable twilight sensor for versatile operation.
Key features include:
- Mini recessed design with a compact sensor.
- Compatible with 12V DC (max 60W) and 24V DC (max 120W) LED loads.
- Minimum load requirement of only 1W.
- Adjustable detection range from 3 to 6 meters with a 360° detection angle.
- Integrated twilight sensor (LUX) adjustable from 10 to 2000 Lux.
- Adjustable switching time from 5 seconds to 8 minutes.
- IP20 protection rating.
2. Safety Information
Please read these safety instructions carefully before installation and use. Failure to follow these instructions may result in electric shock, fire, or other hazards.
- Electrical Safety: Installation should only be performed by a qualified electrician or competent person in accordance with local electrical codes and regulations.
- Power Disconnection: Always disconnect power to the circuit at the main fuse box or circuit breaker before performing any installation, maintenance, or troubleshooting.
- Voltage Compatibility: Ensure the power supply voltage (12V DC or 24V DC) matches the requirements of the motion detector and the connected LED load.
- Load Capacity: Do not exceed the maximum load capacity of 60W for 12V DC or 120W for 24V DC.
- Environment: This device has an IP20 rating, meaning it is protected against solid objects larger than 12.5mm but has no protection against water. Do not install in wet or damp locations.
- Children: Keep the device out of reach of children.
3. Product Overview
The HAVA Mini Recessed Motion Detector consists of a compact control unit and a separate, small PIR sensor designed for recessed mounting.
Figure 3.1: HAVA Mini Recessed Motion Detector control unit with DIP switches and connected PIR sensor. This image displays the main control unit of the HAVA Mini Recessed Motion Detector, featuring adjustable DIP switches for settings, and its connected passive infrared (PIR) sensor.
4. Specifications
| Feature | Specification |
|---|---|
| Brand | HAVA |
| Model | 12V-24V |
| Power Source | Wired Electric |
| Input Voltage | 12V DC / 24V DC |
| Max Load (12V DC) | 60W |
| Max Load (24V DC) | 120W |
| Min Load | 1W |
| Sensor Type | Passive Infrared (PIR) |
| Detection Angle | 360° |
| Detection Range | 3 - 6 meters (adjustable) |
| Twilight Sensor (LUX) | 10 - 2000 Lux (adjustable) |
| Switching Time | 5 seconds - 8 minutes (adjustable) |
| Protection Rating | IP20 |
| Control Unit Dimensions (L x W x H) | 55 x 38 x 26 mm |
| Sensor Dimensions (Ø x H) | Ø 15 x 25 mm |
| Sensor Cable Length | 16 cm |
| Connection Cable Length | 16 cm |
| Mounting Type | Recessed (sensor Ø 15 mm) |
| Item Weight | 60 g |
Figure 4.1: Dimensional drawing of HAVA Mini Recessed Motion Detector components. This technical drawing provides precise measurements for the control unit and the recessed sensor, including cable lengths, essential for installation planning.
5. Installation (Setup)
Careful installation is crucial for optimal performance and safety. Ensure all safety precautions from Section 2 are followed.
5.1 Pre-installation Checklist
- Verify that the power supply is 12V DC or 24V DC.
- Ensure the total wattage of the connected LED load does not exceed the detector's maximum capacity (60W for 12V, 120W for 24V).
- Choose a suitable location for the recessed sensor (Ø 15 mm hole required) that provides the desired detection coverage and is free from obstructions. Avoid placing near heat sources or direct sunlight, which can cause false triggers.
- Ensure adequate space for the control unit (55 x 38 x 26 mm) to be hidden or mounted securely.
5.2 Wiring Instructions
Always disconnect power before wiring.
- Identify the input wires for your 12V/24V DC power supply and the output wires for your LED load.
- Connect the input wires from your DC power supply to the corresponding input terminals on the control unit. Typically, this involves positive (+) and negative (-) connections.
- Connect the output wires from the control unit to your LED lighting fixture. Ensure correct polarity if required by your LED lights.
- The PIR sensor is pre-connected to the control unit via a 16 cm cable. Ensure this connection is secure.
Figure 5.1: Wiring diagram for HAVA Mini Recessed Motion Detector. This diagram illustrates the electrical connections for the HAVA Mini Recessed Motion Detector, showing input and output wiring for 12V or 24V DC power and LED load.
5.3 Mounting the Sensor
- Drill a hole of Ø 15 mm at the chosen installation location for the sensor.
- Carefully insert the sensor into the drilled hole until it sits flush with the surface.
- Position the control unit in a secure, hidden location, ensuring the sensor cable is not strained.
6. Operation and Settings
The HAVA Mini Recessed Motion Detector features adjustable settings for detection range, twilight sensitivity (LUX), and switching time (TIME) using DIP switches located on the control unit.
6.1 Adjusting Detection Range
The detection range can be adjusted between 3 and 6 meters. Refer to the DIP switch settings on the control unit (Figure 3.1) for specific configurations. Experiment with settings to find the optimal range for your environment.
Figure 6.1: Motion detection range illustration. An icon representing the motion detection capability of the sensor, indicating its ability to detect movement within its specified range.
6.2 Adjusting Twilight Sensitivity (LUX)
The LUX setting determines the ambient light level at which the motion detector will activate the connected lights. It can be adjusted from less than 10 Lux (darkness) up to 2000 Lux (daylight). This allows for day/night or night-only operation.
- < 10 Lux: The detector will only activate in very dark conditions.
- 2000 Lux: The detector will activate regardless of ambient light (day and night operation).
Refer to the DIP switch settings on the control unit (Figure 3.1) for specific LUX configurations.
Figure 6.2: Day/Night operation setting icon. An icon symbolizing the adjustable twilight sensor (LUX setting) for day, night, or combined operation modes.
6.3 Adjusting Switching Time (TIME)
The TIME setting determines how long the connected lights remain on after motion is no longer detected. The adjustable options are 5 seconds, 30 seconds, 1 minute, 3 minutes, 5 minutes, and 8 minutes.
Refer to the DIP switch settings on the control unit (Figure 3.1) for specific TIME configurations.
7. Maintenance
The HAVA Mini Recessed Motion Detector requires minimal maintenance.
- Cleaning: Gently wipe the sensor lens and control unit with a soft, dry cloth. Do not use abrasive cleaners or solvents.
- Inspection: Periodically check the wiring for any signs of damage or loose connections. Ensure the sensor is free from obstructions.
- Environment: Ensure the operating environment remains within the specified IP20 rating (dry, indoor use).
8. Troubleshooting
If you experience issues with your motion detector, please refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Lights do not turn on with motion. | No power; incorrect wiring; LUX setting too high; sensor obstructed; faulty LED load. | Check power supply; verify wiring (refer to Figure 5.1); adjust LUX setting to a lower value or 2000 Lux for testing; clear obstructions from sensor; test LED load with direct power. |
| Lights stay on continuously. | Constant motion in detection area; TIME setting too long; faulty unit. | Ensure no continuous motion; reduce TIME setting; if problem persists, unit may be faulty. |
| Lights turn on too frequently or falsely. | Sensor too sensitive; detection range too wide; heat sources or air currents in detection area. | Adjust detection range to a lower setting; reposition sensor away from heat vents, windows, or moving objects; adjust LUX setting if ambient light is causing issues. |
| Lights turn off too quickly. | TIME setting too short. | Increase TIME setting. |
9. Warranty and Support
HAVA products are manufactured to high-quality standards. For information regarding warranty terms and conditions, please refer to the documentation provided at the time of purchase or contact your retailer.
If you encounter any issues that cannot be resolved using the troubleshooting guide, please contact HAVA customer support or your product supplier for assistance. Please have your product model (12V-24V) and purchase details ready when contacting support.
