Vita Avalon 10' x 10' Adjustable Louvered Vinyl Pergola Instruction Manual

Product Overview

The Vita Avalon 10' x 10' Adjustable Louvered Vinyl Pergola is designed to enhance your outdoor living space. This pergola features a three-panel adjustable louver system, allowing for customizable shade. Constructed from premium weather-resistant vinyl, it offers durability and requires minimal maintenance. The louver panels can be adjusted 45 degrees in both directions, providing flexibility to manage sun exposure throughout the day.

Setup and Installation

Proper installation is crucial for the stability and longevity of your Avalon pergola. Please review the following instructions carefully. Note that additional materials are required for installation and must be purchased separately, depending on your chosen mounting method.

In-Ground Installation

For installing the pergola directly into the ground, the following materials are required:

• Pressure-Treated Wood Posts (4) – 4x4x12’ (10.2 cm x 10.2 cm x 365.8 cm)
• Pressure-Treated Boards (10) – 2x6x10’ (5 cm x 15 cm x 305 cm)
• Concrete Ready Mix (4)

Concrete Patio or Deck Installation (Bolt Down)

If mounting the pergola onto an existing concrete patio or deck (not intended for patio stones or pavers), the following materials are needed:

• Bolt Down Bracket System (Item Code: VA80205)
• Pressure-Treated Wood Posts (4) – 4x4x8’ (10.2 cm x 10.2 cm x 243.8 cm)
• Pressure-Treated Boards (10) – 2x6x10’ (5 cm x 15 cm x 305 cm)
• Wood Shims (32) – ½” x 3 ½” x 12” (1.3 cm x 9 cm x 30.5 cm)
• Cement Screws, Countersunk Head (12) – ¼” x 2 ¾” (0.64 cm x 7 cm)
• Concrete Drill Bit (1) – 3/16” (0.48 cm), min. 3” long

Deck Installation with Accessible Underside

For mounting the pergola onto a deck with an accessible underside, the following materials are required:

• Bolt Down Bracket System
• Pressure-Treated Wood Posts (4) – 4x4x8’ (10.2 cm x 10.2 cm x 243.8 cm)
• Pressure-Treated Boards (10) – 2x6x10’ (5 cm x 15 cm x 305 cm)
• Wood Shims (32) – ½” x 3 ½” x 12” (1.3 cm x 9 cm x 30.5 cm)
• Bolts and Nuts, Countersunk Head (12) – ¼” (0.64 cm), length depends on blocking material
• Washers (12) – ¼” (0.64 cm)
• Wood Drill Bit (1) – ¼” (0.64 cm), min. 3” long
• Wood Blocks (4) – 2x10” (5.1 cm x 25 cm), to be secured between deck joists

Operating Instructions

The Avalon pergola features an adjustable louver system for controlling sun and shade. The louver panels can be turned 45 degrees in both directions, allowing you to customize the amount of sunlight filtering through. When fully closed, the system provides up to 90% shade coverage. Adjust the louvers as needed to create your desired outdoor ambiance.

Maintenance

The Vita Avalon Pergola is designed for low maintenance. Crafted from durable, weather-resistant vinyl, it is easy to clean. Regular cleaning with water and a mild detergent is recommended to maintain its appearance and ensure its longevity. Avoid using abrasive cleaners or harsh chemicals that could damage the vinyl surface.

Specifications

Warranty Information

The Vita Avalon Pergola is covered by a 20-year warranty against manufacturing defects. The adjustable louver assembly is covered by a 5-year warranty. Please retain your proof of purchase for warranty claims.

Support

For further assistance, technical support, or to inquire about replacement parts, please contact Vita customer support. You can find contact information and additional resources on the official Vita website.
