Vividmoo Countertop Nugget Ice Maker User Manual

1. المقدمة

Thank you for choosing the Vividmoo Countertop Nugget Ice Maker. This portable and efficient ice machine is designed to provide you with soft, chewable nugget ice quickly and conveniently, perfect for enhancing your favorite beverages at home, in the kitchen, or at the office. Please read this manual thoroughly before operation to ensure safe and optimal performance.

Figure 1: The Vividmoo Countertop Nugget Ice Maker, showcasing its sleek design and the type of ice it produces.

2. تعليمات السلامة الهامة

• اقرأ جميع التعليمات قبل تشغيل الجهاز.
• تأكد من جهد مأخذ الطاقةtage matches the appliance's requirements (115V~60Hz).
• لا تغمر سلك الطاقة أو القابس أو أي جزء من الجهاز في الماء أو السوائل الأخرى.
• افصل الجهاز عن المنفذ عندما لا يكون قيد الاستخدام وقبل التنظيف.
• لا تقم بتشغيل أي جهاز بسلك أو قابس تالف، أو بعد حدوث عطل في الجهاز أو تعرضه للتلف بأي شكل من الأشكال.
• احفظ الجهاز بعيدًا عن مصادر الحرارة وأشعة الشمس المباشرة.
• Ensure proper ventilation around the unit. Allow at least 6 inches of space around the ice maker when in use.
• هذا الجهاز مخصص للاستخدام المنزلي فقط.
• Before plugging in your ice maker for the first time, allow it to stand upright for at least 2 hours to allow the refrigerant fluid to settle.

3. انتهى المنتجview

The Vividmoo Nugget Ice Maker is designed for convenience and efficiency. Key features include:

• Nugget Ice Production: Produces soft, chewable nugget ice, ideal for beverages.
• قدرة عالية: Capable of producing up to 33 pounds of ice in 24 hours.
• تشغيل منخفض الضوضاء: Utilizes advanced compressor technology for a quiet operation at approximately 43dB.
• تصميم مضغوط: Measures 8.50 x 11.22 x 12.60 inches, fitting easily on most countertops.
• التشغيل بضغطة زر واحدة: Simple and intuitive control for ice making and cleaning.
• وظيفة التنظيف الذاتي: Automated cleaning routine for easy maintenance.
• حساس الأشعة تحت الحمراء: Prevents ice overflow by automatically stopping production when the basket is full.
• Circular Indicator Light: Notifies you when to refill water or when the ice basket is full.
• مقبض محمول: For easy transport and placement.

Figure 2: Compact design and capacity details of the ice maker.

Figure 3: Illustrates the low noise operation of the ice maker at 43dB.

الشكل 4: مثالample of the chewable nugget ice produced by the machine.

4. الإعداد

1. فك التعبئة: Carefully remove the ice maker from its packaging. Remove all packing materials, tapes, and labels.
2. الموقع: Place the ice maker on a stable, level surface, away from direct sunlight and heat sources. Ensure there is at least 6 inches of clear space around the unit for proper ventilation.
3. Settle Refrigerant: Before plugging in the ice maker for the first time, allow it to stand upright for at least 2 hours. This allows the refrigerant fluid to settle, which is crucial for optimal performance and longevity.
4. التنظيف الأولي: قبل الاستخدام الأول، نظّف الجزء الداخلي لصانعة الثلج. راجع قسم "الصيانة" للاطلاع على تعليمات التنظيف المفصلة.
5. إضافة الماء: Open the top lid and fill the water tank with clean, potable water up to the 'MAX' fill line. The tank capacity is approximately 4.6 cups (1.1L).
6. توصيل الطاقة: Plug the power cord into a standard 115V~60Hz electrical outlet.

5. تعليمات التشغيل

Operating your Vividmoo Nugget Ice Maker is simple and straightforward:

1. بدء إنتاج الثلج: After adding water and plugging in the unit, press the 'ICE/CLEAN' button once. The indicator light will illuminate, and the ice making process will begin.
2. Fast Ice Making: The ice maker can produce its first batch of nugget ice in as little as 5 minutes.
3. مؤشر امتلاء الجليد: When the ice basket is full, the 'Ice Full' indicator light will turn on, and the ice maker will automatically pause production to prevent overflow. Once ice is removed, production will resume.
4. إضافة مؤشر المياه: If the water level in the tank is too low, the 'Add Water' indicator light will turn on. Refill the water tank to continue ice production.
5. Retrieving Ice: Use the provided ice scoop to retrieve ice from the basket. The transparent window allows you to monitor the ice level without opening the lid.

Figure 5: The ice maker's rapid ice production capability.

6. الصيانة

Regular cleaning and maintenance will ensure the longevity and hygiene of your ice maker.

1. وظيفة التنظيف الذاتي:
   • تأكد من امتلاء خزان المياه بالمياه النظيفة.
   • Press and hold the 'ICE/CLEAN' button for 5 seconds to activate the self-cleaning cycle.
   • The self-cleaning process will run for approximately 15 minutes.
   • Once the cycle is complete, remove the drain cap at the bottom of the unit to drain the water.
2. التنظيف اليدوي:
   • افصل صانعة الثلج عن مأخذ الطاقة.
   • قم بتصريف أي مياه متبقية من الخزان.
   • Wipe the interior with a soft cloth and a mild detergent solution. Rinse thoroughly with clean water.
   • The top-open lid design allows for thorough deep cleaning of the interior.
   • تنظيف السطح الخارجي بقطعة ناعمة ، دamp القماش. لا تستخدم المنظفات أو المذيبات الكاشطة.
   • Ensure all parts are completely dry before reassembling and storing or operating the unit.

Figure 6: Steps for utilizing the self-cleaning function.

7. استكشاف الأخطاء وإصلاحها

إذا واجهتك مشكلات مع صانع الثلج، فيرجى الرجوع إلى المشكلات والحلول الشائعة التالية:

8. المواصفات

Figure 7: Detailed specifications and components of the ice maker.

9. الضمان والدعم

Vividmoo offers a ضمان لمدة 24 شهرًا for your ice maker, ensuring peace of mind with your purchase. Additionally, we provide الدعم الفني مدى الحياة لمساعدتك في أي أسئلة أو مشاكل قد تواجهها.

For any inquiries or support needs, please feel free to contact Vividmoo customer service. We are committed to ensuring your satisfaction.
