Leviton 4-Gang 3-Toggle 1-Decora/GFCI Combination Wallplate (80732-I)

Introduction

This manual provides instructions for the installation, operation, and maintenance of your Leviton 4-Gang 3-Toggle 1-Decora/GFCI Device Combination Wallplate, model 80732-I. This wallplate is designed to cover a combination of three toggle switches and one Decora/GFCI device, providing a clean and finished appearance to your electrical installations.

The wallplate is constructed from molded thermoplastic nylon, offering maximum resistance to impact, abrasion, fading, and discoloration. Its smooth face and rounded edges help resist dust accumulation, ensuring a neat look.

Safety Information

WARNING: To avoid fire, shock, or death, turn off power at the circuit breaker or fuse box and test that the power is off before wiring. It is recommended that this product be installed by a qualified electrician. Always follow local electrical codes.

• Ensure power is disconnected before beginning any work.
• Use appropriate tools and safety equipment.
• Do not overtighten screws, as this may damage the wallplate or devices.

Package Contents

• 1 x Leviton 4-Gang 3-Toggle 1-Decora/GFCI Device Combination Wallplate (Ivory)
• Mounting Screws (typically included with wallplate)

Setup and Installation

1. Turn Off Power: Locate the circuit breaker or fuse box that controls the power to the electrical box where the wallplate will be installed. Turn off the power completely. Verify power is off using a voltage tester.
2. Remove Existing Wallplate: Carefully unscrew and remove the old wallplate, if present.
3. Prepare Devices: Ensure your three toggle switches and one Decora/GFCI device are properly installed and secured within the electrical box.
4. Position New Wallplate: Align the new Leviton 4-Gang 3-Toggle 1-Decora/GFCI Combination Wallplate over the installed devices. Ensure the openings on the wallplate match the configuration of your devices (three toggle, one Decora/GFCI).
5. Secure Wallplate: Use the provided mounting screws to attach the wallplate to the electrical box. Hand-tighten the screws until the wallplate is snug against the wall. Avoid overtightening, which can crack the wallplate or cause devices to bind.
6. Restore Power: Once the wallplate is securely installed, turn the power back on at the circuit breaker or fuse box.

Image: Leviton 4-Gang 3-Toggle 1-Decora/GFCI Combination Wallplate (Ivory). This image shows the installed wallplate with one GFCI outlet and three toggle switches.

Operating Instructions

The Leviton 4-Gang 3-Toggle 1-Decora/GFCI Combination Wallplate functions as a protective and decorative cover for your electrical devices. Once installed, it requires no specific operation. The devices it covers (toggle switches and Decora/GFCI outlets) will operate as normal through the wallplate openings.

Maintenance

• Cleaning: To clean the wallplate, wipe it with a soft, damp cloth. For stubborn marks, a mild soap solution can be used. Avoid abrasive cleaners or harsh chemicals, as these can damage the finish.
• Inspection: Periodically check the wallplate for any signs of damage, cracks, or discoloration. If damage is observed, replace the wallplate to maintain safety and appearance.

Troubleshooting

• Wallplate Does Not Fit Flush: Ensure that the electrical box and all devices (switches, GFCI) are properly seated and aligned within the wall. Sometimes, slight adjustments to the device mounting screws can help the wallplate sit flush. Do not force the wallplate into position.
• Screws Do Not Tighten: Check if the screws are correctly aligned with the screw holes on the electrical box and devices. If the threads are stripped, you may need to replace the screws or use appropriate anchors if the box is damaged.
• Discoloration or Damage: If the wallplate shows significant discoloration, cracks, or other damage, it should be replaced. While made from durable thermoplastic nylon, extreme conditions or impacts can cause wear.

Specifications

Warranty Information

This Leviton wallplate is covered by a manufacturer's warranty. For specific details regarding the warranty period and terms, please refer to the official Leviton website or contact their customer support directly. Retain your proof of purchase for warranty claims.

Support

For additional assistance, technical support, or to view other Leviton products, please visit the official Leviton website at www.leviton.com. You can also find contact information for customer service on their website.
