Waterpik WP-662E Professional Dental Flosser Instruction Manual

Introduction

This manual provides detailed instructions for the safe and effective use of your Waterpik WP-662E Professional Dental Flosser. This device is designed to remove bacteria deep between teeth and below the gumline, areas often missed by traditional brushing and flossing. Please read all instructions before operating the device.

The Waterpik WP-662E features 7 unique tips, 10 pressure settings, and a 650 ml reservoir for over 90 seconds of continuous use. It is suitable for individuals with braces, implants, crowns, bridges, or periodontal pockets.

Important Safeguards

When using electrical products, especially when children are present, basic safety precautions should always be followed. Read all instructions before use.

• Do not place or store the product where it can fall or be pulled into a tub or sink.
• Do not reach for a product that has fallen into water. Unplug immediately.
• Do not use while bathing.
• Do not direct water under the tongue, into the ear, nose, or other delicate areas. This product is capable of producing pressures that may cause serious damage in these areas.
• Use this product only for its intended use as described in this manual.
• Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water.

Package Contents

Your Waterpik WP-662E Professional Dental Flosser package includes the main unit and a variety of specialized tips to meet different oral care needs.

• Waterpik WP-662E Main Unit (Black)
• 7 Water Flosser Tips:
• 3 Classic Jet Tips (for general use)
• 1 Plaque Seeker Tip (for implants, crowns, bridges, veneers)
• 1 Orthodontic Tip (for braces)
• 1 Pik Pocket Tip (for periodontal pockets)
• 1 Toothbrush Tip (for brushing and water flossing simultaneously)

Image: The Waterpik WP-662E unit shown with its full set of 7 interchangeable tips, including classic jet, plaque seeker, orthodontic, pik pocket, and toothbrush tips.

Setup

1. Placement: Place the Waterpik unit on a flat, stable surface near a power outlet and a sink.
2. Fill Reservoir: Lift the hinged lid of the reservoir and fill it with lukewarm water. You may also add mouthwash if desired. Close the lid. The reservoir has a capacity of 650 ml.


Image: A hand is shown filling the clear water reservoir of the Waterpik flosser directly from a faucet, indicating the fill line markings.

3. Insert Tip: Select the desired tip and insert it into the center of the handle until it clicks into place. To remove a tip, press the eject button on the handle.
4. Plug In: Plug the power cord into a suitable electrical outlet. Ensure the outlet is compatible with the device's voltage requirements.

Image: A European two-pin power plug, suitable for shaver sockets, is shown next to a wall outlet labeled 'SHAVERS ONLY', indicating the power connection method.

Operating Instructions

1. Prime Unit (First Use Only): If using for the first time, set the pressure control dial to high (setting 10). Direct the tip into the sink. Turn the unit ON until water flows from the tip. Turn OFF the unit.
2. Adjust Pressure: Turn the pressure control dial on the base of the unit to the lowest setting (1) for initial use. Gradually increase the pressure to a comfortable level. The device offers 10 pressure settings.


Image: A close-up view of the Waterpik control panel, showing the power button, dedicated buttons for 'Floss' and 'Massage' modes, and a rotary dial for adjusting water pressure from 1 to 10.

3. Select Mode: Press the 'Floss' button for standard water flossing or the 'Massage' button for a pulsating gum massage.
4. Begin Flossing: Lean over the sink and place the tip in your mouth. Close your lips enough to prevent splashing, but allow water to flow from your mouth into the sink. Turn the unit ON.

Image: A woman is shown using the Waterpik flosser while leaning over a bathroom sink, with the device placed on the counter next to the faucet. She is looking into a mirror, demonstrating proper usage posture.
5. Technique: Aim the water stream at the gumline at a 90-degree angle. Follow the gumline, pausing briefly between teeth. Continue until you have cleaned the inside and outside of both upper and lower teeth.
6. Finish: Turn the unit OFF when finished or when the reservoir is empty.

Maintenance

Regular cleaning ensures optimal performance and hygiene of your Waterpik Dental Flosser.

1. Cleaning the Tip: After each use, remove the tip from the handle. Rinse the tip under running water. For thorough cleaning, tips can be placed in the top rack of a dishwasher.
2. Cleaning the Reservoir: Empty any remaining water from the reservoir. It is recommended to rinse the reservoir with clean water after each use. For deeper cleaning, the reservoir is top-rack dishwasher safe.
3. Cleaning the Unit: Wipe the main unit with a soft cloth and mild, non-abrasive cleaner as needed. Do not immerse the unit in water.
4. Mineral Deposits: If hard water is used, mineral deposits may build up. To clean, add 2 tablespoons of white vinegar to a full reservoir of warm water. Run the unit until the reservoir is empty. Rinse by filling the reservoir with clean warm water and running the unit until empty.

Troubleshooting

If you encounter issues with your Waterpik WP-662E, refer to the following common solutions:

• No Water Flow:
  • Ensure the reservoir is filled with water.
  • Check that the tip is securely inserted into the handle.
  • If it's the first use, ensure the unit has been primed as described in the setup section.
  • Inspect the hose for kinks or blockages.
• Low Pressure:
  • Verify the pressure control dial is set to a higher number.
  • Clean the unit for mineral deposits as described in the Maintenance section.
• Unit Not Turning On:
  • Ensure the power cord is securely plugged into a working electrical outlet.
  • Check if the outlet itself is functional by plugging in another device.
• Leaking:
  • Ensure the reservoir is properly seated on the base.
  • Check that the tip is fully inserted and not damaged.

For further assistance, please contact Waterpik customer support.

Specifications

Warranty and Support

Waterpik products are manufactured with high-quality standards. For warranty information or technical support, please refer to the warranty card included with your product or visit the official Waterpik website. Keep your purchase receipt as proof of purchase for warranty claims.

For direct assistance, you may contact Waterpik customer service through their official channels.
