Product Overview
The Spectra 9 Plus is a portable and rechargeable electric breast pump designed to provide comfortable and efficient milk expression. It features Natural Nursing Technology to mimic natural breastfeeding and offers personalized settings for optimal comfort.
Image: Spectra 9 Plus pump unit with digital display and control buttons.
Package Contents
Your Spectra 9 Plus package includes the following components:
Image: All components included with the Spectra 9 Plus: 9 Plus pump, 24mm breast flanges, tubing, duckbill valves, backflow protectors, wide neck storage bottles, and 9V charger.
- Spectra 9 Plus Pump Unit
- 2 x 24mm Breast Flanges
- 2 x Tubing
- 2 x Duckbill Valves
- 2 x Backflow Protectors
- 2 x Wide Neck Storage Bottles
- 1 x 9V Charger
Setup
Initial Charging
Before first use, ensure the pump unit is fully charged. Connect the power cord to the pump unit and plug it into a power outlet. The battery indicator on the display will flash while charging. A full charge is indicated when the battery icon is solid.
Assembling the Pump Kit
- Attach the duckbill valve firmly to the bottom of the breast flange.
- Connect the backflow protector to the top of the breast flange.
- Screw the wide neck storage bottle onto the bottom of the breast flange assembly.
- Connect one end of the tubing to the backflow protector and the other end to the port on the top of the pump unit. For single pumping, ensure the unused port is capped. For double pumping, remove the cap and connect the second tubing.
Video: A detailed guide on assembling the Spectra 9 Plus pump, including connecting the power cord, attaching tubing, and setting up for single or double pumping.
Operating the Pump
Power On/Off
Press the power button (green circle) to turn the pump on. The display will illuminate. To turn off, press the power button again.
Modes and Vacuum Adjustment
The Spectra 9 Plus offers two primary modes: Massage Mode and Expression Mode. You can switch between these modes using the 'Massage' button (three waves icon).
- Massage Mode: This mode simulates the natural suckling of a baby to help initiate let-down. You can adjust the vacuum level from L1 to L5 using the '+' and '-' buttons.
- Expression Mode: Once let-down occurs, switch to Expression Mode for milk collection. You can adjust the vacuum level from L1 to L10 using the '+' and '-' buttons.
Video: Demonstration of the Spectra 9 Plus pump's operation, including switching between massage and expression modes and adjusting vacuum levels.
Image: The Spectra 9 Plus pump unit shown on a desk, highlighting its compact size and digital display.
Portability and Quiet Operation
The Spectra 9 Plus is designed for on-the-go use, featuring a compact and lightweight design with a built-in rechargeable battery. Its ultra-quiet motor ensures discreet pumping sessions.
Image: The Spectra 9 Plus pump unit next to a passport, emphasizing its suitability for travel.
Image: A user discreetly pumping with the Spectra 9 Plus, highlighting its quiet operation.
Maintenance
Cleaning and Sterilization
All parts of the Spectra 9 Plus that come into contact with breast milk are made from BPA/DEHP-free materials. It is crucial to clean and sterilize these parts regularly to maintain hygiene and pump performance.
- Disassemble all parts that come into contact with milk after each use.
- Wash thoroughly with warm soapy water.
- Rinse well with clean water.
- Sterilize by boiling for 5 minutes or using a steam sterilizer.
- Allow parts to air dry completely before reassembling or storing.
Image: Text indicating all Spectra Baby plastic or silicone parts are BPA free, with a leaf icon.
Replacing Parts
Regular replacement of certain parts, such as duckbill valves, is recommended to ensure optimal pump performance and suction strength. Refer to the user guide for recommended replacement schedules.
Troubleshooting
If you encounter issues with your Spectra 9 Plus pump, consider the following common solutions:
- No Suction or Weak Suction:
- Check that all pump parts are correctly assembled and securely connected.
- Inspect duckbill valves for tears or wear; replace if necessary.
- Ensure tubing is not kinked or damaged.
- Verify that the backflow protector is properly sealed.
- Pump Not Turning On/Charging:
- Ensure the power adapter is securely plugged into both the pump and the wall outlet.
- Check if the power outlet is functional.
- Allow sufficient time for the battery to charge.
- Unusual Noises:
- While the pump is designed to be quiet, any new or loud noises may indicate a loose connection or a part needing replacement. Reassemble all parts and test again.
For further assistance, please refer to the official user guide or contact customer support.
Specifications
| Feature | Detail |
|---|---|
| Model Number | MM011343 |
| Brand | SPECTRA |
| Operation Mode | Electric |
| Special Feature | Portable, Painless |
| Included Components | Bottle, Breast Flange, Valve |
| Product Dimensions | 7.9 x 7.9 x 6.7 inches; 9.92 ounces |
| Batteries | 1 Lithium Ion batteries required (included) |
| Manufacturer Recommended Age | 0 months and up |
Warranty & Support
Spectra Baby USA is committed to supporting mothers in their breastfeeding journeys. We are Moms, we are Nurses, we understand.
Image: Text stating 'Made For Moms, By Moms' with the Spectra logo.
For detailed warranty information and customer support, please refer to the official user guide provided with your product or visit the Spectra Store on Amazon.
Video: An overview of the Spectra brand, emphasizing their commitment to supporting mothers.
