1. Güvenlik Bilgileri
Lütfen bu cihazı kullanmadan önce tüm talimatları okuyun.
- Aşırı Isınma Koruması: The heater is equipped with an automatic overheat shutoff. If the internal components reach a certain temperature, the heater will automatically turn off to prevent overheating. It will resume operation once it has cooled down.
- Devrilme Koruması: A safety switch is integrated into the base of the heater. If the unit is accidentally knocked over, the power will immediately cut off. Operation will resume once the heater is placed upright on a stable surface.
- Alev Geciktirici Malzemeler: The ceramic space heater is constructed from flame-retardant materials to minimize fire hazards.
- Always plug the heater directly into a wall outlet. Do not use with extension cords or power strips.
- Do not cover the heater or block its air inlets/outlets. Maintain a minimum distance of 3 feet (0.9 meters) from walls, furniture, and curtains.
- Keep the heater away from water and do not use it in wet or damp locations like bathrooms (unless specifically designed and rated for such use).
- Isıtıcı çalışırken çocukları ve evcil hayvanları gözetim altında tutun.
- Kullanmadığınız zamanlarda veya temizlemeden önce ısıtıcının fişini çekin.

Image: Visual representation of the heater's tip-over and overheat safety mechanisms.
2. Ürün Bittiview
The Electactic H36902 Portable Ceramic Space Heater is designed to provide efficient and targeted heating for small to medium-sized indoor spaces. Its compact design and integrated handle make it easy to move between rooms, offering versatile comfort.

Resim: Ön view of the Electactic H36902 Portable Ceramic Space Heater.
Temel Özellikler:
- 2'si 1 arada İşlevsellik: Offers two heat settings (750W Low Heat, 1500W High Heat) for cold weather and a cool air fan mode for warmer days.
- Ayarlanabilir Termostat: Allows you to set your desired room temperature between 41°F and 95°F. The heater will automatically cycle on and off to maintain the set temperature.
- Hızlı Isıtma: Utilizes PTC ceramic heating technology to deliver warmth within 2 seconds.
- Sessiz Çalışma: Operates at a noise level below 45 decibels, suitable for bedrooms and offices.
- Kompakt ve Taşınabilir: Lightweight (under 3 lbs) with an easy-to-carry handle, making it ideal for personal use in various indoor settings.
- Isıtma Kapsamı: Effectively heats areas up to 200 square feet.

Image: Illustration showing the heater's rapid 2-second heating feature.

Image: Diagram comparing the heater's low noise level to common sounds.
3. Kurulum
- Paketi aç: Isıtıcıyı ambalajından dikkatlice çıkarın. Ambalajı, ilerideki depolama veya taşıma için saklayın.
- Atama: Place the heater on a firm, level surface. Ensure there are no obstructions within 3 feet (0.9 meters) of the front, back, or sides of the heater. Do not place it on soft surfaces like beds or rugs where openings may be blocked.
- Güç Bağlantısı: Güç kablosunu doğrudan 120V AC, 60Hz'lik bir duvar prizine takın. Prizin iyi durumda ve aşırı yüklenmemiş olduğundan emin olun.
4. Kullanım Talimatları
The Electactic H36902 features two control knobs on the top for easy operation.

Image: Heater operating in a room, highlighting its coverage and control knobs.
Kontrol Düğmeleri:
- Sağ Düğme (Mod Seçici): This knob controls the power and operating mode.
- KAPALI (0): Isıtıcıyı kapatır.
- FAN (Fan Icon): Activates the fan-only mode, circulating cool air.
- LOW HEAT (I): Activates the 750W low heat setting.
- HIGH HEAT (II): Activates the 1500W high heat setting.
- Sol Düğme (Termostat Kontrolü): This knob adjusts the desired temperature.
- Rotate clockwise for higher temperatures (up to 95°F).
- Rotate counter-clockwise for lower temperatures (down to 41°F).
- Isıtıcı, ayarlanan sıcaklığı korumak için açılıp kapanacaktır.
Adım Adım İşlem:
- Plug the heater into a suitable electrical outlet. The power indicator light will illuminate.
- Çevir Mode Selector (Right Knob) to your desired setting: FAN, LOW HEAT (I), or HIGH HEAT (II).
- If a heat setting is selected, adjust the Thermostat Control (Left Knob) to your preferred temperature.
- Isıtıcıyı kapatmak için, çevirin. Mode Selector (Right Knob) to the OFF (0) position.

Image: Heater demonstrating its dual functionality as a fan and a heater.
Ürün Tanıtım Videosu:
Video: A seller-provided demonstration of the heater's features and operation, including heat settings and safety features.
5. Bakım
Düzenli bakım, ısıtıcınızın optimum performans göstermesini ve uzun ömürlü olmasını sağlar.
- Temizlik:
- Temizlemeden önce ısıtıcının fişini mutlaka çekin ve tamamen soğumasını bekleyin.
- Yumuşak bir d kullanınamp Dış yüzeyleri silmek için bez kullanın. Aşındırıcı temizleyiciler veya çözücüler kullanmayın.
- Hava giriş ve çıkış ızgaralarındaki tozu, fırçalı bir başlık takılı elektrikli süpürge kullanarak nazikçe temizleyin.
- Depolamak: Kullanılmadığı zamanlarda ısıtıcıyı serin ve kuru bir yerde saklayın. Toz ve hasardan korumak için orijinal ambalajında saklamanız önerilir.
6. Sorun Giderme
If your heater is not operating correctly, please consult the following common issues before contacting support.
| Sorun | Olası Neden | Çözüm |
|---|---|---|
| Isıtıcı açılmıyor. | Not plugged in; power switch off; tip-over switch activated; overheat protection activated. | Ensure plug is secure; turn power switch on; place heater upright on a flat surface; allow unit to cool down. |
| Isı çıkışı yok. | Fan mode selected; thermostat set too low; overheat protection activated. | Select a heat mode (I or II); increase thermostat setting; allow unit to cool down. |
| Isıtıcı beklenmedik bir şekilde kapanıyor. | Tip-over switch activated; overheat protection activated. | Place heater upright on a flat surface; allow unit to cool down. Ensure air inlets/outlets are not blocked. |
7. Özellikler
| Özellik | Detay |
|---|---|
| Marka | Elektroktik |
| Model Numarası | H36902 |
| Güç Çıkışı | 1500W (Yüksek), 750W (Düşük) |
| Cilttage | 120 Volt |
| Ürün Boyutları | 5.47"D x 6.85"G x 9.65"Y |
| Ürün Ağırlığı | 2.58 pound |
| Isıtma Kapsamı | 200 metrekareye kadar |
| Sıcaklık Aralığı | 41°F - 95°F |
| Özel Özellikler | Adjustable Temperature, Electronic Thermostat, Fast Heating, Overheat Protection, Tip-Over Protection |

Image: Heater on a desk, illustrating its compact size and dimensions.
8. Garanti ve Destek
For warranty information or product support, please refer to the documentation included with your purchase or contact Electactic customer service. Keep your purchase receipt as proof of purchase.
For further assistance, please visit the official Electactic websiteyi ziyaret edin veya müşteri destek kanallarıyla iletişime geçin.
