Introduction
This instruction manual provides essential information for the proper installation, use, and maintenance of your new Honda TRX500 Foreman ATV Complete Seat. Please read this manual thoroughly before attempting installation or use to ensure safety and optimal performance. This seat is a genuine Honda replacement part designed for specific Honda TRX500 Foreman ATV models from 2005 to 2011.
Safety Information
- Always wear appropriate safety gear, including gloves and eye protection, when performing maintenance or installation on your ATV.
- Ensure the ATV is turned off, the engine is cool, and the parking brake is engaged before beginning any work.
- If you are unsure about any step, consult a qualified service technician or refer to your ATV's official service manual.
- Keep all tools and small parts away from children and pets.
Package Contents
Upon opening the package, verify that all components are present and undamaged. The package should contain:
- One (1) Honda TRX500 Foreman ATV Complete Seat (Model Hengulus)
If any parts are missing or damaged, contact your retailer immediately.
Setup and Installation
Tools Required:
- Basic hand tools (e.g., wrench set, screwdriver, as needed for your specific ATV model's seat removal mechanism).
Installation Steps:
- Prepare the ATV: Park your Honda TRX500 Foreman ATV on a level surface. Turn off the engine and engage the parking brake.
- Remove the Old Seat: Locate the seat release mechanism on your ATV. This is typically a latch or a bolt located at the rear or side of the seat. Disengage the latch or unbolt the securing hardware. Carefully lift and remove the old seat from the ATV frame.
- Inspect the Mounting Area: Clean any dirt or debris from the ATV's seat mounting area. Inspect the frame for any damage or wear that might affect the new seat's installation.
- Position the New Seat: Align the front hooks or tabs of the new Honda complete seat with the corresponding slots on the ATV frame. Gently lower the seat into place, ensuring the rear mounting points align.
- Secure the New Seat: Press down firmly on the rear of the seat until the latch engages, or re-install any bolts or securing hardware that were removed in step 2. Ensure the seat is fully seated and secure.
- Verify Installation: Gently pull up on the seat to confirm it is securely attached and does not wobble. A properly installed seat will not move or lift easily.
This image displays the underside of the complete seat, highlighting the integrated mounting hardware and the molded foam base. Observe the attachment points and the securing bar, which are essential for proper installation onto your ATV frame.
Operating Instructions
While a seat does not have operational controls, proper use involves ensuring it is always securely fastened before operating the ATV. Regularly check the seat's attachment points for tightness and wear. Never operate the ATV with a loose or improperly installed seat, as this can lead to loss of control or injury.
Maintenance
Cleaning:
- Clean the seat regularly with mild soap and water.
- Avoid using harsh chemicals, abrasive cleaners, or solvents, as these can damage the vinyl material.
- Rinse thoroughly with clean water and allow to air dry completely before use or storage.
Inspection:
- Periodically inspect the seat for tears, cracks, or excessive wear in the vinyl.
- Check the integrity of the seat base and mounting hardware for any signs of damage or corrosion.
- Ensure all attachment points on the ATV frame are clean and free from obstruction.
Storage:
- When not in use for extended periods, store the ATV in a dry, covered area to protect the seat from prolonged exposure to UV rays and harsh weather conditions.
Troubleshooting
Seat Does Not Fit Correctly:
- Check Compatibility: Ensure the seat is the correct model for your 2005-2011 Honda TRX500 Foreman ATV.
- Verify Alignment: Re-check that the front hooks and rear mounting points are correctly aligned with the ATV frame.
- Inspect for Obstructions: Look for any debris or foreign objects preventing the seat from seating properly.
Seat Feels Loose After Installation:
- Re-engage Latch/Tighten Bolts: Ensure the seat's latch mechanism is fully engaged or that any securing bolts are tightened to the manufacturer's specifications.
- Inspect Latch/Hardware: Check the seat's latch and the ATV's receiving mechanism for wear or damage. Replace if necessary.
Specifications
- Brand: Honda
- Model Number: Hengulus
- Vehicle Service Type: ATV
- Fit Type: Vehicle Specific Fit (2005-2011 Honda TRX500 Foreman)
- Material: Vinyl
- Orientation: Driver's Side
- Item Weight: Approximately 9.03 Pounds
- Product Dimensions: Approximately 1 x 1 x 1 inches (packaging/shipping dimensions may vary)
Warranty and Support
This genuine Honda product is covered by Honda's standard warranty for replacement parts. For specific warranty details, claims, or technical support, please refer to your original ATV owner's manual or contact an authorized Honda dealer. Keep your purchase receipt as proof of purchase.
For further assistance, you may visit the official Honda Powersports website or contact their customer service department.
