Drive Medical 700-869
Hugo Portable Transport Wheelchair User Manual
Model: 700-869
Product Overview
The Hugo Portable Transport Wheelchair is designed to provide comfortable and convenient mobility assistance. This lightweight and ultra-compact wheelchair is ideal for travel and easy transport.
Key features include:
- Lightweight aluminum frame, weighing only 16 lbs (without accessories).
- Ultra-compact folding design for easy storage and transport.
- Adjustable and detachable footrests.
- Ergonomically angled handlebars for caregiver comfort and increased user shoulder room.
- Large 8-inch wheels for improved comfort over obstacles.
- Fully padded seat and backrest.
- Integrated storage pocket.
- Standard safety features: seat belt and dual locking rear wheels.
- Supports users up to 250 lbs.
Image: The Hugo Portable Transport Wheelchair in Midnight Blue, showcasing its compact design and features.
Setup and Assembly
The Hugo Portable Transport Wheelchair features tool-free assembly, designed for quick and easy setup.
- Unfolding the Wheelchair: Carefully remove the wheelchair from its packaging. Grasp the frame and pull outwards until the chair is fully open and locked into position. Ensure all locking mechanisms are engaged.
- Attaching Footrests: Align the footrest pins with the receptacles on the front of the wheelchair frame. Insert the pins and push down until they click securely into place. Adjust the footrests to the desired height by pressing the adjustment buttons and sliding them up or down.
- Verifying Stability: Before use, ensure all parts are securely attached and the wheelchair is stable. Check that the dual locking rear wheels engage properly.
Image: The Hugo Transport Chair in its retail packaging, indicating ease of transport and setup.
Operating Instructions
User Seating and Transfer
- Ensure the dual locking rear wheels are engaged before a user attempts to sit in or stand from the wheelchair.
- Assist the user in sitting fully back into the padded seat.
- Fasten the seat belt securely around the user for added safety during transport.
Pushing and Maneuvering
- The ergonomically angled handlebars provide a comfortable grip for the caregiver.
- Push the wheelchair forward by applying gentle, consistent pressure on the handlebars.
- To turn, apply slightly more pressure to one handle while easing pressure on the other.
- The large 8-inch wheels are designed to navigate minor obstacles with increased comfort.
Image: A user seated in the Hugo Transport Wheelchair, highlighting the design that provides 35% more shoulder room for enhanced comfort.
Folding for Transport and Storage
- Ensure the user has exited the wheelchair and the footrests are detached or swung out of the way.
- Utilize the easy-touch levers to fold the back of the chair down.
- Grasp the seat and pull upwards to collapse the frame inward, making it ultra-compact for storage or placement in a car trunk.
Image: The Hugo Transport Wheelchair folded and stored compactly in a car trunk, demonstrating its portability.
Maintenance
Regular maintenance ensures the longevity and safe operation of your Hugo Portable Transport Wheelchair.
- Cleaning: Wipe down the frame and padded surfaces with a damp cloth and mild detergent. Avoid abrasive cleaners.
- Wheel Inspection: Periodically check the wheels for wear and tear. Ensure they spin freely and are free of debris.
- Fastener Check: Regularly inspect all bolts, screws, and locking mechanisms to ensure they are tight and secure. Tighten any loose fasteners as needed.
- Footrest Functionality: Verify that the detachable footrests attach and detach smoothly and that their height adjustment mechanisms operate correctly.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Wheelchair does not fold or unfold smoothly. | Mechanism obstructed or not fully engaged. | Check for any obstructions. Ensure easy-touch levers are fully depressed and frame is aligned. |
| Footrests are loose or detach unexpectedly. | Pins not fully inserted or locking mechanism worn. | Ensure footrest pins are fully inserted and click into place. Inspect locking mechanism for damage. |
| Wheels do not roll freely. | Debris in wheel bearings or brake engaged. | Clear any debris from wheels and axles. Ensure brakes are fully disengaged. |
| Seat belt does not fasten securely. | Buckle mechanism damaged or obstructed. | Inspect the buckle for damage or foreign objects. Clean if necessary. |
Specifications
| Specification | Value |
|---|---|
| Model Number | 700-869 |
| Weight Capacity | 250 lbs. |
| Item Weight | 22.1 lbs. |
| Wheel Size | 8.0 inches |
| Seat Width | 19.3 inches |
| Seat Depth | 15.4 inches |
| Seat Height (seat to floor) | 19.3 inches |
| Armrest Height (seat to armrest) | 10.2 inches |
| Assembled Dimensions (open) | 40.2" (Length) x 22.8" (Width) x 36.6" (Height) |
| Color | Midnight Blue |
| Frame Material | Aluminum |
Image: Detailed dimensions of the Hugo Portable Transport Wheelchair, including height, length, and width.
Warranty and Support
For specific warranty information and support inquiries regarding your Hugo Portable Transport Wheelchair, please refer to the official documentation provided with your purchase or contact Drive Medical customer service.
An installation manual is available in PDF format for additional guidance: Installation Manual (PDF)
