Introduction
Thank you for choosing the Auraglow Up/Down Wall Light. This modern fixture is designed to provide both upward and downward illumination, suitable for both indoor and outdoor environments. Its robust construction ensures durability and resistance to various weather conditions. This manual provides essential information for the safe installation, operation, and maintenance of your new wall light.
Image: Auraglow Up/Down Wall Light (Model AG434) shown with included LED bulbs. The fixture is black with clear glass diffusers at the top and bottom, designed for dual-direction lighting.
Safety Information
Please read all safety instructions carefully before installation and use. Failure to follow these instructions may result in electric shock, fire, or other hazards.
- Electrical Safety: Always disconnect the main power supply at the circuit breaker before attempting any installation, maintenance, or bulb replacement.
- Qualified Electrician: Installation should be performed by a qualified electrician or competent person in accordance with local wiring regulations.
- Voltage: This fixture operates on 220-240V, 50Hz. Ensure your electrical supply matches these requirements.
- Grounding: This is a Class 1 appliance and must be earthed. Ensure proper grounding during installation.
- Water Resistance: The fixture has an IP44 rating, making it suitable for outdoor use where it is protected against splashing water from any direction. However, it is not designed for submersion.
- Bulb Type: Use only the specified LED bulb type (GU10, 5.5W, 3000K warm white) or equivalent. Do not exceed the maximum wattage.
- Heat: LED bulbs can still generate heat. Allow bulbs to cool before handling.
Package Contents
Verify that all components are present before beginning installation:
- 1 x Auraglow Up/Down Wall Light Fixture (Model AG434)
- 2 x Auraglow 5.5W LED Bulbs (GU10, 3000K Warm White)
- Mounting Hardware (screws, wall plugs)
- 1 x Small Allen Key (for securing diffusers/bulb access)
Setup and Installation
Follow these steps for safe and correct installation:
- Prepare for Installation:
- Ensure the main power supply to the installation area is switched off at the consumer unit/fuse box.
- Choose a suitable mounting location, ensuring the surface can support the weight of the fixture and that there are no hidden pipes or electrical cables.
- Mark Drilling Points:
- Carefully remove the mounting bracket from the back of the light fixture.
- Hold the mounting bracket against the wall at the desired installation point and mark the drilling holes with a pencil.
- Drill Holes and Insert Wall Plugs:
- Drill holes at the marked positions using an appropriate drill bit for your wall type.
- Insert the provided wall plugs into the drilled holes.
- Secure Mounting Bracket:
- Attach the mounting bracket to the wall using the provided screws. Ensure it is firmly secured.
- Electrical Connection:
- Connect the household wiring to the terminal block inside the fixture. Ensure correct polarity (Live, Neutral, Earth) and that all connections are tight.
- This fixture is Class 1 and requires an earth connection.
- Mount the Fixture:
- Carefully align the light fixture with the mounting bracket and secure it using the screws provided, ensuring a tight seal if installing outdoors to maintain the IP44 rating.
- Install Bulbs:
- Using the small Allen key, loosen the screws on the top and bottom diffusers to access the bulb sockets.
- Insert the two Auraglow 5.5W GU10 LED bulbs into their respective sockets.
- Securely reattach the diffusers using the Allen key.
- Restore Power:
- Once installation is complete, restore power at the circuit breaker and test the light.
Image: Side view of the Auraglow Up/Down Wall Light, illustrating the mounting bracket and how the fixture attaches to the wall. This view highlights the compact design and secure fitting.
Operating Instructions
The Auraglow Up/Down Wall Light is designed for straightforward operation:
- Once properly installed and connected to the main power supply, the light can be switched on and off using your standard wall switch.
- The fixture will emit light both upwards and downwards, creating a decorative and functional lighting effect.
Maintenance
Regular maintenance ensures the longevity and optimal performance of your wall light:
- Cleaning:
- Ensure the power is off before cleaning.
- Wipe the fixture with a soft, damp cloth. Do not use abrasive cleaners or solvents, as these can damage the finish.
- For outdoor installations, periodically check and clean the glass diffusers to ensure maximum light output.
- Bulb Replacement:
- Always disconnect power before replacing bulbs.
- Using the small Allen key, loosen the screws on the top and bottom diffusers to access the GU10 bulb sockets.
- Carefully remove the old bulb by twisting and pulling it out.
- Insert a new GU10 LED bulb (max 5.5W, 3000K warm white recommended) by pushing it in and twisting to secure.
- Reattach the diffusers and tighten the screws with the Allen key.
- Restore power and test the light.
Image: Front view of the Auraglow Up/Down Wall Light, showing the clear glass diffusers at the top and bottom where the LED bulbs are housed. This image is useful for understanding bulb access.
Troubleshooting
If you encounter issues with your wall light, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Light does not turn on. | No power supply. Faulty bulb. Incorrect wiring. | Check circuit breaker and wall switch. Replace bulb with a known working one. Verify wiring connections (consult a qualified electrician if unsure). |
| Light flickers. | Loose bulb connection. Incompatible dimmer switch (if applicable). Faulty bulb. | Ensure bulbs are securely seated. Ensure you are using non-dimmable bulbs with a standard switch, or compatible dimmable bulbs with a suitable dimmer. Replace bulb. |
| Reduced light output. | Dirty diffusers. Aging bulbs. | Clean the glass diffusers. Consider replacing bulbs if they are old. |
Specifications
| Feature | Detail |
|---|---|
| Model Number | AG434BWW |
| Brand | Auraglow |
| Dimensions (L x W x H) | 26.3 x 10.3 x 11 cm (10.3 x 4.0 x 4.3 inches) |
| Weight | 1.3 Kilograms (2.87 lbs) |
| Material | Metal (body), Glass (diffusers) |
| Finish Type | Matte |
| Voltage | 220-240 Volts, 50Hz |
| Wattage (Total) | 10 Watts (2 x 5.5W LED bulbs) |
| Luminous Flux | 1100 lm |
| Color Temperature | 3000 Kelvin (Warm White) |
| Bulb Type | LED (GU10) |
| Energy Efficiency Class | A+ |
| IP Rating | IP44 (Waterproof) |
| Installation Type | Wall Mount |
| Special Features | Waterproof, Up/Down Illumination |
Image: Energy efficiency label, indicating an A+ rating for the Auraglow wall light.
Warranty
The Auraglow Up/Down Wall Light comes with a 2-year warranty from the date of purchase. This warranty covers manufacturing defects and faulty materials under normal use. Please retain your proof of purchase for any warranty claims. The warranty does not cover damage caused by improper installation, misuse, accidents, or unauthorized modifications.
Support
For further assistance, technical support, or warranty inquiries, please contact Auraglow customer service. Refer to your purchase documentation or the Auraglow website for contact details.
Please note: Always ensure power is disconnected before performing any checks or maintenance on the light fixture.
