Introduction
This manual provides essential information for the installation, operation, and maintenance of your SCHOCK Formhaus D-150L Nero granite kitchen sink. Please read these instructions carefully before beginning installation or use to ensure proper function and longevity of your product.
The SCHOCK Formhaus D-150L Nero is a premium quartz composite sink, measuring 100 x 50 cm, designed to be a focal point in any kitchen. Its CRISTALITE material offers a robust, stone-like surface that is resistant to heat, odors, staining foods, impacts, and scratches. The sink features a large main bowl, a half bowl, and an integrated drainer, offering practical functionality for daily kitchen tasks. Manufactured in Germany, SCHOCK sinks are known for their timeless design, functionality, and durability.
Image: The SCHOCK Formhaus D-150L Nero kitchen sink, showcasing its elegant design and integrated drainer in a kitchen environment.
Setup and Installation
The SCHOCK Formhaus D-150L sink is designed for inset/top-mount installation and is reversible, allowing you to choose the orientation of the bowls (main bowl on the left or right) to best suit your kitchen layout. It is suitable for cabinets with a minimum width of 60 cm.
Package Contents:
- SCHOCK Formhaus D-150L Nero Sink
- 3½" Waste Fitting
- Basket Strainer
- Eccentric Control (for waste operation)
Installation Steps:
- Prepare the Cabinet: Ensure your kitchen cabinet has a minimum width of 60 cm. Create the necessary cutout in your countertop according to the provided template (not included in this manual, refer to packaging).
- Orient the Sink: Decide whether you want the main bowl on the left or right side. The sink's reversible design accommodates both configurations.
- Punch Out Faucet Holes: The sink features pre-drilled holes for faucet installation. Carefully punch out the desired holes using appropriate tools.
- Install Waste Fittings: Assemble the 3½" waste fitting, basket strainer, and eccentric control according to the separate instructions provided with these components.
- Place the Sink: Carefully lower the sink into the countertop cutout. Ensure a secure and watertight seal using appropriate sealant (not included).
- Connect Plumbing: Connect the waste fittings to your household plumbing system. Ensure all connections are tight and leak-free.
- Install Faucet: Mount your kitchen faucet into the prepared hole and connect its water supply lines.
Image: Technical drawing showing the dimensions and layout of the SCHOCK Formhaus D-150L sink, including bowl sizes and overall measurements.
Operating Instructions
Your SCHOCK Formhaus D-150L sink is designed for everyday kitchen use, offering convenience and durability.
- Bowl Usage: Utilize the large main bowl for washing larger items like pots and pans, and the half bowl for smaller tasks or as a rinsing area.
- Drainer: The integrated drainer provides a convenient space for drying dishes, fruits, or vegetables.
- Eccentric Control: The eccentric control allows you to open and close the waste outlet without reaching into the water, providing hygienic and easy operation. Turn the knob to control the basket strainer.
Image: Detail of the eccentric control knob, which allows for convenient operation of the waste fitting.
Maintenance and Care
The CRISTALITE material of your SCHOCK sink is highly durable and easy to maintain. Regular cleaning will preserve its appearance and hygienic properties.
- Daily Cleaning: For everyday cleaning, use a soft cloth or sponge with mild dish soap and warm water. Rinse thoroughly and dry with a soft cloth to prevent water spots.
- Stain Removal: The CRISTALITE surface is resistant to stubborn stains. For more persistent marks, use a non-abrasive cream cleaner or a specialized granite sink cleaner. Avoid harsh chemicals, abrasive pads, or steel wool, as these can damage the surface.
- Heat Resistance: The sink is heat-resistant, but it is always recommended to use a trivet or heat pad for extremely hot pots and pans to prevent potential thermal shock or discoloration over time.
- Impact and Scratch Resistance: While highly resistant to impacts and scratches, avoid dropping heavy or sharp objects into the sink to prevent damage.
- Odor Neutral: The material is odor-neutral, ensuring your kitchen remains fresh.
- Pro Hygienic 21: The integrated Pro Hygienic 21 feature provides enhanced hygiene, making the surface easy to clean and inhibiting bacterial growth.
Image: Visual representation of the SCHOCK sink's material properties, including resistance to color, heat, impacts, and its hygienic qualities.
Troubleshooting
Should you encounter any issues with your SCHOCK Formhaus D-150L sink, please consider the following:
- Water Leaks: Check all plumbing connections for tightness. Ensure that the sealant around the sink's edge is intact.
- Slow Drainage: Inspect the basket strainer and waste fitting for any blockages. Clean as necessary.
- Surface Discoloration: While highly stain-resistant, some strong dyes or chemicals left for extended periods might cause temporary discoloration. Refer to the maintenance section for cleaning recommendations.
If problems persist, please contact SCHOCK customer support or a qualified plumber.
Specifications
| Feature | Specification |
|---|---|
| Manufacturer | SCHOCK |
| Model Number | FOMD150LAGNE |
| Product Dimensions (L x W x H) | 100 x 50 x 29.7 cm |
| Weight | 12.6 Kilograms |
| Color | Nero (Black) |
| Material | Quartz Composite Granite (CRISTALITE) |
| Style | Timeless, Modern |
| Finish | Brushed |
| Shape | Rectangular |
| Installation Method | Inset / Top-mount |
| Minimum Cabinet Width | 60 cm |
| Number of Bowls | 1 Main Bowl, 1 Half Bowl |
| Drain Type | Grid (Basket Strainer) |
| Included Components | Sink, 3½" Waste Fitting, Basket Strainer, Eccentric Control |
Warranty Information
SCHOCK products are manufactured to high-quality standards. For specific warranty terms and conditions, please refer to the documentation included with your purchase or visit the official SCHOCK website. Keep your proof of purchase for any warranty claims.
Customer Support
If you have any questions regarding the installation, operation, or maintenance of your SCHOCK Formhaus D-150L sink, please contact SCHOCK customer support. Contact details can typically be found on the manufacturer's website or in the product packaging.
