  • Model: ACM1552S-C
  • Type: Serial Contactless Reader Module with SAM Slot
  • Version: 1.00
  • Frequency Range: 13.56 MHz
  • Antenna Type: PCB
  • Antenna Gain: 0dBi
  • Impedance: 50 Ohms

Introduction

The ACM1552S-C (Serial Contactless Reader Module with SAM Slot) is an interface for the communication between a host (for example, a PC) and a contactless card. The ACM1552S-C (Serial Contactless Reader Module with SAM Slot) establishes a uniform interface from the computer to the smart card for a wide variety of cards. By taking care of the card specific particulars, it releases the software programmer of getting involved with the technical details of the smart card operation, which are in many cases not relevant for the implementation of a smart card system.
This document serves as a guide for host product manufacturers according to KDB 996369 D03 OEM.

Integration instructions for host product manufacturers according to KDB 996369 D03

List of applicable FCC rules
CFR 47 FCC PART 15 SUBPART C has been investigated.

Specific operational use conditions
This module is certified connecting to specific host for indoor application.

Limited module procedures
The module acquired single module approval.

Trace antenna designs
Not applicable.

RF exposure considerations
To maintain compliance with FCC’s RF Exposure guidelines, this equipment should be installed and operated with minimum distance of 20cm from your body.

Antennas
This radio transmitter FCC ID: V5MACM1552S-C has been approved by Federal Communications Commission to operate with the antenna types listed below, with the maximum permissible gain indicated. The antenna is permanently fixed. It cannot be replaced.

No. Antenna Type Antenna Gain Impedance Frequency Range
1 PCB 0dBi 50W 13.56 MHz

Label and compliance information
The host product must be labeled in a visible area with the following “Contains FCC ID: V5MACM1552S-C”

Information on test modes and additional testing requirements
Module manufacturer tested ACM1552S in specific condition. No change should be made on the module. Any change to the module should be tested against specific FCC rule parts.

Additional testing, Part 15 Subpart B disclaimer
Module manufacturer tested ACM1552S-C in specific condition. No change should be made on the module. Any change to the module should be tested against specific FCC rule parts.

FCC Warning Statement

FCC Caution
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

  1. This device may not cause harmful interference, and
  2. This device must accept any interference received, including interference that may cause undesired operation.

IMPORTANT NOTE:
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

  • Reorient or relocate the receiving antenna.
  • Increase the separation between the equipment and receiver.
  • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
  • Consult the dealer or an experienced radio/TV technician for help.

FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

ACM1552S-C – User Manual Version 1.00
info@acs.com.hk
www.acs.com.hk

FAQ

  • Q: What is the maximum permissible gain of the antenna?
    A: The antenna type is PCB with a gain of 0dBi and impedance of 50 Ohms.
  • Q: What are the FCC rules investigated for this module?
    A: CFR 47 FCC PART 15 SUBPART C has been investigated for this module.
