SLLEA 4-Pin DIN AC/DC Adapter User Manual

1. Introduction

This manual provides essential information for the safe and effective use of your SLLEA 4-Pin DIN AC/DC Adapter. Please read this manual thoroughly before using the product and retain it for future reference. This adapter is specifically designed for use with Memorex 52X 16X Ultra-Speed Combo Recorder CD-RW models 3202, 3244, and 32023244.

Note: This adapter is NOT compatible with Memorex CD-RW Drive models MRX523252AJEL-1 (32023234) or MRX523252AJI-2 (32023257).

2. Product Overview

The SLLEA 4-Pin DIN AC/DC Adapter is a reliable power supply unit designed to provide stable and efficient power to compatible Memorex CD-RW recorders. It converts standard AC wall power to the DC power required by your device.

Figure 2.1: SLLEA 4-Pin DIN AC/DC Adapter with attached cables.

Key Features:

• Cable Length: Total 7 feet for flexible placement.
• Input: 100 - 240 VAC 50/60Hz, suitable for worldwide voltage use.
• Safety: Equipped with Over Voltage Protection and Over Heat Protection for enhanced safety.

3. Safety Information

To ensure safe operation and prevent damage, please observe the following safety precautions:

• Compatibility: Always verify that the adapter's output voltage and connector tip match the requirements of your device before connecting. Incorrect voltage or tip can damage your equipment.
• Indoor Use Only: This adapter is designed for indoor use. Do not expose it to rain, moisture, or extreme temperatures.
• Ventilation: Ensure adequate ventilation around the adapter during operation. Do not cover it or place it in an enclosed space that could lead to overheating.
• Cable Care: Do not place heavy objects on the power cord. Avoid bending, twisting, or pulling the cord excessively.
• Disconnection: Always grasp the plug, not the cord, when disconnecting the adapter from the wall outlet or your device.
• Professional Service: Do not attempt to open or repair the adapter yourself. Servicing should only be performed by qualified personnel.
• Proposition 65 Warning: This product may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

Figure 3.1: The adapter features a Multi-Protection Safety System, including Static-Reducing, Over-Current, Drop, Over-Charging, Short-Circuit, and Over-Temperature Protection.

4. Setup

Follow these steps to set up your SLLEA 4-Pin DIN AC/DC Adapter:

1. Verify Compatibility: Before connecting, ensure that your Memorex CD-RW recorder requires a 4-Pin DIN connector and the specified voltage/current output of this adapter.
2. Connect to Device: Insert the 4-Pin DIN connector of the adapter firmly into the corresponding power input port on your Memorex CD-RW recorder.


   Figure 4.1: Close-up view of the 4-Pin DIN barrel connector, which must match your device's input port.

3. Connect to Power Outlet: Plug the AC power cord (included) into the adapter's AC input port, then plug the other end of the AC power cord into a standard 100-240V wall outlet.
4. Power On: Once connected, your device should receive power. Refer to your Memorex CD-RW recorder's manual for specific power-on procedures.

5. Operating Instructions

The SLLEA 4-Pin DIN AC/DC Adapter operates automatically once connected to a power source and a compatible device. It provides continuous power as long as it is plugged in.

• Ensure the adapter is placed in a well-ventilated area to prevent overheating.
• Do not use the adapter if the cables or casing appear damaged.
• Disconnect the adapter from the power outlet when not in use for extended periods.

6. Maintenance

Proper maintenance ensures the longevity and safe operation of your adapter:

• Cleaning: Disconnect the adapter from all power sources before cleaning. Use a soft, dry cloth to wipe the exterior. Do not use liquid cleaners or abrasive materials.
• Storage: When not in use, store the adapter in a cool, dry place, away from direct sunlight and extreme temperatures. Avoid tightly coiling the cables to prevent damage.
• Inspection: Periodically inspect the adapter and its cables for any signs of wear, cuts, or damage. If damage is found, discontinue use immediately and replace the adapter.

7. Troubleshooting

If you encounter issues with your adapter, refer to the following common problems and solutions:

• No Power to Device:
  • Ensure the adapter is securely plugged into a working wall outlet.
  • Verify that the 4-Pin DIN connector is fully inserted into your device's power port.
  • Check if the wall outlet is functional by plugging in another device.
  • Confirm that the adapter's specifications (voltage, amperage, tip type) match your device's requirements.
• Adapter Overheating:
  • Ensure the adapter is in a well-ventilated area and not covered.
  • Verify that the device connected is compatible and not drawing excessive power.
  • If overheating persists, discontinue use and contact support.
• Device Not Recognized/Functioning Incorrectly:
  • This adapter is a power supply only. If your device is not recognized or functioning incorrectly, the issue may lie with the device itself or its drivers, not the power adapter.

If these steps do not resolve the issue, please contact SLLEA customer support.

8. Specifications

9. Warranty and Support

Your SLLEA 4-Pin DIN AC/DC Adapter is backed by a return policy that allows for refund or replacement within 30 days of purchase. For any product-related inquiries, technical support, or warranty claims, please contact the manufacturer, SLLEA.

For the most up-to-date support information, please visit the official SLLEA store or contact their customer service directly.

Manufacturer: SLLEA

Return Policy: 30 days (Refund/Replacement)
