Bear DFH-A20D1 Multifunctional Electric Lunch Box User Manual

1. Product Overview

The Bear DFH-A20D1 is a 2.0L multifunctional electric lunch box designed for convenient and healthy meal preparation. It integrates several cooking functions, including rice cooking, soup preparation, vegetable steaming, and egg steaming, making it ideal for various culinary needs. Its compact and portable design, coupled with intelligent features, ensures ease of use and food preservation.

• Equipped with a rice cooker, soup pot, vegetable pot, and egg steamer.
• Capable of steaming, cooking desserts, and baby congee.
• Designed to retain moisture, nutrition, and flavor in food.
• Features a smart switch for easy operation and wide applicability.
• Stylish appearance with delicate processing for durability.

2. Safety Instructions

To ensure safe operation and prevent damage to the appliance or injury, please read and adhere to the following safety guidelines:

• Always connect the appliance to a grounded power outlet with the correct voltage (220-240V ~ 50/60Hz).
• Do not immerse the main unit (base with electrical components) in water or any other liquid.
• Ensure the power cord is not damaged, kinked, or placed near hot surfaces.
• Keep the appliance out of reach of children and pets.
• Do not operate the appliance if it is damaged or malfunctioning. Contact customer support for repairs.
• The appliance features an Overheat Protection system and Safe Auto Power Off When Dry function to prevent damage from overheating or dry boiling.
• Always ensure there is sufficient water in the heating plate before operation to avoid dry boiling.
• Use only the accessories provided or recommended by the manufacturer.
• Allow the appliance to cool down completely before cleaning or storing.

Illustration of the 'Safe Auto Power Off When Dry' feature, indicating automatic shutdown for safety.

3. Product Components

The Bear DFH-A20D1 Electric Lunch Box comes with the following components:

• Main Unit (Heating Base and Outer Shell)
• 304 Food Grade Stainless Steel Bowls:
• 1 x 1.0L Bowl
• 1 x 0.65L Soup Bowl
• 1 x 0.35L Dish Plate
• Sealing Covers for Bowls
• Egg Rack Tray
• Measuring Cup
• Vacuum Rod (for vacuum sealing function)
• Power Cord

An exploded view illustrating the various components of the lunch box, including the stainless steel bowls and their respective capacities.

Detail showing the use of 304 food-grade stainless steel for inner components and PP material for the outer shell, ensuring safety and durability.

4. Setup

1. Unpacking: Carefully remove all components from the packaging. Retain packaging for future storage or transport if needed.
2. Initial Cleaning: Before first use, wash all removable parts (stainless steel bowls, covers, egg rack) with warm soapy water. Rinse thoroughly and dry completely. Wipe the main unit with a damp cloth; do not immerse it in water.
3. Assembly: Place the desired stainless steel bowls into the main unit. Ensure they are properly seated. If using the egg rack, place it on top of the lower bowl before adding eggs.
4. Water Addition: Pour the appropriate amount of water into the heating plate at the bottom of the main unit, according to the cooking function and food quantity. Do not exceed the maximum water level indicator.
5. Power Connection: Connect the power cord to the appliance and then plug it into a suitable electrical outlet.

5. Operating Instructions

5.1 General Operation

The Bear DFH-A20D1 features a smart switch for easy cooking. It utilizes PTC heating technology for efficient and uniform cooking.

• PTC Heating: The appliance uses PTC (Positive Temperature Coefficient) heating, which automatically adjusts power to save energy and ensures 360-degree fast uniform heating, keeping food evenly cooked.
• Micro-Pressure Penetration: Equipped with 8-holes for micro-pressure penetration, promoting water vapor circulation for evenly heated food.

Diagram illustrating the 360-degree uniform heating technology and the 8-holes micro-pressure penetration for efficient cooking.

5.2 Cooking Functions

This electric lunch box is highly versatile, capable of preparing a variety of dishes:

• Rice Cooking: Add rice and water to the designated bowl. Place it in the main unit and start the cooking cycle.
• Soup/Stew Preparation: Place ingredients for soup or stew in the soup pot. The appliance is excellent for cooking herbal soups, stews, or bird's nest with little or no supervision needed.
• Steaming Vegetables/Dishes: Place vegetables or other dishes in the appropriate bowls for steaming.
• Egg Steaming: Use the provided egg rack to steam eggs.
• Dessert/Congee: Prepare various desserts or baby congee with ease.

The electric lunch box in use, demonstrating its capacity to hold separate bowls for rice and soup, allowing for a complete meal.

5.3 Timing and Preset Functions

The intelligent control system allows for timing and preset functions, offering convenience for meal preparation.

• 6-Hour Preset: You can set a delay timer for up to 6 hours, allowing you to prepare ingredients in advance and have your meal ready at a specific time.
• Automatic Insulation: After cooking is complete, the appliance will automatically enter an insulation state to keep food warm and fresh.
• Preheat Function: A preheat function is available to warm up food quickly.

Examples of using the 6-hour preset function for breakfast, lunch, and afternoon tea, demonstrating how to schedule meals.

Illustration of the preheat function and how the appliance automatically transitions to an insulation state after cooking to keep food warm.

5.4 Vacuum & Double Seal for Freshness

The lunch box is designed to preserve moisture and taste, and keep food fresh for longer periods.

• Preserving Moisture and Taste: After food is cooked, the appliance will auto-insulate, reducing water loss and maintaining freshness.
• Vacuum and Seal: The vacuum rod allows for extraction of excess air, creating a vacuum seal to preserve freshness.

Visual explanation of how the lunch box preserves moisture and taste, and the mechanism of vacuum and double sealing for extended freshness.

6. Maintenance and Cleaning

Regular cleaning and maintenance will prolong the life of your Bear DFH-A20D1 Electric Lunch Box.

1. Unplug Before Cleaning: Always unplug the appliance from the power outlet and allow it to cool down completely before cleaning.
2. Cleaning Bowls and Lids: The 304 food-grade stainless steel bowls and their lids can be washed with warm soapy water. Rinse thoroughly and dry immediately to prevent water spots. They are generally dishwasher-safe, but hand washing is recommended for longevity.
3. Cleaning Main Unit: Wipe the exterior of the main unit (PP material outer shell) with a soft, damp cloth. For stubborn stains, use a mild detergent. Do not use abrasive cleaners or scouring pads.
4. Cleaning Heating Plate: After each use, wipe the heating plate at the bottom of the main unit with a damp cloth to remove any food residue or water stains. If mineral deposits accumulate, a solution of vinegar and water can be used to gently scrub and remove them, followed by a clean water rinse and thorough drying.
5. Storage: Ensure all parts are completely dry before storing the appliance. Store in a cool, dry place away from direct sunlight.

7. Troubleshooting

If you encounter issues with your Bear DFH-A20D1 Electric Lunch Box, refer to the following common problems and solutions:

If the problem persists after attempting these solutions, please contact Bear customer support for further assistance.

8. Specifications

Visual representation of product dimensions and key specifications like power and capacity.

9. Warranty and Support

For warranty information and customer support, please refer to the documentation provided at the time of purchase or contact your retailer. Keep your purchase receipt as proof of purchase for any warranty claims.

For technical assistance or inquiries, please contact Bear customer service through their official website or the contact details provided with your product.
