EmETXe-i2309 COM Express Compact Type 6 CPU Module
Installation Guide

EmETXe-i2309 COM Express Compact Type 6 CPU Module

Form Factor
COM Express® Compact Type 6 CPU Module
CPU
Intel® Atom™ processor E3845 1.91GHz
Video
24-bit Dual Channels LVDS/ DisplayPort/Analog RGB
I/O
USB 2.0/USB 3.0/SATA/PCIe x1/SPI/LPC/eMMC
LAN
Intel® i210X Series Controller
Video
24-bit Dual Channels LVDS/ DisplayPort/Analog RGB
Audio
HD Audio Interface

Technical Support

If you have any technical difficulties, please consult the user’s manual first at: http://www.arbor-technology.com
Please do not hesitate to call or e-mail our customer service when you still can not find out the answer. http://www.arbor-technology.com
E-mail: info@arbor.com.tw
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Copyright® 2017 All Rights Reserved.

4041230900200P

COM Express supports seven pin-out Type applying to Basic and Extended form factors:
Module Type 1 and 10 support single connector with two rows of pins (220 pins) Module Type 2, 3, 4, 5 and 6 support two connectors with four rows of pins (440 pins) Connector placement and most mounting holes have transparency between Form Factors.
The differences among the Module Type 6 and EmETXe-i2309 are summarized in table below:

Module Type	Standard Type 6	EmETXe-i2309
Connectors	2	2
Connector Rows	A, B, C, D	A, B, C, D
PCIe Lanes (Max)	24	8
LAN (Max)	1	1
Serial Ports (Max)	2	1
Digital Display I/F (Max)	3	1 (Stabdard default) 2 (OEM request)
USB 3.0 Ports (Max)	4	1

Packing List

Before you begin installing your single board, please make sure that the following materials have been shipped:

	1 x EmETXe-i2309 COM Express CPU Module
	1 x Driver CD 1 x Quick Installation Guide

If any of the above items is damaged or missing, contact your vendor immediately.

Specifications

System
CPU	Soldered onboard Intel® Atom™ processor E3845 1.91GHz
Memory	1 x DDR3L SO-DIMM socket, supporting up to 8GB 1333MT/s SDRAM
BIOS	Insyde UEFI BIOS
Watchdog Timer	1~255 levels reset (function depends on carrierboard)
I/O
USB Port*	8 x USB 2.0 ports*, 1 x USB 3.0 port
Expansion Bus	8 x PCIex1 lanes, SPI, LPC, SM_BUS, GPIO(Optional)
Storage	2 x Serial ATA ports with 300MB/s HDD transfer rate
	Soldered onboard 8GB eMMC 4.5 (Optional)
Ethernet Chipset	1 x Intel® i210X PCIe GbE controller
Serial Port	1 x UART (RX/TX)
TPM	Supports TPM (OEM Request)
Audio	HD audio link
Display
Graphic Chipset	SoC integrated Intel® Gen7 Graphics
Graphic Interface	Analog RGB, with resolution up to 2048×1536
	LCD: Dual Channels 24-bit LVDS, with resolution up to 1920×1200
	1 x DDI port
Mechanical & Environmental
Power Requirement	DC 12V, 5VSB
Power Consumption	1.05A@12V with E3825 (Typical, with PBE-1705)
Operating Temp.	-20 ~ 70oC (-4 ~ 158oF) -40 ~ 85oC (-40 ~ 185oF, WT series)
Operating Humidity	10 ~ 95% @ 70oC (non-condensing) 10 ~ 95% @ 85oC (non-condensing, WT series)
Dimensions (L x W)	95 x 95 mm (3.7” x 3.7”)

* USB port 2~7 support USB2.0 only, USB port 0~1 work after driver installation.

Ordering Information

EmETXe-i2309-E3845	Intel® Atom™ processor E3845 1.91GHz COM Express® Compact CPU module
EmETXe-i2309-E3845-DIO	Intel® Atom™ processor E3845 1.91GHz COM Express® Compact CPU module, w/GPIO
EmETXe-i2309-WT-E3845	Intel® Atom™ processor E3845 WT COM Express® Compact Type 6 CPU module

Optional Accessories

HS-2309-F2-NT*	Heat spreader, non-thereaded standoffs (bore hole) (95x95x11mm), not compatible with WT series
HS-0000-W4	Universal evaluation heatsink kit w/ thermal pad (dimensions: 125x95x22mm, only used on a flat type heat spreader)
PBE-1705-F1	COM Express® Type 6 evaluation carrier board with super I/O F71869ED in ATX form factor
CBK-03-1705-00	Cable kit 1 x SATA cable 2 x COM flat cables

*For Wide-Temperature series, it is suggested to use HS-2309-F2-NT in conjunction with HS-0000-W4. The user must cut the HS-0000-W4 thermal pad to the right size to fit the heat spreader.

Find Device Drivers on CD

The CPU module supports Windows 7 and 8. Find the necessary drivers on the CD that comes with your purchase. For different OS, the driver installation may vary slightly, but generally they are similar. DO install Chipset→Graphic→Audio before the rest to prevent errors.
Find the drivers on CD by the following paths:
Windows 8.1

Driver	Path
Chipset	\Chipset\SetupChipset_10.0.13_PC
Graphic	\Graphics\WIN8_32\15.33.22.3621
	\Graphics\WIN8_64\15.33.22.64.3621
Audio	\Audio\32bit_Win7_Win8_Win81_R275
	\Audio\64bit_Win7_Win8_Win81_R275
Ethernet	\Ethernet\Intel
GPIO	\GPIO\Kit 100882 20140211 windows 8.1 64\GPIO
TXE	\TXE\Installers
Serial IO	\Serial IO\SerialIO_Installer_Win8.1_64bit_WW23
MBI	\MBI\MBI Kit 58443 20140106_windows 8_8.132_64
WINUSB	\WINUSB

Windows 7

Driver	Path
Chipset	\Chipset\SetupChipset_10.0.13_PC
Graphic	\Graphics\WIN7_32\Intel_EMGD.WIN7_PC_Version_36_15_0_1073
	\Graphics\WIN7_64\Intel_EMGD.WIN7_PC_Version_37_15_0_1073
Audio	\Audio\32bit_Win7_Win8_Win81_R275
	\Audio\64bit_Win7_Win8_Win81_R275
Ethernet	\Ethernet\Intel
TXE	\TXE\Installers
GPIO	\GPIO\windows 7 32_64\Intel Atom E3800 Win7 IO Drivers_Gold_v1.0 pack- age 501232_20140211
USB3.0	\USB3.0\Intel(R) USB 3.0 eXtensible Host Controller_Win7_32bit_64bit_ R3.0.0.33
Serial IO	\Serial IO\Intel Processor IO Drivers_Win7_32bit_64bit_Gold_v2.0
WINUSB	\WINUSB

Board Dimensions\Connectors Quick Reference

COM Express AB Connector (bottom side)

COM Express CD Connector (bottom side)

Version 2.0
