BEMIS Renew Plus Bidet Cleansing Spa with Night Light - Round White User Manual

Introduction

This manual provides comprehensive instructions for the installation, operation, and maintenance of your BEMIS Renew Plus Bidet Cleansing Spa. Designed for superior hygiene and comfort, this bidet seat offers advanced features for a refreshing experience.

Figure 1: BEMIS Renew Plus Bidet Cleansing Spa (Top View)

Safety Information

WARNING: To reduce the risk of burns, electrocution, fire, or injury to persons:

• Ensure the bidet is connected to a GFCI (Ground Fault Circuit Interrupter) protected outlet.
• Do not immerse the electrical components in water or other liquids.
• Unplug the bidet from the outlet before cleaning or servicing.
• Do not allow children or individuals with reduced physical, sensory, or mental capabilities to operate the bidet without supervision.
• Use this product only for its intended use as described in this manual.

Package Contents

Before beginning installation, verify that all components are present:

• BEMIS Renew Plus Bidet Cleansing Spa
• Remote Control with Magnetic Holder
• 4 AAA Batteries
• Deodorizing Cartridge
• Installation Hardware (2 bolts, 2 hinge brackets, 2 cone washers, 2 flat washers, 2 nuts, 1 seat bracket)
• Bidet Hose
• 7/8-inch T-Valve
• 4-foot Power Cord (attached to unit)
• Tightening Tool (optional for installation)

Figure 2: Underside View of Bidet Seat

Setup and Installation

Follow these steps for proper installation of your bidet seat. It is recommended to watch the installation video for visual guidance.

1. Prepare the Toilet: Turn off the water supply to the toilet and drain the tank by holding down the flush handle until empty. Place a container under the connecting hose to catch any residual water.
2. Remove Existing Seat: Detach the existing toilet seat and lid.
3. Install T-Valve: Disconnect the existing water supply line from the toilet tank's water supply fitting. Secure the 7/8-inch T-valve to the toilet tank water supply fitting. Ensure the T-valve is installed at the bottom of the toilet tank, not at the wall.
4. Connect Water Supply Line: Connect the water supply line coming from the wall to the bottom of the T-valve.
5. Install Seat Bracket: Place the adjustable seat bracket over the toilet mounting holes. Insert the metal hinge brackets (flat side down) into the large openings of the seat bracket.
6. Insert Bolts: Insert the bolts through the hinge brackets and mounting holes. The square bolt head should be even with the sides of the metal hinge brackets.
7. Secure Bolts: From underneath the toilet bowl, slide the rubber cone washer, flat washer, and nut onto the bolts. Lightly tighten to keep the seat bracket in place.
8. Attach Bidet Seat: Set the bidet seat on the bowl in front of the mounted bracket. Push the seat backward onto the bracket until it clicks into place.
9. Adjust Alignment: Adjust the seat forward and backward for proper alignment with the toilet bowl.
10. Final Tightening: Either finger-tighten the nuts from below or use the provided tightening tool to fully secure the seat to the bowl.
11. Connect Bidet Hose: Attach the bidet hose to the T-valve. If using an optional filter (sold separately), position it onto the T-valve first, then attach the bidet hose to the other end of the filter. If not using a filter, attach the bidet hose directly to the T-valve.
12. Connect to Bidet Seat: Attach the other end of the bidet hose to the connection on the bidet seat, ensuring it is firmly secured.
13. Install Deodorizing Cartridge (Renew Plus only): For the Renew Plus seat, install the deodorizing cartridge into the designated slot on the side of the seat.
14. Restore Water Supply: Slowly turn on the water supply to the toilet. Check all connections for leaks immediately and again after 5 minutes.
15. Connect Power: Plug the power cord into a GFCI protected electrical outlet.

Figure 3: Precision Seat Fit for proper alignment.

Operating Instructions

Your BEMIS Renew Plus Bidet Cleansing Spa offers a range of features for personalized comfort and hygiene. All functions are controlled via the intuitive touch remote control.

Remote Control Functions:

Figure 4: Remote Control for BEMIS Renew Plus Bidet.

• Aerated Wash with Continuous Heated Water: Adjust water temperature and pressure for a comfortable and thorough clean.
• Stainless Steel Nozzle: Provides options for a soft wash (gentle clean) or intense wash (deeper cleaning).
• Pulsate Function: Automatically transitions from a soft to strong wash for enhanced cleaning.
• Oscillate Function: (Renew Plus exclusive) Provides a massaging forward and backward cleansing motion.
• Multi-Setting Warm Air Dryer: (Renew Plus exclusive) Features 5 temperature settings for efficient drying.
• Heated Seat: Offers 4 temperature settings for personalized warmth and comfort.
• iLumaLight Night Light: (Renew Plus exclusive) Blue LED night light provides soft illumination and automatically shuts off when bathroom lights are on.
• Automatic Deodorizer: (Renew Plus exclusive) Features a replaceable carbon filter to neutralize odors.
• User Presets: The remote allows for saving customized settings for two users for everyday convenience.
• Whisper Close: The seat and lid close slowly and quietly with a light tap, preventing slamming and pinched fingers.
• Quick Release: The seat and lid are easily removed for cleaning or replacement.
• Super Grip Bumpers: Prevent the seat from shifting on the toilet bowl, providing greater stability.

Figure 5: iLumaLight Night Light in operation.

Maintenance

• Cleaning: Unplug the bidet seat before cleaning. Use mild soap and water with a soft cloth. Avoid abrasive cleaners or harsh chemicals that could damage the surface. The quick-release feature allows for easy removal of the seat for thorough cleaning of the toilet bowl and seat.
• Deodorizer Cartridge Replacement: The automatic deodorizer uses a replaceable carbon filter. Replace the cartridge periodically as needed to maintain odor neutralization effectiveness. Refer to the deodorizer cartridge packaging for specific replacement intervals.
• Nozzle Cleaning: The stainless steel nozzle is self-cleaning. If manual cleaning is required, use a soft brush and mild soap.

Figure 6: Quick-release feature for easy cleaning.

Troubleshooting

If you encounter issues with your BEMIS Renew Plus Bidet Cleansing Spa, please review the following common troubleshooting tips:

• No Power: Ensure the power cord is securely plugged into a functional GFCI outlet. Check if the GFCI outlet has tripped and reset it if necessary.
• No Water Spray: Verify that the water supply valve to the toilet is fully open. Check that the bidet hose connections are secure and not kinked.
• Weak Water Pressure: Ensure the water supply valve is fully open. Check for any blockages in the nozzle or filter (if installed).
• Remote Control Not Responding: Check and replace the AAA batteries in the remote control. Ensure the remote is within range and not obstructed.
• Seat Not Heating: Verify the heated seat function is activated on the remote control and the temperature setting is appropriate.
• Deodorizer Not Working: Check if the deodorizing cartridge is correctly installed and replace it if it's old or depleted.

If problems persist after attempting these solutions, please contact customer support.

Specifications

Figure 7: Product Dimensions.

Figure 8: Round Toilet Measurement Guide.

Warranty and Support

Manufacturer Warranty: The manufacturer warranty covers US and Canada customer purchases. For specific details regarding your warranty coverage, please refer to the documentation included with your product or visit the official Bemis website.

Customer Support: For technical assistance, troubleshooting, or warranty claims, please contact Bemis customer service. Contact information can typically be found on the product packaging or the official Bemis website (RenewSeats.com).
