Great Northern Popcorn Foundation 8oz Popcorn Machine with Cart User Manual

Introduction

Thank you for choosing the Great Northern Popcorn Foundation 8oz Popcorn Machine with Cart. This manual provides essential information for the safe and efficient operation, assembly, maintenance, and troubleshooting of your new popcorn machine. Please read all instructions carefully before use and retain this manual for future reference.

Important Safety Instructions

To reduce the risk of fire, electric shock, or injury, always follow these basic safety precautions:

• Read all instructions before operating the appliance.
• Do not touch hot surfaces. Use handles or knobs.
• To protect against electrical hazards, do not immerse cord, plugs, or the appliance in water or other liquid.
• Close supervision is necessary when any appliance is used by or near children.
• Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts.
• Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or has been damaged in any manner.
• The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.
• Do not use outdoors.
• Do not let cord hang over edge of table or counter, or touch hot surfaces.
• Do not place on or near a hot gas or electric burner, or in a heated oven.
• Extreme caution must be used when moving an appliance containing hot oil or other hot liquids.
• Always attach plug to appliance first, then plug cord into the wall outlet. To disconnect, turn any control to "off", then remove plug from wall outlet.
• Do not use appliance for other than intended use.
• A short power-supply cord is provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord.
• Extension cords may be used if care is exercised in their use. If an extension cord is used, the marked electrical rating of the extension cord should be at least as great as the electrical rating of the appliance.
• The cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over.

Package Contents

Please verify that all components are present and undamaged upon opening the package:

• Popcorn Popper Unit (8oz kettle)
• Detachable Cart with 15.5-inch bicycle-style wheels
• Storage Cabinet (integrated into cart)
• Large Working Shelf (foldable)
• Measuring Cups
• Popcorn Scoop
• 25 Popcorn Bags
• 3 Popcorn Buckets

Image: Contents of the storage cabinet, including measuring cups, scoop, popcorn bags, and buckets.

Assembly and Setup

The Great Northern Popcorn Foundation machine is designed for straightforward assembly. No additional tools are typically required.

1. Unpack Components: Carefully remove all parts from the packaging.
2. Assemble Cart Base: Attach the wheels to the cart base according to the diagrams provided in the separate assembly guide (if applicable). Ensure all connections are secure.
3. Attach Popper Unit: Place the popcorn popper unit securely onto the cart. The unit can also be used independently on a countertop if desired.
4. Install Side Shelf: Attach the foldable side shelf to the designated brackets on the cart. Ensure it can be securely extended and folded.


Image: The foldable side shelf in its extended position, providing a working surface.


Image: Close-up view of the bracket mechanism for attaching the side shelf to the cart.
5. Kettle Connection: Ensure the kettle is properly seated and the power cord for the kettle is connected to the receptacle inside the popper unit.


Image: Rear view of the popcorn popper unit, illustrating the kettle's position and electrical connection point.

6. Placement: Position the assembled machine on a stable, level surface, away from water sources.
7. Power Connection: Plug the machine into a standard 120V electrical outlet.

Operating Instructions

This popcorn machine features a 3-switch design for independent control of its functions.

Image: Control panel with three switches for kettle heater, stirrer, and warming light.

1. Preparation: Ensure the kettle is clean and dry.
2. Add Oil: Add the recommended amount of popcorn oil (e.g., coconut oil) to the kettle.
3. Preheat Kettle: Turn on the Kettle Heater switch. Allow the kettle to preheat for 3-5 minutes.
4. Add Kernels: Once preheated, add 8 ounces of popcorn kernels to the kettle.
5. Start Stirrer: Turn on the Stirrer switch to ensure even popping.
6. Activate Warming Light: Turn on the Warming Light switch to keep popped corn warm and illuminated.


Image: Popcorn kernels expanding and popping within the stainless-steel kettle.

7. Popping Process: Popcorn will begin to pop and fall into the main chamber. The machine can produce up to 3 gallons (48 cups) per batch.
8. Empty Kettle: Once popping slows significantly, turn off the Kettle Heater and Stirrer switches. Carefully tilt the kettle to empty any remaining popcorn.
9. Serve: Use the provided scoop to serve popcorn into bags or buckets.

Note: For optimal results, use high-quality popcorn kernels and oil. Do not overfill the kettle.

Maintenance and Cleaning

Regular cleaning ensures optimal performance and longevity of your popcorn machine.

1. Unplug and Cool: Always unplug the machine from the power outlet and allow all hot surfaces to cool completely before cleaning.
2. Empty Reject Tray: The reject kernel tray at the bottom collects un-popped kernels. Slide it out and dispose of the contents. Clean the tray with a damp cloth.
3. Clean Interior: Wipe down the interior of the machine, including the tempered glass panels and the heated deck, with a damp cloth. For stubborn grease, a mild, food-safe detergent can be used, followed by wiping with a clean, damp cloth.
4. Clean Kettle: The stainless-steel kettle can be wiped clean with a damp cloth. For thorough cleaning, it may be detached. Do not immerse the kettle's electrical components in water.

Image: Front view of the popper unit, highlighting the stainless-steel kettle and interior warming light, both accessible for cleaning.
5. Exterior Cleaning: Wipe the exterior surfaces of the machine and cart with a damp cloth.
6. Storage: Store the machine in a clean, dry place. The cart's storage cabinet can be used for accessories.

Caution: Do not use abrasive cleaners or scouring pads, as they may scratch surfaces. Ensure all parts are dry before next use.

Troubleshooting

Product Specifications

• Model: 6127 All Star GNP-800
• Brand: Great Northern Popcorn Company
• Capacity: 8 ounces (per batch)
• Output: Up to 3 gallons (48 cups) per batch
• Power: 850 Watts, 120 Volts
• Warming Light: 60 Watts
• Materials: Tempered Glass, Stainless-Steel, Metal (Alloy Steel)
• Dimensions (L x W x H): 26.4” x 17.7” x 59.6” (67.06 cm x 44.96 cm x 151.38 cm)
• Item Weight: 49 lbs (22.23 kg)
• Included Components: Popcorn Popper, Detachable Cart, Measuring Cups, Scoop, 25 Popcorn Bags, 3 Popcorn Buckets
• Color: Black Floral All-Star
• UPC: 610708146100

Image: Full view of the Great Northern Popcorn Foundation 8oz Popcorn Machine with Cart in black.

Warranty and Customer Support

For warranty information, product support, or to inquire about replacement parts, please refer to the manufacturer's official website or contact their customer service department directly. Contact details are typically found on the product packaging or the Great Northern Popcorn Company website.

Manufacturer: Great Northern Popcorn Company
