CoreLine Trunking Gen2
Instruction Manual

CoreLine Trunking Gen2

Prevent water from entering on or in the iluminare at installation and during use of the luminaire.

• for use with SIA drivers (sensor LL200E H4) or SR drivers (sensor LL200E IRE)
• one sensor supports max. 4 drivers
• to separate group of luminaires containing one sensor use the separator connector

Inrush current

* Warning! The values on the left are for 1.5 mm thick cables, the values on the right are for 2.5 mm thick cables

Maintenance instructions

To asssure the lighting quality of this unique LED lighting concept there are a few instructions regading the maintenance of this LED luminaire:

1. Do not touch electronic components!
   Electronic components are under high voltage.
   Electronic components are ESD sensitive.
2. During installation or when maintaining the luminaire please use static free gloves to avoid marks on the luminaire.
3. To remove dirt and spots use the following:
   Dust: only use micro fiber cloths
   Fingerprints, etc.: use a cleaner for synthetic materials with antistatic properties.
4. Do not stare into the LED light beam.
5. To avoid scratches and dirt on optical parts remove protective foil after installation.
6. The luminaire shall be installed by a qualified electrician and wired in accordance with the lastest IEE electrical regulations or the nationak requirements.
7. The light source of this luminarie is not replaceable: when the light source reaches its end of life whole luminare shall be replaced.
8. Driver insulation: Basic according to IEC 61847-1.

442710401452
© 04/ 2020, Signify Holding All rights reserved
Printed in Poland
Data subject to change without notice
Keep for future reference: www.philips.com/lighting
