XTAR Next Generation 1.5V AA Lithium Rechargeable Batteries (4-Pack) User Manual

1. Ürün Bittiview

The XTAR Next Generation 1.5V AA Lithium Rechargeable Batteries are designed to provide a stable 1.5V output, making them suitable for a wide range of electronic devices. These batteries offer a capacity of 2000mAh (3000mWh) and can be recharged up to 1200 times, offering an economical and environmentally conscious alternative to disposable alkaline batteries.

Each battery integrates a high-efficiency charge and discharge management chip, utilizing 2.4MHz synchronous rectified buck discharge technology. This ensures a constant 1.5V output when the battery voltage is above 3.3V. When the battery voltage drops below 3.3V, the output voltage decreases linearly, signaling a low power state to the device.

Four XTAR 1.5V AA Lithium Rechargeable Batteries in a clear plastic case.

Image: XTAR 1.5V AA Lithium Rechargeable Batteries (4-Pack).

2. Güvenlik Bilgileri

These batteries are equipped with multiple protection features to ensure safe operation:

Aşırı Şarj Koruması: Aşırı şarjdan kaynaklanan hasarı önler.
Aşırı Deşarj Koruması: Pil seviyesinin aşırı derecede düşmesini önler.
Kısa Devre Koruması: Kısa devre durumunda otomatik olarak elektriği keser.
Aşırı Sıcaklık Koruması: Monitors and prevents overheating during use or charging.

Always use the recommended XTAR chargers (such as L4, L8, BC8, BC4, LC4, MX4, VX4) for 1.5V AA/AAA lithium batteries to ensure optimal performance and safety.

XTAR AA battery with a protective shield graphic and icons for overcharge, over-discharge, short circuit, and over-temperature protection.

Image: Integrated safety features of the XTAR AA battery.

3. Kurulum

3.1 Paket İçeriği

Paketinizin aşağıdaki öğeleri içerdiğini doğrulayın:

4 x XTAR 1.5V AA Lithium Rechargeable Batteries
1 x Battery Storage Case

Package contents showing four XTAR AA batteries and a clear plastic storage case.

Image: Contents of the XTAR AA battery package.

3.2 İlk Şarj

For optimal performance, fully charge the batteries before first use. Insert the batteries into a compatible XTAR charger. The charger's indicator will show the charging status and signal when charging is complete.

4. Kullanım Talimatları

4.1 Pil Takılması

Insert the batteries into your electronic device according to the polarity markings (+ and -) inside the battery compartment. Ensure a secure fit.

4.2 Stable 1.5V Output

These batteries maintain a stable 1.5V output throughout most of their discharge cycle, unlike traditional alkaline or Ni-MH batteries where voltage gradually drops. This ensures consistent performance for your devices.

Graph comparing the discharge voltage of XTAR 1.5V lithium batteries, other 1.5V constant voltage batteries, dry cell batteries, and 1.2V Ni-MH batteries over capacity.

Image: Discharge curve comparison showing stable 1.5V output.

4.3 Uyumlu Cihazlar

With a 2.5A discharge current, these batteries are suitable for high-power consumption devices such as digital cameras, remote control toys, wireless mice, blood pressure monitors, and flashlights. They are designed to meet the high energy demands of various electronic equipment.

Various electronic devices including a remote control car, smart lock, digital clock, flashlight, calculator, microphone, electric toothbrush, and computer peripherals, illustrating wide application scenes for the batteries.

Resim: Eskiamples of devices compatible with XTAR AA batteries.

5. Bakım ve Saklama

5.1 Uzun Süreli Saklama

If the lithium-ion batteries will not be used for an extended period, store them in the provided battery box in a cool, dry place away from direct sunlight. It is recommended to perform a standard charge and discharge cycle every six months, followed by a 1.5-hour recharge, to maintain battery health.

5.2 Çalışma Sıcaklığı

These batteries are designed to operate normally in extreme temperatures, ranging from -20°C to 60°C (-4°F to 140°F).

XTAR AA batteries shown in extreme cold (-20°C) and hot (60°C) environments, demonstrating their wide operating temperature range.

Image: Batteries performing in extreme climate conditions.

6. Sorun Giderme

Cihaz Açılmıyor: Ensure batteries are inserted with correct polarity. Check if batteries are fully charged. Some devices may have specific power requirements; verify compatibility.
Pil Şarj olmuyor: Ensure the charger is properly connected to a power source. Verify that the batteries are correctly inserted into the charger. Use only XTAR recommended chargers.
Excessive Heat During Use/Charging: While some warmth is normal, excessive heat may indicate an issue. Discontinue use or charging immediately and consult the support section.
Çalışma Süresinde Azalma: Battery capacity can decrease over time with repeated cycles. Ensure proper storage and maintenance practices are followed.

7. Özellikler

Özellik	Şartname
Pil Türü	Lityum iyon
Nominal Hacimtage	1.5V ± 0.05V
Nominal Kapasite	2000mAh (3000mWh)
Döngü Sayısı	>1200 çevrim
Size (Φ x L)	Φ(14.3 ± 0.3)mm x L(50.3 ± 0.5)mm
Pil başına ağırlık	20 gr
Deşarj Akımı	2.5A'ya kadar
Çalışma Sıcaklığı	-20°C ila 60°C

A table detailing the specifications of the 2000mAh AA Lithium Battery, including nominal voltage, nominal capacity, size, weight, and cycle count.

Image: Detailed specifications of the XTAR AA Lithium Battery.

8. Garanti ve Destek

Bu ürün bir 1 yıllık üretici garantisi from the date of purchase. The warranty covers defects in materials and workmanship under normal use.

For technical support, warranty claims, or any questions regarding your XTAR batteries, please contact XTAR customer service through the retailer where the product was purchased or visit the official XTAR webiletişim bilgileri için site.

Lütfen garanti hizmeti için satın alma belgenizi saklayın.
