Introduction
This manual is a digitally enhanced reproduction of the original manufacturer-issued shop manual for the Massey Ferguson 2200 Industrial Tractor. It specifically covers the Gas and Diesel Forklift variants of this equipment. The primary purpose of this document is to provide exploded views of components with corresponding descriptions and original part numbers. This information is essential for accurate part identification and ordering, particularly for specialized or older equipment. This parts manual serves as a visual complement to any accompanying service manual.
Figure 1: Front cover of the Massey Ferguson 2200 Industrial Tractor Parts Manual. The cover displays the brand names Massey Harris and Massey Ferguson, the manual type as 'Parts Manual', and the model 'MF2200 Industrial Fork Lift Gas & Diesel'. An exploded diagram of an engine block is visible at the top.
How to Use This Manual
This parts manual is organized to facilitate the identification and ordering of replacement components for your Massey Ferguson 2200 Industrial Tractor. Follow these steps to effectively utilize the manual:
- Locate the Relevant Section: The manual is divided into sections corresponding to major systems or assemblies of the tractor (e.g., Engine, Transmission, Hydraulic System). Use the section titles to navigate to the area containing the part you need.
- Identify the Exploded View: Within each section, you will find exploded diagrams. These diagrams illustrate the components of an assembly in a disassembled state, showing how they fit together.
- Match Part to Number: Each component in the exploded view is assigned a reference number. Cross-reference this number with the accompanying parts list.
- Note Part Description and Number: The parts list provides a detailed description of each component, along with its original manufacturer part number. This part number is crucial for ordering the correct replacement.
- Verify Application: Pay attention to any notes or remarks in the parts list that specify the application (e.g., "Gasoline models only," "Diesel models only," "Serial number range").
Interpreting Parts Diagrams
Exploded diagrams are visual representations designed to simplify complex assemblies. Understanding their conventions is key to successful part identification:
- Component Separation: Parts are shown separated from each other but aligned to indicate their relative positions in the assembled unit.
- Reference Numbers: Small numbers or letters point directly to individual components. These correspond to entries in the adjacent or following parts list.
- Directional Arrows: Some diagrams may include arrows to indicate the direction of assembly or flow, though this is less common in pure parts manuals.
- Sub-Assemblies: Larger assemblies may be broken down into smaller sub-assemblies, each with its own diagram and parts list.
Always refer to the accompanying parts list for the definitive part number and description, as diagrams are primarily for visual guidance.
Parts Identification for Maintenance
When performing maintenance or repairs on your Massey Ferguson 2200 Industrial Tractor, accurate part identification is critical to ensure compatibility and proper function. This manual assists in:
- Preventative Maintenance: Identifying wear-and-tear components (e.g., filters, belts, seals) before they fail.
- Corrective Maintenance: Pinpointing the exact part number for a failed or damaged component.
- Assembly Verification: Using the exploded views to confirm the correct order and placement of parts during reassembly.
It is recommended to have the tractor's serial number available when ordering parts, as some components may vary by production run.
Troubleshooting Parts Identification
If you encounter difficulties identifying a specific part, consider the following troubleshooting steps:
- Verify Model and Serial Number: Ensure you are using the correct manual for your specific Massey Ferguson 2200 Industrial Tractor model and serial number.
- Check Adjacent Sections: Sometimes a component might be listed in a related assembly section.
- Look for Revisions: Older equipment may have undergone revisions. If a part doesn't match, consult a dealer with your serial number to check for updated part numbers or superseded components.
- Consult a Service Manual: While this is a parts manual, a service manual may offer additional context or diagnostic information that helps narrow down the component in question.
Manual Specifications
The following are key specifications pertaining to this Massey Ferguson 2200 Industrial Tractor Parts Manual:
| Specification | Detail |
|---|---|
| ASIN | B01E72OBTC |
| Publication Date | January 1, 2015 |
| Print Length | 318 pages |
| Format | Plastic Comb |
Warranty and Support Information
This document is a reproduction of a parts manual and does not typically include warranty information for the tractor itself. For details regarding the warranty of your Massey Ferguson 2200 Industrial Tractor or for technical support, please refer to the original owner's manual, service manual, or contact an authorized Massey Ferguson dealer. Information regarding the return policy for this manual can be found where it was purchased.
