APA-HUB08A Type C
Multipurpose Extension Hub
User Guide
APA-HUB08A Type C Multipurpose Extension Hub
Why choose ANGUSTOS Pro-AV ?
We can provide you the best solution that suits your TVs, interactive screens, meeting room high-end projector, digital signage and videowall system. We do not just simply sell the equipments but also a smart solution that is just as well designed as it is functional. Solutions that guarantee and define our brand:
- Ease-of-use
- Design
- Innovation
- Reliability
- Ease-of-installation.
To help you find the exact solution you need, Angustos has an extensive product range that is possible to compose a solution for nearly every Pro AV application. Our highly skill solution teams are happy to help you to quickly find the best solution for your installation, saving you the time and effort and hassle for complex system.
ANGUSTOS PRO AV APPLICATIONS
- Media – Telecom – Broadcast
- Education – Training
- Manufacturing – Quality Control
- Retail – Advertising
- Meeting Room – Conference
- Healthcare visual system
- Entertainment
- Government – Control Room
Type C Multipurpose Extension Hub – 8 in 1
Model: APA-HUB08A
FEATURES
- USB Type C . Plug and Play.
- Up to 100W power charging
- USB 2.0 : Support 480Mbps rate
- USB 3.0 : Support 5Gbps rate
- HDMI: single display 4K@30Hz
- Simultaneous display 1080P/60Hz support
- VGA: 1080P@60Hz
- 3.5mm Audio support
- Ethernet – RJ45: 100M
PACKAGE CONTENT
* 8 in 1 Hub x 1
SPECIFICATION
| Operating Temperature | -5° to 70°C |
| Operating Humidity | 5 to 90%RH |
| Video Input Connectors | 1 x Type C |
| Video Output Connectors | 1 x HDMI Type A |
| 1 x VGA | |
| Data Rate | 480Mbps / 5 Gbps |
| Resolution Support | 1920x1080p @60Hz |
| 4K @ 30Hz (HDMI) | |
| HDMI Compliance | HDMI1.2, Deep color |
| USB port | Type A 2.0 x 2 |
| Type A 3.0 x 1 | |
| Type C x 1 | |
| Type C power charge | Up to 100W |
| Ethernet | RJ45 x 1 |
| Audio Port | 3.5mm x 1 |
| Peripheral | Support HID peripherals |
CONNECTION DIAGRAM
Website: http://www.angustos.com
Email: inquiries@angustos.com
Documents / Resources
 |
ANGUSTOS APA-HUB08A Type C Multipurpose Extension Hub [pdf] User Guide APA-HUB08A Type C Multipurpose Extension Hub, APA-HUB08A, Type C Multipurpose Extension Hub, Multipurpose Extension Hub, Extension Hub, Hub |
