1. Introduction
1.1. Product Overview
Thank you for choosing a Franke kitchen sink. This product is designed for durability and functionality, enhancing your kitchen space. The Franke Basis BFG 651-78 is a built-in Fragranit sink featuring a Glacier (white) finish. It is designed to fit into base cabinets starting from 60 cm wide and includes a stainless steel drainer.
Image: Franke Basis BFG 651-78 Glacier Granit Sink. This image shows the overall design of the sink with its two bowls and integrated drainer area.
Image: Example installation of a Franke Basis BFG 651-78 sink in Stone Grey color. This image is for illustrative purposes only; the product described in this manual is in Glacier (white) finish.
2. Installation Instructions
Professional installation is recommended. Ensure all local plumbing codes are followed.
2.1. Required Tools and Materials
- Jigsaw or appropriate cutting tool
- Silicone sealant
- Measuring tape and pencil
- Screwdriver
- Drill
- Safety glasses and gloves
2.2. Cabinet Requirements
This sink is suitable for base cabinets with a minimum width of 60 cm.
2.3. Cutting the Countertop Opening
Refer to the provided template (if included with your sink) or the technical drawing for precise cutout dimensions.
Image: Technical drawing showing the dimensions for the Franke Basis BFG 651-78 sink cutout. The overall sink dimensions are 780mm x 500mm, with specific measurements for bowl placement and corner radii.
- Place the sink upside down on the countertop in the desired position.
- Trace the outline of the sink onto the countertop.
- Measure and mark the inner cutting line, typically 8-10mm inside the traced outline, or use the provided template.
- Carefully cut the opening using a jigsaw.
- Seal the cut edges of the countertop to prevent moisture damage.
2.4. Installing the Sink
- Apply a bead of silicone sealant around the edge of the cutout opening on the countertop.
- Carefully lower the sink into the opening.
- Secure the sink using the provided mounting clips from underneath the countertop. Tighten evenly.
- Connect the plumbing for the drain and faucet according to local codes. Ensure all connections are watertight.
The sink includes a stainless steel drainer.
Image: Stainless steel drainer basket, designed to fit into the smaller bowl of the Franke sink.
Image: Another view of the stainless steel drainer basket, identified as Abtropfbecken 1120250014.
If your model includes an eccentric drain control, install it as per the separate instructions provided with the drain kit.
Image: Close-up of an eccentric drain control knob, typically used to open and close the sink drain remotely.
3. Operation
Your Franke Fragranit sink is designed for daily kitchen use.
3.1. Water Flow
Use the faucet to control water flow and temperature. Ensure the drain stopper is open when filling the sink to prevent overflow.
3.2. Drain Usage
The sink features a grid-type drain. For models with an eccentric control, turn the knob to open or close the drain.
4. Care and Maintenance
Proper care will ensure the longevity and appearance of your Franke Fragranit sink.
4.1. Daily Cleaning
- Clean the sink daily with warm water and a mild dish soap.
- Use a soft cloth or sponge.
- Rinse thoroughly after cleaning to remove all soap residue.
- Dry the sink with a soft cloth to prevent water spots, especially in hard water areas.
4.2. Stain Removal
- For stubborn stains, use a non-abrasive cleaner specifically designed for granite or composite sinks.
- Avoid abrasive pads, steel wool, or harsh chemical cleaners (e.g., bleach, ammonia-based products) as they can damage the surface.
- For limescale deposits, use a diluted vinegar solution or a specialized limescale remover, then rinse thoroughly.
4.3. Preventing Damage
- Avoid dropping heavy or sharp objects into the sink, which can cause chips or cracks.
- Do not place hot pots or pans directly onto the sink surface without protection, as extreme temperature changes can cause thermal shock.
- Do not use the sink as a cutting surface.
- Avoid contact with strong acids or alkalis.
The sink's color is Glacier (white).
Image: Color sample for "Glacier" finish, described as a white base color with grey inclusions.
5. Troubleshooting
This section addresses common issues you might encounter.
5.1. Slow Draining
- Check for food debris or blockages in the drain strainer.
- If the blockage is further down, a plumbing snake or chemical drain cleaner (used sparingly and according to product instructions) may be required.
5.2. Water Spots/Limescale
- Ensure the sink is dried after each use.
- Use a diluted vinegar solution or a commercial limescale remover.
5.3. Surface Scratches
- Fragranit is highly scratch-resistant, but not scratch-proof. Minor surface marks may appear over time.
- For deeper scratches, consult a professional or Franke customer support.
6. Product Specifications
| Feature | Specification |
|---|---|
| Model Number | 114.0301.368 |
| Product Name | Franke Basis BFG 651-78 Glacier Granit Sink |
| Brand | FRANKE |
| Material | Fragranit (Sink), Stainless Steel (Drainer) |
| Color | Glacier (White) |
| Overall Dimensions (W x D) | 78 x 50 cm |
| Minimum Base Cabinet Width | 60 cm |
| Installation Type | Built-in |
| Weight | 18 Kilograms |
| Drain Type | Grid |
| Finish Type | Brushed (for stainless steel components) |
7. Warranty and Support
For warranty information and customer support, please refer to the official Franke website or contact your local Franke dealer. Keep your proof of purchase for warranty claims.
Manufacturer: FRANKE
ASIN: B00I9BJ94A
Date First Available: April 28, 2022
