Huntkey SMD407-02 Wall Mount Cradle with Dual USB Charging Ports User Manual

1. Product Overview

The Huntkey SMD407-02 is a wall-mounted power solution designed to expand your electrical outlets and provide convenient USB charging. It features two standard AC outlets and two USB charging ports, along with an integrated cradle ledge to hold your devices while they charge.

Image 1.1: Huntkey SMD407-02 Wall Mount Cradle in use, showcasing its features.

Key Features:

• Two AC Outlets: Provides additional power receptacles for standard electrical devices.
• Dual USB Charging Ports: Two 5V/2.1A USB ports for charging smartphones, tablets, and other USB-powered devices.
• Integrated Cradle Ledge: A convenient shelf to securely hold devices during charging.
• Fire-Retardant Material: Constructed with V0 fire-retardant material for enhanced safety.
• Integral Copper Bar: Designed with an integral copper bar for efficient power transmission.
• Compact Design: Space-saving and portable for various applications.

Image 1.2: Close-up of the dual 5V/2.1A USB charging ports.

2. Safety Information

Please read and understand all safety instructions before using this product. Failure to follow these instructions may result in electric shock, fire, or serious injury.

• Electrical Ratings: Do not exceed the electrical ratings of 125V, 15A, or 1875W. Overloading the device can cause fire or electric shock.
• Indoor Use Only: This product is intended for indoor use in dry locations only. Do not use in wet or damp environments.
• Keep Away from Water: Do not expose the device to water or other liquids.
• Do Not Disassemble: Do not attempt to disassemble, repair, or modify the unit. Contact qualified service personnel for any repairs.
• Children and Pets: Keep out of reach of children and pets.
• Proper Insertion: Ensure plugs are fully inserted into the outlets.
• Ventilation: Do not block ventilation openings.
• Certifications: This product is ETL, cETL, and UL listed, ensuring compliance with safety standards.

3. Setup and Installation

The Huntkey SMD407-02 is designed for easy installation into a standard wall outlet.

1. Identify Outlet Type: This unit is compatible with standard and decor-style duplex wall outlets. It is not designed for use with USB receptacles or GFCI outlets without modification.
2. Stabilizing Post (Optional): The unit features a stabilizing post on the back. For standard and decor outlets, this post helps secure the unit. If plugging into a GFCI or USB receptacle, the stabilizing post may need to be carefully cut off to ensure a flush fit.
3. Plug In: Align the prongs of the Huntkey SMD407-02 with the top or bottom receptacle of your wall outlet. For optimal stability and to utilize the cradle feature effectively, plugging into the top receptacle is recommended. Push firmly until the unit is securely seated against the wall.

Image 3.1: Back view of the unit showing the stabilizing post and outlet compatibility.

4. Operation

Once installed, the Huntkey SMD407-02 is ready for use.

Using the AC Outlets:

• Plug your electrical devices directly into the two 3-prong AC outlets on the front of the unit.
• Ensure that the total power consumption of all connected AC devices does not exceed 1875 Watts.

Using the USB Charging Ports:

• Connect your USB charging cable to one of the two USB ports (5V/2.1A) on the top of the unit.
• Connect the other end of the cable to your smartphone, tablet, or other USB-powered device.
• The 2.1A output is shared between both USB ports. For fastest charging, use one port at a time or ensure your devices can share the available current.

Using the Cradle Ledge:

• The integrated ledge above the USB ports can be used to hold your device while it is charging.
• Place your smartphone or small tablet on the ledge to keep it off the floor or countertop.

Image 4.1: Device resting on the cradle ledge while charging.

5. Maintenance

To ensure the longevity and proper functioning of your Huntkey SMD407-02, follow these simple maintenance guidelines:

• Cleaning: Disconnect the unit from the wall outlet before cleaning. Wipe the exterior with a soft, dry cloth. Do not use liquid cleaners, aerosols, or abrasive cleaning agents.
• Inspection: Periodically inspect the unit for any signs of damage, such as cracks in the casing or loose connections. If damage is observed, discontinue use and contact support.
• Storage: If storing the unit, keep it in a cool, dry place away from direct sunlight and moisture.

6. Troubleshooting

If you encounter issues with your Huntkey SMD407-02, refer to the following common problems and solutions:

• No Power to AC Outlets or USB Ports:
  • Ensure the Huntkey unit is fully and securely plugged into the wall outlet.
  • Check the wall outlet by plugging in another known working device. If the wall outlet has no power, check your home's circuit breaker.
  • Ensure the total wattage of connected devices does not exceed 1875W.
• USB Devices Not Charging or Charging Slowly:
  • Verify that your USB cable is not damaged and is properly connected to both the unit and your device.
  • Ensure your device is compatible with 5V/2.1A charging.
  • If multiple devices are connected to the USB ports, the 2.1A current is shared, which may result in slower charging for each device. Try charging one device at a time.
• Unit Feels Loose in Wall Outlet:
  • Ensure the unit is fully inserted.
  • If the wall outlet itself is worn, it may not provide a snug fit. Consider having a qualified electrician inspect or replace the wall outlet.
  • Ensure the stabilizing post on the back is intact and not interfering with the outlet if it's a GFCI or USB type.

7. Specifications

Image 7.1: Approximate dimensions of the Huntkey SMD407-02.

8. Warranty and Support

The Huntkey SMD407-02 Wall Mount Cradle comes with a 3-year warranty from the date of purchase. This warranty covers defects in materials and workmanship under normal use.

For warranty claims, technical support, or any questions regarding your product, please contact Huntkey customer service through their official website or the retailer where the product was purchased. Please have your proof of purchase and product model number (SMD407-02) available when contacting support.
