Introducere
This manual provides comprehensive instructions for the safe and efficient operation, maintenance, and troubleshooting of your AIRROBO PC100 Robotic Pool Cleaner. Please read this manual thoroughly before using the device and retain it for future reference.
Image: The AIRROBO PC100 Robotic Pool Cleaner, a compact and efficient device designed for autonomous pool cleaning.
Produs terminatview
The AIRROBO PC100 is a wireless robotic pool cleaner designed to efficiently clean the floor, walls, and waterline of various pool types. It features intelligent navigation and powerful suction for thorough cleaning.
Caracteristici cheie:
- Operare wireless: Eliminates tangled cables and hoses, offering hassle-free operation with a single button press.
- Moduri duble de curățare: Automatically scrubs the pool floor, waterline, and walls.
- Strong Suction & Fine Filtration: Equipped with powerful suction, efficient motors, and active scrubbing brushes to remove dust, sand, and small debris. A 180 µm fine filter ensures effective debris capture.
- Navigație inteligentă: Utilizes automatic positioning and smart path planning for comprehensive zigzag cleaning.
- Durată de viață extinsă a bateriei: Provides up to 150 minutes of cleaning, covering areas up to 288 m².
- Parcare automată: The robot parks near the pool wall when the battery is low or a cleaning cycle is complete, facilitating easy retrieval.
Ce este în cutie:
- AIRROBO PC100 Pool Cleaner
- Filtru intern
- Instrumente de întreținere
- Adaptor de alimentare
- Cârlig de recuperare
Înființat
- Încărcați dispozitivul: Before first use, fully charge the AIRROBO PC100 using the provided power adapter. Ensure the charging port is dry before connecting the adapter. The charging indicator will show the charging status.
- Pregătiți piscina: Ensure the pool is free of large debris that could obstruct the cleaner. The water temperature should be within the recommended operating range (typically 10°C to 35°C).
- Scufundați aparatul de curățare: Gently lower the cleaner into the pool. Tilt it slightly to allow air bubbles to escape until it sinks to the bottom. Ensure it is fully submerged before starting.
Image: The AIRROBO PC100 features a wireless design, eliminating the need for external cables during operation.
Instrucțiuni de operare
- Începeți curățarea: Once the cleaner is fully submerged, press the power button to initiate a cleaning cycle. The cleaner will begin its programmed cleaning path.
- Moduri de curățare: The PC100 operates with two cleaning modes, automatically adjusting to clean the pool floor, walls, and waterline. It uses intelligent path planning for efficient coverage.
- Wall Climbing: The cleaner is designed to climb pool walls up to a 90-degree angle to clean the waterline effectively.
- Parcare automată: Upon completion of a cleaning cycle or when the battery is low, the cleaner will automatically move to the nearest pool wall and park itself for easy retrieval.
- Recuperarea dispozitivului de curățare: Use the provided retrieval hook to gently pull the cleaner to the surface. Allow excess water to drain before lifting it out of the pool.
Image: The PC100 uses intelligent path planning for efficient and thorough cleaning in a zigzag pattern.
Image: The cleaner demonstrates its wall-climbing capability, adhering closely to walls for comprehensive cleaning.
Image: The robot automatically stops and parks itself at the side of the pool for easy retrieval after cleaning.
Întreţinere
Regular maintenance ensures optimal performance and extends the lifespan of your AIRROBO PC100.
- Curățați filtrul: After each cleaning cycle, remove the internal filter and rinse it thoroughly with clean water. Ensure all debris is removed from the 180 µm fine filter.
- Scurgerea apei: Before storing, ensure all water is drained from the cleaner. The quick water drainage feature assists in this process.
- Curățați exteriorul: Ștergeți exteriorul aparatului de curățat cu o lavetă moale șiamp pânză. Nu utilizați substanțe chimice dure sau materiale abrazive.
- Inspect Brushes and Tracks: Periodically check the scrubbing brushes and tracks for any trapped debris or wear. Clean or replace as necessary.
- Depozitare: Store the cleaner in a cool, dry place away from direct sunlight and extreme temperatures. Ensure the battery is partially charged before long-term storage.
Image: The cleaner features a quick water drainage system, making it easy to remove water after use.
Depanare
If you encounter issues with your AIRROBO PC100, refer to the following common problems and solutions:
| Problemă | Cauza posibila | Soluţie |
|---|---|---|
| Aparatul de curățat nu pornește | Low battery; Power button not pressed correctly; Obstruction | Charge the battery fully; Ensure the power button is pressed firmly; Check for and remove any obstructions. |
| Performanță slabă de curățare | Clogged filter; Worn brushes; Large debris in pool | Clean the internal filter; Inspect and replace brushes if worn; Remove large debris manually before cleaning. |
| Agentul de curățenie se blochează | Obstruction; Uneven pool surface; Low battery | Remove any obstructions; Ensure the pool surface is suitable for robotic cleaners; Charge the battery. |
| Cleaner nu se catara pe pereti | Low battery; Slippery pool surface (algae); Worn tracks/brushes | Ensure battery is fully charged; Brush pool walls to remove algae; Inspect and replace tracks/brushes if worn. |
If the problem persists, please contact AIRROBO customer support.
Specificații
| Caracteristică | Detaliu |
|---|---|
| Numărul de model | YM-EU-PC100-01 |
| Dimensiuni (L x l x H) | 42 x 39 x 21 cm |
| Greutate | 11.92 kg |
| Material | Plastic |
| Culoare | Alb |
| Sursa de alimentare | Alimentat cu baterie |
| Tip baterie | Litiu |
| Capacitatea bateriei cu litiu | 68.48 wați-oră |
| Greutatea bateriei | 460 grame |
| Timp de rulare | Până la 150 de minute |
| Zona de curățare | Până la 288 m² |
| Finețea filtrului | 180 µm |
| Metoda de control | Buton de apăsare |
| Caracteristici speciale | Wireless, Intelligent Navigation, Automatic Parking, Wall Climbing |
Image: Visual representation of the PC100's 150-minute run time and ability to clean up to 288 m² with its 7800 mAh battery.
Garanție și suport
AIRROBO provides a 1-year warranty service for the PC100 Robotic Pool Cleaner. For any questions, technical assistance, or warranty claims, please do not hesitate to contact AIRROBO customer support.
Please refer to your purchase documentation or the official AIRROBO website-ul pentru detalii de contact specifice și termeni de garanție.
