Lorell LLR83306
Lorell Task Chair with Arms User Manual
Model: LLR83306
Important Safety Information
This chair has a maximum weight capacity of 250 lb. Exceeding this limit may compromise the chair's stability and lead to damage or injury.
Improper use of the pneumatic height adjustment feature may lead to injury. Always ensure you are seated properly and adjust the height smoothly.
Ensure proper assembly of the chair for stability and safety. Regularly check all fasteners to ensure they are tight. Do not use the chair if any parts are loose, damaged, or missing.
Product Overview
The Lorell Task Chair with Arms (Model LLR83306) is designed for office use, featuring a cushioned seat and back for comfort. It includes adjustable functions for personalized seating.
Image 1: The Lorell Task Chair with Arms, Model LLR83306, shown in a typical office environment. The chair features a black fabric seat and back, with fixed arms, a five-star base with casters, and pneumatic height adjustment. It is positioned in front of a wooden desk with a computer monitor and a desk lamp.
Parts List
Before assembly, ensure all components are present and undamaged. If any parts are missing or damaged, contact customer support.
- Backrest
- Seat Cushion
- Armrests (2)
- Mechanism Plate
- Gas Lift Cylinder
- Cylinder Cover
- Five-Star Base
- Casters (5)
- Assembly Hardware (screws, washers, Allen wrench)
Setup and Assembly Instructions
Follow these steps carefully for proper assembly. It is recommended to assemble the chair on a soft, non-abrasive surface to prevent damage.
- Attach Casters to Base: Insert each of the five casters into the holes at the end of each leg of the five-star base. Push firmly until they click into place.
- Insert Gas Lift: Place the gas lift cylinder into the center hole of the five-star base. Cover the cylinder with the cylinder cover.
- Attach Mechanism Plate to Seat: Align the mechanism plate with the pre-drilled holes on the underside of the seat cushion. Ensure the front of the mechanism (usually indicated by an arrow or "FRONT" label) faces the front of the seat. Secure with screws using the provided Allen wrench.
- Attach Armrests to Seat: Attach the armrests to the sides of the seat cushion using the designated screws. Do not overtighten initially.
- Attach Backrest to Seat/Arms: Align the backrest with the mounting points on the seat mechanism or armrests. Secure with screws. Once all screws are in place for the backrest and armrests, tighten all screws firmly.
- Connect Seat Assembly to Gas Lift: Carefully place the assembled seat onto the gas lift cylinder, ensuring the center hole of the mechanism plate aligns with the top of the gas lift. Press down firmly to secure.
Assembly is now complete.
Operating Instructions
This chair offers several adjustments to customize your seating experience.
- Pneumatic Seat-Height Adjustment: To raise the seat, lift the lever located under the right side of the seat while taking your weight off the chair. To lower the seat, lift the lever while seated. Release the lever at the desired height.
- Adjustable Tilt Tension: The round knob located under the front-center of the seat controls the tilt tension. Turn clockwise to increase tension (making it harder to recline) or counter-clockwise to decrease tension (making it easier to recline).
- Tilt Lock: To lock the chair in an upright position, push the lever (often the same lever as height adjustment, pushed inwards) towards the center of the chair. To unlock and allow reclining, pull the lever outwards.
- 360-Degree Swivel: The chair is designed to swivel freely 360 degrees for easy movement and access to your workspace.
- Waterfall Front Edge: The seat features a waterfall front edge designed to relieve pressure on your legs and improve circulation.
Maintenance
- Cleaning: For general cleaning, wipe surfaces with a soft, damp cloth. For fabric upholstery, spot clean only. Use a mild fabric cleaner if necessary, testing on an inconspicuous area first. Avoid harsh chemicals or abrasive cleaners.
- Inspection: Periodically check all screws and fasteners to ensure they are tight. Retighten if necessary. Inspect casters for any debris that might hinder movement.
- Weight Capacity: Do not exceed the maximum weight capacity of 250 lb.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Chair does not adjust height | Gas lift cylinder malfunction or lever not engaged. | Ensure the height adjustment lever is fully engaged. If the problem persists, the gas lift may need replacement. Contact customer support. |
| Chair wobbles or is unstable | Loose assembly screws or uneven floor. | Check and tighten all assembly screws, especially those connecting the seat, back, and arms. Ensure the chair is on a flat, even surface. |
| Casters do not roll smoothly | Debris caught in casters or damaged casters. | Turn the chair over and remove any hair, dust, or debris from the caster wheels. If casters are damaged, they may need replacement. |
| Chair reclines too easily or too stiffly | Tilt tension not adjusted correctly. | Adjust the tilt tension knob located under the seat. Turn clockwise to increase tension, counter-clockwise to decrease. |
Specifications
- Brand: Lorell
- Model Number: LLR83306
- Color: Black
- Material: Textile (Seat Material: Fabric, Fill Material: Foam)
- Frame Material: Polypropylene
- Product Dimensions (D x W x H): 25.6" x 24" x 14.8"
- Item Weight: 33.07 Ounces
- Maximum Weight Recommendation: 250 Pounds
- Seat Height: 20.87 Inches
- Seat Depth: 25.8 Inches
- Chair Backrest Width: 19.88 Inches
- Features: Armrests, Cushioned, Swivel, Tilting, Pneumatic Height Adjustment, Tilt Lock, Adjustable Tilt Tension, Waterfall Seat Edge
- Recommended Use: Office (Indoor)
- Required Assembly: Yes
- Care Instructions: Spot Clean
Warranty and Support
This Lorell Task Chair (Model LLR83306) comes with a 3-year manufacturer's warranty. This warranty covers defects in materials and workmanship under normal use.
For warranty claims, missing parts, or technical support, please contact Lorell customer service. Refer to your purchase documentation for specific contact details or visit the official Lorell website.
