SPT SU-1051B Personal Humidifier Instruction Manual

1. Introduction

Thank you for purchasing the SPT SU-1051B Personal Humidifier. This compact and portable device is designed to provide a comfortable humidity level in small personal spaces, such as during travel, at your desk, or in a nursery. Utilizing ultrasonic technology, it produces a cool mist quietly and efficiently. Please read this manual thoroughly before operation to ensure safe and optimal use of your humidifier.

2. Important Safety Instructions

When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following:

• Read all instructions before using the appliance.
• Always place the humidifier on a firm, flat, and level surface.
• Do not operate the humidifier without water.
• Do not place the humidifier near heat sources such as stoves, radiators, or direct sunlight.
• Do not block air vents.
• Do not immerse the humidifier in water or other liquids.
• Unplug the humidifier from the power outlet when not in use, when filling, or when cleaning.
• Keep out of reach of children.
• Use only clean, cool tap water or distilled water. Distilled water is recommended to prevent mineral buildup and potential clogging.
• Do not add essential oils or other additives directly into the water bottle or base, as this may damage the unit.
• Ensure the water bottle is securely attached to prevent leaks.

3. Package Contents

Please check the package contents. If any items are missing or damaged, contact your retailer.

• SPT SU-1051B Personal Humidifier Unit
• Two (2) different sized bottle adapters
• One (1) 100-240V AC adapter (UL listed)
• Instruction Manual (this document)

4. Product Features

• Cool Mist (Ultrasonic Technology): Provides a fine, cool mist for comfortable humidification.
• 120cc per hour humidity output: Efficiently humidifies small personal spaces.
• Adjustable Mist: Allows control over the mist output level.
• Uses Water Bottle Instead of Water Tank: Conveniently uses standard water bottles (not included) for water supply, eliminating the need for a separate tank.
• Water Refill Indicator: Alerts you when the water level is low and requires refilling.
• Quiet Operation: Designed for minimal noise, suitable for use in quiet environments.
• Low Power Consumption: Energy-efficient design.
• UL Listed AC Adapter: Ensures safety and reliability of the power supply.
• Patent Pending Design: Innovative and unique product design.

5. Setup

1. Unpack the Humidifier: Carefully remove all components from the packaging.
2. Choose a Location: Place the humidifier on a firm, flat, and water-resistant surface at least 6 inches away from walls or furniture. Ensure it is not placed on carpet or near heat sources.
3. Prepare the Water Bottle:
   • Select a clean, standard plastic water bottle (e.g., 16.9 oz / 500ml or similar size).
   • Fill the bottle with clean, cool tap water or, preferably, distilled water to minimize mineral buildup.
   • Choose the appropriate bottle adapter from the two provided that best fits your water bottle's opening.
   • Screw the chosen adapter securely onto the filled water bottle.
4. Attach Water Bottle to Humidifier:


   Image: The SPT SU-1051B Personal Humidifier shown with a standard water bottle inverted and attached to the top of the unit. The unit is black with a silver control knob.

   Invert the filled water bottle with the adapter attached and carefully place it onto the humidifier's water inlet. Ensure it is seated firmly and straight to prevent water leakage. The water will begin to flow into the humidifier's reservoir.
5. Connect Power: Plug the 100-240V AC adapter into the humidifier's power port, then plug the adapter into a suitable electrical outlet.

6. Operating Instructions

1. Power On: Once plugged in and the water bottle is correctly installed, the humidifier is ready for operation. The unit typically has a touch control or a knob.
2. Adjust Mist Output: Use the control (e.g., touch button or rotary knob) to turn the unit on and adjust the mist intensity to your desired level. A blue indicator light may illuminate when the unit is operating.
3. Water Refill Indicator: When the water level in the humidifier's reservoir becomes low, the unit will automatically shut off, and a red indicator light (or similar) may illuminate, signaling that the water bottle needs to be refilled or replaced.
4. Power Off: To turn off the humidifier, use the control button/knob. Unplug the unit from the power outlet when not in use.

7. Maintenance

Regular cleaning is essential for optimal performance and hygiene.

Daily Maintenance:

• Unplug the unit before cleaning.
• Empty any remaining water from the humidifier base and water bottle.
• Wipe the exterior of the unit with a soft, damp cloth.
• Allow all parts to air dry completely before reassembly or storage.

Weekly Maintenance (or more often with hard water):

• Descaling the Ultrasonic Atomizer: Mineral deposits (scale) can build up on the ultrasonic atomizer, affecting mist output.
  1. Unplug the unit.
  2. Remove the water bottle.
  3. Pour 1 cup of undiluted white vinegar into the base reservoir, ensuring it covers the ultrasonic atomizer.
  4. Let it soak for 20-30 minutes.
  5. Gently scrub the atomizer with a soft brush (not metal) to remove mineral buildup.
  6. Drain the vinegar and rinse the reservoir thoroughly with clean water until the vinegar smell is gone.
• Cleaning the Water Bottle and Adapters: Wash the water bottle and adapters with warm soapy water, rinse thoroughly, and air dry.

Note: Always use distilled water if possible to significantly reduce mineral buildup and extend the life of your humidifier.

8. Troubleshooting

9. Specifications

10. Warranty and Support

This SPT SU-1051B Personal Humidifier comes with a 1-year warranty covering parts and labor from the date of purchase. This warranty covers defects in materials and workmanship under normal use.

For warranty claims, technical support, or inquiries, please contact SPT customer service. Keep your proof of purchase for warranty validation.

Note: The warranty does not cover damage caused by misuse, neglect, unauthorized repairs, or failure to follow the instructions in this manual.
