Fellowes Professional Series Adjustable Depth Single Monitor Arm

1. Product Overview

The Fellowes Professional Series Adjustable Depth Single Monitor Arm (Model 8041601) is designed to enhance your workspace ergonomics and efficiency. This monitor arm allows for easy adjustment of your LCD monitor, providing optimal viewing control and helping to reduce eye, neck, and shoulder strain. It also helps to free up valuable desk space by elevating your monitor.

Key Features:

• Fully Adjustable: Elevates LCD monitors from 3.5 inches to 16.5 inches above the desk.
• Extended Reach: Offers a minimum reach of 2.5 inches to a maximum reach of 21.5 inches.
• Flexible Viewing Angles: Tilts up or down +/- 37 degrees and freely swings left or right with 360-degree rotation capability.
• Easy Mounting: Attaches to the desktop via a clamp or through a grommet hole.
• Tool-Free Installation: Mounts to surfaces up to 2.5 inches thick without requiring additional tools.
• VESA Compliant: Meets VESA mounting standards for broad compatibility.
• Weight Capacity: Safely holds LCD monitors up to 24 lbs.

2. Package Contents

Please ensure all components are present before beginning installation:

• Monitor Arm (main assembly)
• Desk Clamp
• Grommet Mount Hardware
• Mounting Screws for Monitor
• Instruction Manual

3. Setup and Installation

The Fellowes Professional Series Monitor Arm offers two primary installation methods: desk clamp or grommet mount. Both methods are designed for tool-free installation on surfaces up to 2.5 inches thick.

3.1. Choosing Your Mounting Method:

• Desk Clamp: Ideal for desks without existing grommet holes or when a non-permanent attachment is preferred.
• Grommet Mount: Suitable for desks with an existing grommet hole, providing a more integrated look.

3.2. Installation Steps:

1. Attach the Mount to Your Desk:
   • For Desk Clamp: Position the clamp on the edge of your desk. Tighten the screw until the mount is securely fastened to the desk surface.
   • For Grommet Mount: Insert the grommet hardware through the desk hole. Secure it from underneath the desk by tightening the provided nut.
2. Attach the Monitor Arm to the Mount: Slide the monitor arm assembly onto the vertical pole of the desk mount. Adjust the height to your initial preference and secure it using the locking mechanism.
3. Attach Your Monitor: Align the VESA mounting holes on the back of your monitor with the mounting plate on the arm. Use the provided screws to securely attach the monitor to the arm. Ensure the monitor is centered and stable.
4. Cable Management: Utilize the integrated cable management clips or channels on the monitor arm to route your display and power cables neatly. This helps to minimize cord clutter and maintain a clean workspace.

Image: The monitor arm securely mounted to a desk, illustrating the desk clamp and how a monitor is attached. Cables are neatly routed along the arm.

4. Operating and Adjustments

The Fellowes Professional Series Monitor Arm is designed for effortless adjustment to achieve your ideal viewing position. All adjustments can be made manually without tools once the monitor is mounted.

4.1. Adjusting Monitor Position:

• Height Adjustment: Loosen the height adjustment collar on the main pole, slide the arm up or down to the desired height (between 3.5 and 16.5 inches), and then re-tighten the collar.
• Depth/Reach Adjustment: Extend or retract the arm to achieve your preferred viewing distance. The arm offers a reach from 2.5 inches to 21.5 inches.
• Tilt Adjustment: Gently tilt the monitor screen up or down to reduce glare and optimize your viewing angle. The arm allows for +/- 37 degrees of tilt.
• Swivel/Pivot Adjustment: Rotate the monitor left or right (180 degrees pivot) or rotate the entire screen 360 degrees to switch between landscape and portrait orientations.
• Rotation Adjustment: The arm allows for 360-degree rotation of the monitor for easy screen sharing or orientation changes.

Image: Visual representation of the monitor arm's rotational, pivot, and tilt capabilities, including key dimensions for reach and height.

4.2. Official Product Video:

5. Specifications

6. Maintenance

To ensure the longevity and optimal performance of your Fellowes Monitor Arm, follow these simple maintenance guidelines:

• Cleaning: Wipe the monitor arm with a soft, damp cloth. Avoid using abrasive cleaners or solvents, as these may damage the finish.
• Check Connections: Periodically check all mounting screws and adjustment points to ensure they remain tight and secure. Re-tighten if necessary.
• Lubrication: No special lubrication is required for the moving parts.

7. Troubleshooting

If you encounter any issues with your monitor arm, please refer to the following common solutions:

• Monitor Sags or Drifts: Ensure all pivot and tilt tension screws are adequately tightened. Refer to the operating section for adjustment points.
• Arm is Loose on Desk: Check the desk clamp or grommet mount for tightness. Re-secure the mount to the desk surface.
• Difficulty Adjusting Height: Ensure the height adjustment collar is fully loosened before attempting to move the arm up or down.
• Cables are Tangled: Re-route cables through the integrated cable management system to prevent tangling and maintain a tidy appearance.

If the issue persists after attempting these solutions, please contact Fellowes customer support for further assistance.

8. Warranty and Support

This Fellowes product is covered by a manufacturer's warranty. For detailed warranty information, including terms, conditions, and how to make a claim, please refer to the warranty card included with your product or visit the official Fellowes website.

For technical support, replacement parts, or any other inquiries, please contact Fellowes customer service through their official channels.
