1. Product Overview
The DOMO DO9070KR-M Meat Grinder Attachment is a versatile accessory designed to expand the capabilities of your compatible DOMO food processor. This attachment allows you to efficiently grind and mince various ingredients, including raw meat, bread, fruits, vegetables, and dried goods. Its robust stainless steel construction ensures durability and hygiene.
This attachment is specifically designed for use with the following DOMO food processor models:
- DO9070KR
- DO9071KR
- DO9072KR
- DO9073KR
- DO9074KR
- DO9075KR
- DO9076KR
- DO9077KR
- DO9078KR
- DO9079KR
- DO9170KR
Figure 1: The DOMO DO9070KR-M Meat Grinder Attachment securely connected to a compatible DOMO food processor.
2. Important Safety Instructions
WARNING: Failure to follow these safety instructions may result in electric shock, fire, or serious injury.
- Always ensure the food processor is unplugged before attaching, detaching, or cleaning the meat grinder.
- Keep hands and utensils away from moving parts during operation. Always use the food pusher provided.
- Do not attempt to grind bones or other hard, non-food items.
- Ensure all parts are correctly assembled before use.
- This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Children should be supervised to ensure that they do not play with the appliance.
- Do not immerse the motor unit of the food processor in water or any other liquid.
- Clean all parts thoroughly before first use and after each subsequent use.
3. Package Contents and Components
Before first use, unpack all components and verify that all items are present and undamaged. Refer to Figure 2 for an illustration of the main components.
Figure 2: All components of the DOMO DO9070KR-M Meat Grinder Attachment laid out. This includes the main housing, auger, blade, various grinding discs, and food pusher.
Typical components include:
- Main Grinder Housing
- Auger (feeding screw)
- Cutting Blade
- Grinding Discs (Fine, Medium, Coarse)
- Retaining Ring
- Food Tray
- Food Pusher
4. Setup and Assembly
Follow these steps to assemble the meat grinder attachment onto your DOMO food processor:
- Ensure Power Off: Make sure your DOMO food processor is unplugged from the power outlet.
- Attach Grinder Housing: Locate the attachment port on your food processor. Insert the main grinder housing into the port, twisting or securing it according to your food processor's specific instructions until it is firmly in place.
- Insert Auger: Place the auger (feeding screw) into the grinder housing, ensuring the shaft aligns with the drive mechanism of the food processor.
- Position Blade: Place the cutting blade onto the auger shaft, ensuring the sharp edges face outwards towards the grinding disc.
- Select Grinding Disc: Choose the desired grinding disc (fine, medium, or coarse) based on your recipe. Place it over the cutting blade.
- Secure Retaining Ring: Screw the retaining ring onto the end of the grinder housing until it is hand-tight. Do not overtighten.
- Attach Food Tray: Place the food tray on top of the grinder housing.
- Final Check: Verify that all components are securely assembled before plugging in the food processor.
Figure 3: The fully assembled DOMO DO9070KR-M Meat Grinder Attachment, ready for use.
5. Operating Instructions
Once the attachment is assembled and securely connected to your food processor, you can begin processing ingredients.
- Prepare Ingredients: Cut ingredients (meat, vegetables, etc.) into pieces that will fit easily into the feed tube. Remove any bones, gristle, or tough sinews from meat.
- Place Receptacle: Position a bowl or container under the output of the grinder to collect the processed ingredients.
- Power On: Plug in your DOMO food processor and turn it on to the appropriate speed setting as recommended in your food processor's manual for attachments.
- Feed Ingredients: Carefully place prepared ingredients into the food tray. Use the food pusher to gently guide the ingredients down the feed tube. Never use your fingers or other utensils to push food into the grinder.
- Process: Allow the grinder to process the ingredients. Do not overload the machine. If the grinder jams, turn off the food processor immediately, unplug it, and clear the obstruction.
- Finish: Once all ingredients are processed, turn off the food processor and unplug it.
Tip:
- For best results when grinding meat, ensure the meat is chilled but not frozen.
- Experiment with the three grinding discs to achieve your desired consistency for different recipes.
6. Cleaning and Maintenance
Regular cleaning ensures optimal performance and extends the lifespan of your meat grinder attachment.
- Disconnect Power: Always unplug the food processor from the power outlet before cleaning.
- Disassemble: Carefully disassemble the meat grinder attachment in reverse order of assembly.
- Remove Residue: Use a brush or spatula to remove any large food residues from all parts.
- Wash Parts: Wash all removable parts (grinder housing, auger, blade, discs, retaining ring, food tray, food pusher) in warm, soapy water. Rinse thoroughly.
- Dry Thoroughly: Dry all parts immediately and thoroughly to prevent rust, especially the metal components. Air drying is not recommended for metal parts.
- Storage: Store the clean, dry components in a safe place.
CAUTION: The cutting blade is sharp. Handle with extreme care during cleaning.
7. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Grinder is jammed or stops working. | Overloaded with ingredients; hard object (e.g., bone) stuck; ingredients not cut small enough. | Turn off and unplug the food processor. Disassemble the grinder and remove the obstruction. Cut ingredients into smaller pieces. |
| Meat is not grinding properly (mushing instead of mincing). | Meat is too warm; blade is dull or incorrectly installed; wrong grinding disc selected. | Ensure meat is well-chilled. Check blade orientation and sharpness. Select a finer grinding disc if necessary. |
| Attachment is difficult to assemble/disassemble. | Parts are not aligned correctly; food residue build-up. | Refer to the assembly instructions. Ensure all parts are clean and dry. Do not force parts. |
8. Product Specifications
- Model: DO9070KR-M
- Brand: Domo
- Material: Stainless Steel
- Color: Silver
- Item Weight: Approximately 1.72 kg (3.79 lbs)
- Attachment Dimensions (approximate):
- Length: 25.5 cm (10 inches)
- Width of Casing: 17 cm (6.7 inches)
- Compatibility: Designed for DOMO Food Processor models DO9070KR, DO9071KR, DO9072KR, DO9073KR, DO9074KR, DO9075KR, DO9076KR, DO9077KR, DO9078KR, DO9079KR, DO9170KR.
- International Article Code (EAN/UPC): 05411397010148
9. Warranty and Support
This DOMO product is covered by a manufacturer's warranty against defects in materials and workmanship. Please refer to the warranty card included with your original food processor or visit the official DOMO website for detailed warranty terms and conditions specific to your region.
For technical support, spare parts, or service inquiries, please contact DOMO customer service or your authorized dealer. Ensure you have your model number (DO9070KR-M) and proof of purchase available when contacting support.
Online Support: Visit www.domo-elektro.be for product information, FAQs, and contact details.
