Lokar CINB-1782 LED Boot Indicator for 700-R Transmission Instruction Manual

1. Introduction

The Lokar CINB-1782 Vertical Rectangular Cable Operated LED Boot Indicator is designed to provide clear, illuminated gear position indication for vehicles equipped with a 700-R Transmission. This unit integrates seamlessly with Lokar transmission shifters and features a programmable circuit board, a neutral safety switch, and a backup light circuit for enhanced functionality and safety. Constructed from CNC machined 6061-T6 billet aluminum, it offers durability and a precise fit. The cable-operated design allows for flexible mounting options, and color-coded wiring simplifies the installation process.

2. Safety Information

Read all instructions carefully before installation. Failure to follow these instructions may result in property damage, personal injury, or product malfunction.

• Always disconnect the vehicle's battery before beginning any electrical work to prevent electrical shock or short circuits.
• Wear appropriate personal protective equipment, including safety glasses, during installation.
• Ensure the vehicle is securely supported on jack stands if working underneath.
• Verify all connections are secure and properly insulated to prevent hazards.
• Professional installation is recommended for optimal performance and safety.
• This product is intended for automotive use only.

3. Package Contents

Please verify that all components listed below are present in your package before proceeding with installation. If any parts are missing or damaged, contact Lokar customer service.

• LED Boot Indicator Unit
• Cable Assembly
• Control Module / Circuit Board
• Wiring Harness (Color-Coded)
• Mounting Bracket(s)
• Mounting Hardware (Bolts, Nuts, Washers, Spacers)
• Relay (for backup light circuit)

Figure 3.1: Main components of the Lokar CINB-1782 kit, including the LED indicator unit, cable assembly, and control module.

Figure 3.2: Included mounting hardware, bolts, washers, and the relay for the backup light circuit.

4. Setup and Installation

4.1 Pre-Installation Checklist

• Ensure the vehicle's battery is disconnected.
• Gather necessary tools: basic hand tools, wire strippers, crimpers, multimeter, drill (if mounting holes are required).
• Identify a suitable mounting location for the LED boot indicator and the control module.

4.2 Mounting the Indicator and Control Module

1. Determine the desired location for the LED boot indicator within your vehicle's shifter boot area. The cable-operated design offers flexibility.
2. Secure the indicator unit using the provided mounting brackets and hardware. Ensure it is firmly attached and does not interfere with shifter operation.
3. Route the cable assembly from the indicator unit to the transmission, ensuring it is clear of moving parts, exhaust, and sharp edges. Secure the cable at regular intervals.
4. Mount the control module in a dry, protected location, typically under the dashboard or in the console, using appropriate fasteners.

4.3 Wiring Instructions

The CINB-1782 features color-coded wiring for straightforward installation. Refer to the specific wiring diagram provided with your product for exact connections. General connections include:

• Power (12V Switched): Connect to a fused 12-volt ignition switched power source.
• Ground: Connect to a reliable chassis ground point.
• Neutral Safety Switch: Integrate into the vehicle's starter circuit to prevent engine start unless the transmission is in Park or Neutral.
• Backup Light Circuit: Connect to the vehicle's backup light circuit, utilizing the provided relay if necessary, to activate backup lights when reverse gear is selected.
• Gear Position Inputs: Connect the individual gear position wires from the control module to the corresponding switches or sensors on your 700-R transmission. The programmable circuit board allows for calibration.

After all connections are made, re-connect the vehicle's battery and test the system.

5. Operating Instructions

Once properly installed and calibrated, the Lokar CINB-1782 LED Boot Indicator operates automatically. When the ignition is on and the transmission shifter is moved, the corresponding LED on the indicator will illuminate, clearly displaying the selected gear (e.g., Park, Reverse, Neutral, Drive, Low gears).

• The neutral safety switch function will prevent the engine from starting unless the shifter is in the Park or Neutral position.
• When Reverse gear is selected, the backup light circuit will activate, illuminating the vehicle's backup lights.

6. Maintenance

The Lokar CINB-1782 LED Boot Indicator is designed for long-term, maintenance-free operation. Periodic checks are recommended:

• Cleaning: Gently wipe the LED indicator display with a soft, damp cloth to remove dust or debris. Avoid abrasive cleaners.
• Cable Inspection: Periodically inspect the cable assembly for any signs of wear, fraying, or damage. Ensure it remains securely routed and fastened.
• Wiring Connections: Check all electrical connections for tightness and corrosion, especially after significant vehicle vibrations or environmental exposure.

7. Troubleshooting

If you experience issues with your Lokar CINB-1782 LED Boot Indicator, refer to the following common troubleshooting steps:

• Indicator Not Lighting Up:
  • Check power and ground connections to the control module.
  • Verify the vehicle's ignition is on.
  • Inspect the cable assembly for proper connection and movement.
  • Ensure the LED indicator unit is securely plugged into the control module.
• Incorrect Gear Indication:
  • Check the connections of the individual gear position wires to the transmission.
  • Refer to the product-specific calibration instructions for the programmable circuit board.
  • Ensure the cable assembly is not binding or misaligned.
• Neutral Safety Switch Not Functioning:
  • Verify the neutral safety switch wiring is correctly integrated into the starter circuit.
  • Ensure the shifter is fully engaged in Park or Neutral.
• Backup Lights Not Activating:
  • Check the wiring to the backup light circuit and the relay.
  • Ensure the transmission is fully engaged in Reverse.

If problems persist after performing these checks, contact Lokar technical support for further assistance.

8. Specifications

9. Warranty and Support

For specific warranty information regarding your Lokar CINB-1782 LED Boot Indicator, please refer to the documentation included with your purchase or visit the official Lokar website. For technical assistance, installation questions, or troubleshooting beyond this manual, please contact Lokar customer service directly.

Lokar Customer Service:
Refer to Lokar's official website for current contact information.
