1. Important Safety Instructions
Please read and understand all instructions before using this appliance. Failure to follow these instructions may result in electric shock, fire, or serious injury.
- Placement: Always place the radiator on a firm, level surface. Ensure it is at least 1 meter (3 feet) away from walls, furniture, curtains, and other combustible materials. Do not place it on soft surfaces like beds or deep carpets where openings may be blocked.
- Electrical Safety: Connect the radiator only to a properly grounded 230V AC outlet. Do not overload electrical circuits. Avoid using extension cords; if one is necessary, ensure it is rated for the appliance's wattage and fully unwound. Never operate the radiator with a damaged cord or plug.
- Moisture: Do not use the radiator in bathrooms, laundry areas, or other damp locations. Never immerse the radiator in water or other liquids.
- Supervision: Close supervision is necessary when the radiator is used by or near children or individuals with reduced physical, sensory, or mental capabilities. Do not leave the appliance unattended while operating.
- Overheating Protection: This radiator is equipped with an automatic overheat protection system that will shut off the unit if it becomes too hot. If this occurs, unplug the unit, allow it to cool, and ensure no obstructions are blocking the air vents before restarting.
- Tip-Over Protection: The radiator includes a safety switch that automatically turns off the unit if it is accidentally tipped over. If this happens, place the radiator upright on a stable surface to resume operation.
- Do Not Cover: Never cover the radiator with clothing, blankets, or any other material. This can lead to overheating and fire.
- Moving the Unit: Always use the integrated handle to move the radiator. Ensure the unit is cool and unplugged before relocating it.
- Maintenance: Refer to the maintenance section for cleaning instructions. Do not attempt to repair the appliance yourself. Contact qualified service personnel for repairs.
2. Product Overview
The Perel Oil-Filled Radiator 700W is a portable heating solution designed for indoor use. It features 7 oil-filled fins for efficient heat distribution, an adjustable thermostat, and essential safety features like overheat and tip-over protection.
Figure 1: Front view of the Perel Oil-Filled Radiator 700W.
Key Features:
- 7 Oil-Filled Fins: For rapid and even heat distribution.
- Adjustable Thermostat: To set and maintain desired room temperature.
- Overheat Protection: Automatic shut-off for safety.
- Tip-Over Protection: Automatically turns off if the unit is knocked over.
- Integrated Carry Handle: For easy portability.
- Wheels: For convenient movement between rooms.
- Power Indicator Light: Shows when the unit is operating.
Figure 2: Detailed view of the radiator highlighting its handle, adjustable heating dial, stable base, and oil-filled elements.
3. Setup
- Unpacking: Carefully remove the radiator from its packaging. Retain the packaging for future storage or transport.
- Inspection: Check the appliance for any signs of damage. Do not operate if the unit, cord, or plug is damaged.
- Placement: Place the radiator upright on a stable, level, and heat-resistant surface. Ensure it is positioned away from any flammable materials, as specified in the safety instructions.
- Ventilation: Ensure there is adequate space around the radiator for proper air circulation. Do not block the air vents.
4. Operating Instructions
Follow these steps to operate your Perel Oil-Filled Radiator:
- Plug In: Insert the power plug into a suitable 230V AC grounded wall outlet.
- Power On: Press the ON/OFF switch to the 'ON' position. The power indicator light will illuminate.
- Set Thermostat: Turn the thermostat dial clockwise to the 'HIGH' setting to quickly warm the room. Once the desired room temperature is reached, slowly turn the thermostat dial counter-clockwise until the heater turns off. The heater will then cycle on and off to maintain this temperature.
- Adjust Heat Output: The thermostat dial allows for continuous adjustment of the heat output from 'LOW' to 'HIGH'.
- Power Off: To turn off the radiator, press the ON/OFF switch to the 'OFF' position and unplug the unit from the wall outlet.
Figure 3: Close-up of the control panel with ON/OFF switch and thermostat dial.
Note: During the first few uses, a slight odor may be noticeable. This is normal and will dissipate quickly. Ensure the room is well-ventilated during initial operation.
5. Maintenance
Regular cleaning and proper storage will ensure the longevity and efficient operation of your radiator.
- Before Cleaning: Always unplug the radiator from the power outlet and allow it to cool completely before cleaning.
- Exterior Cleaning: Wipe the exterior surfaces of the radiator with a soft, damp cloth. Do not use abrasive cleaners, solvents, or harsh chemicals, as these can damage the finish.
- Dust Removal: Use a vacuum cleaner with a brush attachment to remove dust from the air vents and between the fins.
- Storage: When not in use, store the radiator in a cool, dry place. If possible, use the original packaging to protect it from dust and damage.
6. Troubleshooting
If you encounter issues with your Perel Oil-Filled Radiator, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Radiator does not turn on. |
|
|
| Radiator is on but not heating. |
|
|
| Radiator emits an unusual odor. |
|
|
If the problem persists after attempting these solutions, please contact customer support or a qualified technician.
7. Specifications
Detailed technical specifications for the Perel Oil-Filled Radiator 700W (Model VELLtc78007).
Figure 4: Product dimensions for the Perel Oil-Filled Radiator.
- Brand: Perel
- Model Number: VELLtc78007
- Power: 700 Watts
- Voltage: 230 Volts (AC)
- Number of Elements: 7 oil-filled fins
- Dimensions (L x W x H): 13.5 x 35.5 x 41 cm (approx. 33 x 14 x 38 cm based on image)
- Weight: 3.83 Kilograms
- Color: White
- Features: Adjustable Thermostat, Overheat Protection, Tip-Over Protection, Portable, Wheels
- Intended Use: Indoor only
Figure 5: Radiator highlighting 700W power and suitability for areas up to 8m².
8. Warranty and Support
For warranty information, please refer to the documentation provided with your purchase or contact your retailer. Keep your proof of purchase for any warranty claims.
For technical support or service inquiries, please contact the manufacturer, Perel, or your local distributor. Contact details can typically be found on the product packaging or the manufacturer's official website.
