Omega BMJ330 Mega Mouth Juicer Instruction Manual

1. Overview

The Omega BMJ330 Mega Mouth Juicer is a 350-watt commercial pulp-ejection-style juicer designed for efficient extraction of juice from fruits and vegetables. It features a powerful 1/2-horsepower induction motor, a heavy-duty stainless-steel blade, basket, and cover, and an oversized feed chute to accommodate larger produce portions. This juicer is engineered for quick and easy preparation of fresh, healthy beverages.

Figure 1.1: Front view of the Omega BMJ330 Mega Mouth Juicer.

2. Important Safety Instructions

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons, including the following:

• Read all instructions before operating the juicer.
• Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or has been dropped or damaged in any manner.
• Always ensure the juicer is properly assembled and the safety locking arm is securely in place before operating.
• Do not place fingers or other objects into the feed chute while the appliance is in operation. Use the food pusher provided.
• Always unplug the juicer from the outlet when not in use, before putting on or taking off parts, and before cleaning.
• Avoid contact with moving parts.
• Do not juice fruits with hard pits or large seeds (e.g., peaches, nectarines, mangoes) without removing the pits first, as this may damage the appliance.
• This appliance is for household use only.

3. Parts & Assembly

Before first use, wash all removable parts in warm, soapy water. Rinse thoroughly and dry. Ensure the motor base is unplugged from the power outlet.

3.1 Components

• Motor Base
• Juicer Cover
• Stainless-Steel Blade
• Stainless-Steel Filter Basket
• Pulp Collector
• Juice Pitcher (not included, use your own glass/container)
• Food Pusher

Figure 3.1: Key components of the Omega BMJ330 Juicer.

3.2 Assembly Steps

1. Place the motor base on a dry, level surface.
2. Insert the stainless-steel filter basket into the juicer cover. Ensure it is seated firmly.
3. Place the juicer cover assembly onto the motor base, aligning the spout with the juice outlet.
4. Raise the safety locking arm and secure it into the grooves on the juicer cover until it clicks into place. The juicer will not operate if the locking arm is not secured.
5. Position the pulp collector under the pulp ejection spout at the back of the juicer.
6. Place a juice pitcher or glass under the juice spout.

Figure 3.2: Front view of the fully assembled juicer.

4. Operating Instructions

4.1 Preparing Produce

• Wash all fruits and vegetables thoroughly.
• For fruits with hard pits (e.g., peaches, cherries), remove the pits before juicing.
• The oversized feed chute can accommodate whole fruits and vegetables. However, for very large items or to ensure smoother operation, you may cut them into smaller pieces.

4.2 Juicing Process

1. Ensure the juicer is properly assembled and plugged into a 110V power outlet.
2. Turn the juicer ON using the power switch.
3. Gradually feed fruits and vegetables into the oversized feed chute. Do not force produce into the chute.
4. Use the food pusher to gently guide the produce down the chute. Avoid excessive pressure.
5. Fresh juice will dispense from the spout into your pitcher/glass, and pulp will be automatically ejected into the pulp collector.
6. When finished, turn the juicer OFF and unplug it from the power outlet.

Figure 4.1: Juicer ready for operation with various fruits and vegetables.

5. Cleaning & Maintenance

Regular cleaning is essential to maintain the performance and longevity of your Omega BMJ330 Juicer. Clean the appliance immediately after each use.

5.1 Disassembly for Cleaning

1. Ensure the juicer is turned OFF and unplugged from the power outlet.
2. Remove the food pusher.
3. Lower the safety locking arm to release the juicer cover assembly.
4. Carefully remove the juicer cover assembly from the motor base.
5. Remove the stainless-steel filter basket and blade from the juicer cover.
6. Empty the pulp collector.

5.2 Washing Instructions

• All removable parts (juicer cover, filter basket, blade, food pusher, pulp collector) are dishwasher safe.
• Alternatively, wash these parts in warm, soapy water using a soft brush or sponge. Pay special attention to the mesh of the filter basket to remove any pulp residue.
• Rinse all parts thoroughly under running water.
• Wipe the motor base with a damp cloth. Never immerse the motor base in water or any other liquid.
• Dry all parts completely before reassembling or storing the juicer.

Figure 5.1: Emptying the large-capacity pulp collector after juicing.

6. Troubleshooting

• Juicer does not turn on: Ensure the appliance is correctly assembled and the safety locking arm is securely in place. Check that the power cord is firmly plugged into a working 110V outlet.
• Motor stops during operation: This may indicate an overload. Turn the juicer OFF, unplug it, and clear any blockages in the filter basket or feed chute. Allow the motor to cool down for a few minutes before restarting.
• Excessive vibration or noise: Ensure the juicer cover and filter basket are correctly seated and the safety locking arm is engaged. Uneven loading of produce can also cause vibration; feed produce gradually.
• Pulp is wet: This can happen with very soft or overripe fruits. For maximum juice extraction, process produce slowly and avoid overfilling the feed chute.
• Juice leaks: Check that all parts are correctly assembled and the juice spout is properly positioned.

7. Specifications

8. Warranty & Support

The Omega BMJ330 Mega Mouth Juicer comes with a 10-year limited warranty. For warranty claims, technical support, or replacement parts, please contact Omega customer service directly. Keep your proof of purchase for all warranty-related inquiries.

For further assistance, please refer to the official Omega website or contact their support channels.
