Core Line Recessed Spot gen2
RS155Z
| System lumen (Lm) | light source of energy efficiency class | P (w) |  |
|
| RS155Z MODULE LED6-WB-/827 D68 PSR | 720 | E | 7.2 | 0.24 |
| RS155Z MODULE LED6-WB-/830 D68 PSR | 750 | |||
| RS155Z MODULE LED6-WB-/840 D68 PSR | 800 | |||
| RS155Z MODULE LED9-WB-/830 D68 PSR | 1000 | E | 10.2 | 0.24 |
| RS155Z MODULE LED9-WB-/840 D68 PSR | 1080 |
Electrical characteristics
 |
|
  |
• The luminaire shall be installed by a qualified electrician and wired in accordance with the latest IEE electrical regulations or the national requirements. • Only to be installed outside arms reach as recessed ceiling luminaire. • For complete and updated list of advised dimmers, please check the CoreLine Recessed Spot RS155 page on the Philips Lighting eCatalog: http://www.ecat.lighting.philips.com • The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent or a similar qualified person. • Reinforce insulation between LV and accessible part(working voltage:250V) |
This product contains a light source of energy efficiency class: see table or label.
The light source and/or control gear and/or the external flexible cable contained in this luminaire shall only be replaced by the manufacturer or his service agent or a similar qualified person.
© 2022 Signify Holding. All rights reserved
Data subject to change without notice
Keep for future reference: https://www.lighting.philips.com/
