1. Introduction
This manual provides detailed instructions for the setup, operation, maintenance, and troubleshooting of your Nektar IMPACT GX61 USB MIDI Keyboard Controller. Please read this manual thoroughly to ensure proper use and to maximize the functionality of your device. Retain this manual for future reference.
2. Product Overview
The Nektar IMPACT GX61 is a 61-key velocity-sensitive USB MIDI keyboard controller designed for seamless integration with Digital Audio Workstations (DAWs). It features a compact design, robust build quality, and essential controls for music production.
Figure 2.1: Top view of the Nektar IMPACT GX61 MIDI Keyboard Controller, showcasing its 61 full-size keys and control panel on the left.
Figure 2.2: An overview highlighting key features of the IMPACT GX61, including its 61 velocity-sensitive full-size keys, Nektar's build quality, advanced DAW control capabilities, and straightforward connectivity options.
Key Features:
- 61 full-size, velocity-sensitive synth-action keys.
- Dedicated transport controls for DAW navigation.
- 7 assignable buttons for custom MIDI messages.
- Pitch bend and modulation wheels.
- Assignable footswitch input.
- Nektar DAW Integration for major DAWs.
- USB class compliant for Mac, Windows, and iOS.
3. Setup
Follow these steps to set up your Nektar IMPACT GX61 controller.
3.1 System Requirements
- Operating System: Windows XP or higher, Apple OSX, Apple iOS, Linux (MIDI driver software may be required).
- Hardware: Available USB port. For iOS devices, an Apple iPad Camera Connection Kit (sold separately) is required.
3.2 Connecting the Controller
- Connect one end of the supplied USB cable to the USB port on the rear of the IMPACT GX61.
- Connect the other end of the USB cable to an available USB port on your computer (Mac/PC) or to the Apple iPad Camera Connection Kit for iOS devices.
- The IMPACT GX61 is USB class compliant and does not require additional drivers for basic functionality on most operating systems. Your system should automatically recognize the device.
Figure 3.1: Side view of the Nektar IMPACT GX61, illustrating the USB connection port and indicating compatibility with USB Class Compliant devices, Windows OS, Mac OS, and iOS (via Camera Connection Kit).
3.3 Software Installation (Bitwig 8-Track)
Your IMPACT GX61 includes a license for Bitwig 8-Track DAW software. Follow the instructions provided with your product to download and activate this software. Bitwig 8-Track provides a powerful platform for music creation and integrates seamlessly with your Nektar controller.
Figure 3.2: The Nektar IMPACT GX61 shown alongside the Bitwig 8-Track software box and its distinctive logo, indicating the included software bundle.
4. Operating Instructions
This section details the primary functions and controls of the IMPACT GX61.
4.1 Keyboard Keys
The 61 full-size keys are velocity-sensitive, meaning the volume or intensity of the sound produced will vary based on how hard or soft you press the keys. This allows for expressive musical performance.
4.2 Pitch Bend and Modulation Wheels
- Pitch Bend Wheel: Located on the left side of the control panel, this wheel allows you to temporarily raise or lower the pitch of notes for expressive effects. It typically springs back to the center position.
- Modulation Wheel: Also on the left, this wheel can be assigned to control various parameters in your software, such as vibrato, filter cutoff, or tremolo. It stays in the position you set it.
4.3 Octave and Transpose Buttons
The dedicated Octave Up/Down and Transpose Up/Down buttons allow you to shift the keyboard's pitch range. The multi-colored LED indicators show the current octave or transpose status.
4.4 Transport Controls and Assignable Buttons
The IMPACT GX61 features dedicated transport controls (Play, Stop, Record, Rewind, Fast Forward) for controlling your DAW. Additionally, there are 7 assignable buttons that can be configured to send specific MIDI messages, offering hands-on control over various software functions.
Figure 4.1: A detailed view of the Nektar IMPACT GX61's DAW Control Center, highlighting the 8 buttons with advanced functionality, multi-colored Octave/Transpose buttons, Pitch-bend wheel, and Modulation wheel.
5. DAW Integration
Nektar's custom DAW integration provides enhanced control over popular Digital Audio Workstations, allowing you to navigate projects, control transport, and manage tracks directly from your IMPACT GX61.
Figure 5.1: The Nektar IMPACT GX61 positioned in front of a laptop displaying a Digital Audio Workstation interface, with a graphic highlighting Nektar's award-winning DAW integration and logos of various compatible DAWs.
Compatible DAWs include:
- Bitwig Studio
- Cubase
- Digital Performer
- FL Studio
- GarageBand
- Logic Pro X
- Nuendo
- Reason
- Reaper
- Studio One
- Cakewalk SONAR
For specific setup instructions for your DAW, please refer to the Nektar website or the software's documentation.
6. Maintenance
Proper care and maintenance will extend the life of your Nektar IMPACT GX61.
- Cleaning: Use a soft, dry cloth to clean the surface of the controller. For stubborn dirt, a slightly damp cloth can be used, but ensure no moisture enters the device. Avoid abrasive cleaners or solvents.
- Storage: Store the controller in a clean, dry environment away from direct sunlight, extreme temperatures, and excessive dust.
- Handling: Avoid dropping the unit or subjecting it to strong impacts. Do not place heavy objects on the keys or controls.
7. Troubleshooting
If you encounter issues with your IMPACT GX61, refer to the following common problems and solutions.
| Problem | Possible Cause | Solution |
|---|---|---|
| No sound or MIDI signal | Incorrect USB connection; DAW not configured correctly; volume levels too low. | Ensure USB cable is securely connected. Verify the IMPACT GX61 is selected as a MIDI input device in your DAW's preferences. Check master volume and track volume levels in your DAW. |
| Keys not responding or inconsistent velocity | Dust or debris under keys; incorrect velocity curve setting. | Gently clean around the keys. Refer to the Nektar documentation for adjusting velocity curves on the device. If the issue persists, contact support. |
| Pitch bend or modulation wheel malfunctioning | Dust accumulation; physical damage. | Attempt to gently clean around the wheel. Avoid forcing the wheel. If the issue persists, contact Nektar support as internal cleaning or replacement may be required. |
| DAW integration not working | Incorrect DAW setup; outdated firmware/software. | Ensure you have installed the correct Nektar DAW integration files for your specific DAW. Check for firmware updates for the IMPACT GX61 and software updates for your DAW. Restart your computer and controller. |
If the problem persists after attempting these solutions, please contact Nektar customer support.
8. Specifications
- Product Dimensions: 96.5 x 17.8 x 5.1 cm
- Item Weight: 2 kg
- Model Number: Impact GX61
- Color: Black
- Number of Keyboard Keys: 61
- Key Type: Velocity-sensitive, full-size synth-action
- Connectivity Technology: USB
- Hardware Interface: USB
- Compatible Devices: Laptop, PC/Mac/iOS
- Supported Software: Apple iOS, Apple OSX, Windows XP or higher, Linux (MIDI driver software required)
- Included Components: USB Cable, User Manual
- Country of Origin: China
9. Warranty and Support
For warranty information and technical support, please contact the manufacturer or authorized service center.
Manufacturer:
Nektar
Importer/Service Contact:
The InventoryOld No.102/ New No.145, Luz Church Road,
Mylapore, Chennai - 600 004,
Tamilnadu, India.
General/Service Email: info@theinventory.in
Contact Number: +91-44-42026415
