JERDON Wall-Mounted Makeup Mirror HL65CD Instruction Manual

Introduction

Thank you for choosing the JERDON HL65CD Wall-Mounted Makeup Mirror. This premium mirror is designed to provide clear, magnified reflection with integrated LED lighting, ideal for detailed grooming and makeup application. Featuring an 8-inch diameter, dual-sided 1X and 5X magnification, and a sleek chrome finish, this direct-wire mirror extends up to 14 inches from the wall for optimal positioning. Please read this manual thoroughly before installation and use to ensure safe and proper operation.

Safety Information

WARNING: This mirror is hardwired and requires professional installation. Do not attempt to install or repair the electrical components yourself. Always turn off the power at the circuit breaker before installing or removing the mirror. Be cautious when using the 5X magnification to avoid injury from sharp objects or sudden movements.

Features

• Wall-Mount Design: Modern chrome-finish mirror with a 14-inch extendable arm for flexible positioning. Direct wire installation ensures no exposed cords.
• LED Lighting: Features bright, long-lasting LED bulbs for optimal illumination during use.
• Dual Magnification: Offers 1X magnification for general viewing and 5X magnification for detailed tasks like tweezing or makeup application.
• 360-Degree Swivel: The mirror head rotates smoothly to switch between magnification levels and adjust viewing angles.
• Durable Construction: Designed with scratch-resistant finishes and durable hardware for long-lasting performance.

Figure 1: Key features of the HL65CD mirror, including adjustable arm, LED lighting, modern style, and direct wire.

Setup and Installation

The JERDON HL65CD mirror is designed for direct-wire wall mounting. This means it connects directly to your home's electrical system, requiring no visible power cords or plugs. For safety and proper function, professional installation by a qualified electrician is strongly recommended.

• Location Selection: Choose a mounting location that has an existing electrical junction box or where one can be safely installed. Consider the desired height for primary users, as the mirror's vertical position is fixed once mounted.
• Power Disconnection: Before any installation, ensure the power to the circuit is turned off at the main breaker.
• Mounting Plate Installation: Secure the mirror's mounting plate (4" x 5") to the wall over the junction box using the provided hardware. Ensure it is firmly attached to a stud or appropriate wall anchors.
• Wiring: Connect the mirror's electrical wires to the household wiring according to local electrical codes. This typically involves connecting live, neutral, and ground wires.
• Mirror Attachment: Attach the mirror unit to the mounting plate, ensuring all connections are secure and the mirror is stable.
• Power Restoration: Once installation is complete, restore power at the circuit breaker.

Figure 2: The JERDON HL65CD mirror in its wall-mounted position, showcasing its chrome finish and integrated lighting.

Figure 3: Detailed dimensions for installation, including the 8-inch mirror diameter, 4x5 inch mounting plate, and 14-inch extension arm.

Operating Instructions

• Powering On/Off: The mirror features a toggle switch located on the oval base of the wall mount. Flip the switch to turn the LED halo lighting on or off.
• Adjusting Magnification: The mirror head is dual-sided. Gently swivel the mirror 360 degrees to switch between the 1X (true image) and 5X (magnified) sides.
• Positioning the Mirror: The mirror is attached to an extendable arm that allows it to swing out and retract. Adjust the arm to bring the mirror closer or push it back against the wall when not in use. The arm also allows for horizontal pivoting to achieve the desired angle.

Figure 4: Demonstrates the two magnification levels: 1X for a standard view and 5X for close-up detail.

Figure 5: Examples of how the mirror can be used for various personal care activities.

Maintenance

• Cleaning the Mirror: Use a soft, lint-free cloth and a non-abrasive glass cleaner to wipe the mirror surface. Avoid harsh chemicals that may damage the finish.
• Cleaning the Finish: For the chrome finish, wipe with a soft, damp cloth. Do not use abrasive cleaners or pads, as these can scratch the surface.
• Bulb Replacement: The mirror uses a 25-watt replacement lightbulb (Jerdon model JPT25W). To replace the bulb, ensure the power is off at the circuit breaker, then carefully follow the instructions provided with the replacement bulb or consult a professional.

Troubleshooting

• Light is not bright enough: The integrated LED lighting is designed to provide supplementary illumination for detailed tasks. It is not intended to be the primary light source for your bathroom or vanity. Ensure adequate ambient lighting is available.
• Mirror feels unstable after installation: Ensure the mounting plate is securely fastened to a wall stud or appropriate heavy-duty anchors. If only two screws were used, consider adding more for increased stability, especially given the mirror's weight and adjustable arm.
• Mirror fogs up during showers: To prevent fogging, turn on the mirror's light a few minutes before taking a shower. The warmth from the bulb, combined with airflow openings, can help keep the mirror surface clear.
• Mounting plate holes do not align with electrical box: While designed for standard electrical boxes, minor adjustments or professional assistance may be required if alignment issues occur during installation.

Specifications

Warranty & Support

The JERDON HL65CD Wall-Mounted Makeup Mirror comes with a 1-year limited warranty that protects against any defects due to faulty material or workmanship. For warranty claims, technical support, or replacement parts, please contact JERDON customer service. Keep your purchase receipt as proof of purchase.
