Important Safety Information
Please read and understand all instructions before using the laminator. Keep this manual for future reference.
- Do not operate the laminator if the power cord or plug is damaged.
- Keep the laminator away from water or other liquids.
- Do not insert metal objects into the laminator.
- Ensure proper ventilation around the machine during operation.
- Unplug the laminator when not in use or before cleaning.
- This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Product Overview
The Amazon Basics 9-Inch Thermal Laminator is designed for home, office, or classroom use, providing high-quality lamination for various document sizes.
Figure 1: Front view of the Amazon Basics 9-Inch Thermal Laminator Machine, showing the feed slot and branding.
Key Features:
- Laminates documents up to 9 inches wide.
- Two heat settings: 3 mil and 5 mil.
- Quick 4-minute warm-up time.
- Jam release lever for easy clearing.
- Compact design.
Setup
Unpacking:
Carefully remove the laminator from its packaging. Retain the packaging for future storage or transport.
Figure 2: The laminator machine as it appears inside its frustration-free packaging.
Placement:
Place the laminator on a flat, stable, and heat-resistant surface. Ensure there is adequate space around the machine for proper ventilation and for documents to exit the rear.
Power Connection:
Plug the power cord into a standard electrical outlet. The power switch is located on the side of the unit.
Figure 3: Close-up view of the power switch, 3mil/5mil heat settings, and release lever on the side of the laminator.
Operating Instructions
Laminating a Document:
Power On and Warm-up:
Turn the power switch to the "On" position. The "Ready" indicator light will illuminate once the machine has warmed up (approximately 4 minutes).
Select Heat Setting:
Choose the appropriate heat setting based on the laminating pouch thickness:
- 3 mil: For normal documents, photos, and card stock.
- 5 mil: For thinner papers.
Prepare Document:
Place the document inside a laminating pouch, ensuring it is centered and there is an even border around the edges. Use the included 3 mil thick, 8.9 by 11.4 inch laminating pouches or any compatible 3 mil or 5 mil pouch.
Figure 4: Example of laminating recipe cards, showing the document being fed into the laminator.
Insert Pouch:
Carefully insert the sealed edge of the laminating pouch into the laminator's feed slot. The machine will automatically pull the pouch through.
Figure 5: A calendar page being laminated, demonstrating the machine's ability to handle various document types.
Retrieve Laminated Document:
Once the pouch exits the rear of the machine, allow it to cool on a flat surface before handling to ensure proper sealing.
Figure 6: A collection of laminated items, including recipe cards, ID badges, and a calendar, showcasing the versatility of the laminator.
Maintenance
Cleaning:
Ensure the laminator is unplugged and completely cool before cleaning. Wipe the exterior with a soft, damp cloth. Do not use abrasive cleaners or solvents.
Roller Cleaning (Optional):
Periodically, you may run a cleaning sheet (available separately) through the laminator to remove any adhesive residue from the rollers.
Storage:
Store the laminator in a cool, dry place when not in use. Ensure the power cord is neatly wrapped and not kinked.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Laminator does not turn on. | Not plugged in; power switch off; no power at outlet. | Check power cord connection; ensure power switch is "On"; test outlet with another device. |
| Pouch jams in the machine. | Pouch inserted incorrectly; pouch too thick; foreign object. | Press the release lever to clear the jam. Ensure pouch is inserted sealed edge first and is within specified thickness (3 or 5 mil). |
| Lamination is cloudy or bubbly. | Incorrect heat setting; machine not fully warmed up; low-quality pouch. | Ensure correct heat setting (3 mil for normal, 5 mil for thinner); wait for "Ready" light; use high-quality laminating pouches. |
| Lamination is not sealed properly. | Incorrect heat setting; machine not fully warmed up; document too thick for pouch. | Verify heat setting; wait for "Ready" light; ensure document fits pouch with adequate border. |
Specifications
| Feature | Detail |
|---|---|
| Model Number | PL9-US |
| Laminating Width | Up to 9 inches |
| Heat Settings | 3 mil, 5 mil |
| Warm-up Time | Approximately 4 minutes |
| Number of Rollers | 2 |
| Weight | 1.2 kg |
| Power Supply | Standard AC |
Warranty and Support
For warranty information and customer support, please visit the official Amazon Basics website or contact Amazon customer service directly.
Online Support: Amazon Basics Store
Note: Reading the full user manual is recommended prior to the first use of this product.
