Liebert Rack Bracket Components 2UTELECOMRKIT

1. Introduction

This manual provides essential information for the proper installation, operation, and maintenance of the Liebert Rack Bracket Components 2UTELECOMRKIT. This 19-inch rack bracket is designed to optimize data center management and enhance performance for IT systems and data centers. Please read this manual thoroughly before proceeding with installation.

2. Safety Information

Always observe the following safety precautions to prevent injury and damage to equipment:

• Ensure the rack is stable and properly secured before installing any components.
• Distribute weight evenly within the rack to prevent tipping.
• Use appropriate tools for installation.
• Do not exceed the weight capacity of the rack or the bracket.
• Keep hands and clothing clear of moving parts during installation.

3. Package Contents

Verify that all items are present and undamaged upon unpacking:

• Liebert rack bracket (1 unit)
• Mounting hardware (screws, cage nuts, washers - quantity may vary)

4. Setup and Installation

Follow these steps to properly install the Liebert Rack Bracket Components 2UTELECOMRKIT into a standard 19-inch rack.

1. Prepare the Rack: Identify the desired rack unit (RU) positions for the bracket. Ensure there is sufficient space and proper ventilation for the equipment to be mounted on the bracket.
2. Attach Mounting Hardware: Insert cage nuts into the square holes of the rack rails at the chosen RU positions.
3. Position the Bracket: Align the mounting holes on the Liebert rack bracket with the cage nuts in the rack rails.
4. Secure the Bracket: Using the provided screws and washers, firmly attach the bracket to the rack rails. Tighten all screws evenly to ensure a secure and level installation. Do not overtighten.

Once the bracket is securely installed, you can place compatible equipment onto it. Ensure the equipment is centered and its weight is evenly distributed on the bracket.

5. Operating Instructions

The Liebert Rack Bracket Components 2UTELECOMRKIT is a passive component designed to provide stable support for rack-mountable equipment. Once installed and equipment is placed upon it, no further operational steps are required for the bracket itself. Ensure that any equipment placed on the bracket is properly secured according to its own manual.

6. Maintenance

To ensure the longevity and continued performance of your Liebert rack bracket:

• Periodically inspect all mounting screws to ensure they remain tight.
• Check for any signs of wear, corrosion, or damage to the bracket.
• Clean the bracket with a dry, lint-free cloth as needed to remove dust. Avoid abrasive cleaners.

7. Troubleshooting

Most issues related to a rack bracket are installation-related:

• Bracket does not fit: Verify that your rack is a standard 19-inch width and that you are attempting to install the bracket in the correct orientation.
• Bracket is not level: Loosen the mounting screws slightly, adjust the bracket to be level, and then re-tighten the screws evenly.
• Equipment is unstable on the bracket: Ensure the equipment is centered and its weight is distributed. Verify that the bracket itself is securely mounted to the rack.

8. Specifications

9. Warranty and Support

For warranty information and technical support, please refer to the documentation provided with your purchase or visit the official Liebert website. You can also visit the Liebert Store on Amazon for additional product information and resources.
