Beurer BF 185 Diagnostic Scales User Manual

Introduction

The Beurer BF 185 Diagnostic Scales are designed to provide comprehensive body analysis, including body weight, body fat, body water, muscle percentage, and bone mass. It also calculates your Active Metabolic Rate (AMR). This manual provides essential information for the safe and effective use of your diagnostic scales.

Figure 1: Beurer BF 185 Diagnostic Scales. This image shows the sleek black glass surface of the scale, with four metallic electrodes for body composition analysis. The blue backlit LCD display is visible, indicating various measurements such as weight and body composition percentages.

Safety Information

Please read this section carefully before using the device to ensure safe operation and to prevent injury or damage.

• Do not step on the scale with wet feet or if the surface is wet, as this may cause slipping.
• The scale is designed for personal use and is not intended for medical or commercial purposes.
• Keep batteries out of reach of children. If swallowed, seek immediate medical attention.
• Do not attempt to disassemble or repair the scale yourself. Contact authorized service personnel.
• Avoid strong impacts or dropping the scale, as it contains sensitive electronic components and a glass surface.
• Individuals with medical implants (e.g., pacemakers) should not use this scale, as the electrical current used for body analysis may interfere with the implant.

Setup

1. Battery Installation

Your Beurer BF 185 scales require 4 x 1.5 V AAA batteries (included). Ensure correct polarity when inserting the batteries.

1. Open the battery compartment cover on the underside of the scale.
2. Insert the 4 AAA batteries, observing the positive (+) and negative (-) markings.
3. Close the battery compartment cover securely.

2. Initial Placement

Place the scale on a firm, level surface. Uneven surfaces can affect measurement accuracy. Avoid placing it on carpets or soft flooring.

3. User Profile Setup

The scale has 10 user storage spaces to save personal data for accurate analysis. This data includes height, age, and activity level.

Figure 2: 10 User Memories for the Whole Family. This image illustrates the convenience of having multiple user profiles, showing a diverse family. An inset displays the scale's screen, highlighting the user, age, and height settings, indicating its suitability for multi-person use.

1. With the scale off, press the "SET" button.
2. Use the arrow buttons (▲/▼) to select a user memory space (P1-P10). Confirm with "SET".
3. Enter your gender, height, age, and activity level using the arrow buttons and confirming each with "SET".
4. The scale will save your profile.

Activity Levels: The scale offers 5 activity levels for precise AMR calculation. Choose the level that best describes your physical activity:

• Level 1: No physical activity.
• Level 2: Light physical activity (e.g., walking).
• Level 3: Moderate physical activity (e.g., regular exercise 1-2 times/week).
• Level 4: Active physical activity (e.g., regular exercise 3-4 times/week).
• Level 5: Very active physical activity (e.g., intense exercise daily).

Figure 3: Understanding Activity Levels. This image depicts an active individual, emphasizing the importance of selecting the correct activity level for accurate metabolic rate calculations. The scale uses this input to provide a more personalized analysis.

Operating Instructions

1. Taking a Measurement

The Beurer BF 185 features quick-start technology for immediate weight measurement. For full body analysis, ensure your feet are bare and make good contact with the electrodes.

1. Gently tap the scale with your foot to turn it on, or simply step on it.
2. Wait for "0.0 kg" to appear on the display.
3. Step onto the scale barefoot, ensuring your feet are positioned on the four metallic electrodes. Stand still.
4. The scale will first display your weight, then cycle through body fat, body water, muscle percentage, bone mass, and AMR.
5. The measurements will be saved to your selected user profile.

2. Active Metabolic Rate (AMR) Calculation

The AMR indicates the daily calorie requirement of your body when active. This is calculated based on your entered personal data (gender, age, height, activity level) and your measured body composition.

3. Automatic Shut-off

The scale will automatically turn off after a few seconds of inactivity to conserve battery life.

Maintenance

1. Cleaning

Clean the scale regularly to ensure hygiene and accurate readings.

• Wipe the surface with a damp cloth and a mild detergent if necessary.
• Do not use abrasive cleaning agents or immerse the scale in water.
• Ensure the scale is completely dry before storage or next use.

2. Battery Replacement

When the battery indicator appears on the display, replace all 4 AAA batteries simultaneously. Refer to the "Battery Installation" section under Setup.

3. Storage

Store the scale in a cool, dry place, away from direct sunlight and extreme temperatures.

Troubleshooting

Specifications

• Model: Beurer BF 185
• Item Model Number: 749.10
• Functions: Weight, Body Fat, Body Water, Muscle Percentage, Bone Mass, Active Metabolic Rate (AMR)
• User Memory: 10 user storage spaces
• Display: LCD with blue backlight, 37 mm digit size
• Maximum Load Capacity: 180 kg (396 lbs / 28 st)
• Power Source: 4 x 1.5 V AAA batteries (included)
• Product Dimensions: 32 x 33 x 4.2 cm (L x W x H)
• Product Weight: 1.73 kg
• Special Features: Quick-start technology, Automatic shut-off, Overload indicator

Figure 4: Product Dimensions. This image provides a visual representation of the scale's physical dimensions, indicating its length, width, and height for reference.

Warranty and Support

Beurer products are manufactured to the highest quality standards. For information regarding warranty terms and conditions, please refer to the warranty card included with your product or visit the official Beurer website.

For technical support or service inquiries, please contact Beurer customer service or visit their official website for contact details and FAQs.

Official Beurer Website: www.beurer.com
