Benro Carbon Travel Angel Tripod C-269m8 User Manual

Introduction

This manual provides essential instructions for the safe and effective use of your Benro Carbon Travel Angel Tripod C-269m8. Designed for portability and stability, this carbon fiber tripod is a versatile tool for photographers. Please read this manual thoroughly before operating the tripod to ensure proper setup, operation, and maintenance.

Safety Instructions

• Always ensure all leg locks and adjustments are securely tightened before mounting equipment.
• Do not exceed the maximum load capacity of 12.0 kg to prevent damage to the tripod or attached equipment.
• Avoid placing the tripod on unstable or uneven surfaces.
• Keep hands and fingers clear of moving parts when adjusting the tripod.
• Do not leave the tripod unattended with heavy equipment, especially in windy conditions.
• Clean the tripod regularly to prevent dust and debris from affecting its operation.

Package Contents

Verify that all items are present in the package:

• Benro Carbon Travel Angel Tripod C-269m8
• Tripod Bag
• Carrying Strap

Setup

1. Unfolding the Tripod: Release the leg locks and extend the legs outwards until they are fully spread or set to your desired angle. Ensure the leg angle locks engage securely.
2. Extending Leg Sections: Loosen the twist locks on each leg section. Pull out the desired number of sections and then firmly tighten the twist locks to secure them. Start with the thickest sections first for maximum stability.
3. Adjusting Center Column: If equipped with a center column, loosen its lock to raise or lower it. Tighten the lock firmly once the desired height is achieved. For maximum stability, keep the center column as low as possible.
4. Mounting Equipment: Ensure your camera or equipment is securely attached to the tripod head (if applicable, tripod head sold separately or integrated). Verify that all quick-release plates and mounting screws are tight.

This image shows the Benro Carbon Travel Angel Tripod C-269m8 in its compact, folded state, ready for travel. The carbon fiber legs are collapsed, and the overall design emphasizes portability.

Operating

• Adjusting Leg Angles: Each leg features angle stops. Press the angle lock release to adjust the leg to a wider or narrower spread, then ensure it clicks into place.
• Height Adjustment: Adjust the height by extending or retracting leg sections and/or raising or lowering the center column. Always re-tighten all locks after adjustment.
• Folding for Transport: To fold the tripod, retract all leg sections, lower the center column, and then fold the legs upwards (if applicable) or inwards to their most compact position. Secure any locking mechanisms.

Maintenance

• Cleaning: Wipe down carbon fiber legs and metal parts with a soft, damp cloth. For stubborn dirt, use a mild soap solution. Avoid harsh chemicals.
• Lubrication: Do not apply lubricants to leg sections or twist locks unless specifically instructed by Benro. This can attract dirt and impair function.
• Storage: Store the tripod in its protective bag in a dry, cool environment, away from direct sunlight and extreme temperatures.
• Inspection: Periodically check all screws, bolts, and locks for tightness. Ensure leg sections extend and retract smoothly.

Troubleshooting

• Tripod is unstable: Ensure all leg sections are fully extended and their twist locks are securely tightened. Verify that leg angle locks are engaged. Check that the center column lock is tight.
• Leg sections are stiff or difficult to extend/retract: Clean the leg sections thoroughly to remove any accumulated dirt or sand. If the issue persists, contact Benro support. Do not force the sections.
• Equipment wobbles on tripod: Confirm that the camera or equipment is properly mounted and secured to the tripod head. Ensure the tripod head itself is firmly attached to the tripod.

Specifications

Warranty and Support

For warranty information, technical support, or service inquiries, please refer to the official Benro website or contact your authorized Benro dealer. Keep your purchase receipt as proof of purchase.
